Ubiquiti Networks

Ubiquiti UniFi Access Point U7 Lite | WiFi 7, 5 Gbps

SKU: ART7806
GTIN: 0810084698747
HAN: U7-Lite
Category: UniFi Access Points

WiFi 7 in compact format. The Ubiquiti U7-Lite proves that you don't need huge devices for the latest WiFi standard. This ultra-compact access point brings the efficiency of WiFi 7 to your 2.4 GHz and 5 GHz network. Attention: To remain as space-saving as possible, the "Lite" skips the 6 GHz frequency band but extracts an incredible 4.3 Gbps from the 5 GHz range alone thanks to modern modulation (4096-QAM)! With a total throughput of 5 Gbps and a fast 2.5 GbE uplink, it is the perfect, unobtrusive all-rounder for modern home offices and businesses that want WiFi 7 speeds without upgrading infrastructure for 6 GHz.

Highlights

Compact Design: As small as a nanoHD – barely noticeable on the ceiling.
WiFi 7 Power: Uses 4096-QAM for maximum speed on 2.4 & 5 GHz.
5 Gbps Speed: Massive performance (4.3 Gbps on 5 GHz + 688 Mbps on 2.4 GHz).
2.5 GbE Uplink: Fast network port to prevent WiFi bottlenecks.
Dual-Band Efficiency: Optimizes existing frequencies (no 6 GHz support!).

Do you have questions about the Ubiquiti U7-Lite? Then just ask us!

108,49 €

incl. 19% VAT , plus

Available immediately

Delivery time: 2 - 3 Workdays (DE - int. shipments may differ)

Ubiquiti UniFi Access Point U7 Lite | WiFi 7, 5 Gbps

108,49 € *

Add to basket

Ubiquiti U7-Lite: The Little Giant

You want the benefits of WiFi 7 (extreme speed, low latency), but you don't want to hang huge "UFOs" on your ceiling?
The U7-Lite is the solution. It packs the latest technology into the popular, compact housing of the Lite/nanoHD series.

Important: Dual-Band WiFi 7

To achieve this form factor, Ubiquiti makes a smart compromise: The U7-Lite omits the new 6 GHz frequency band.
Instead, it uses WiFi 7 technology (like 4096-QAM) to massively accelerate the classic 5 GHz band. It reaches up to 4.3 Gbps there – that's almost double that of its predecessor, the U6-Pro!

2.5 GbE is Mandatory

Don't be fooled by the name "Lite". With 5 Gbps total throughput, a standard Gigabit connection would immediately throttle this AP.
That's why even the smallest of the U7 series features a full 2.5 GbE Uplink Port. Ideal in combination with a UniFi Enterprise Switch or the U7-Pro-Wall Switch.

Detailed Technical Data

General & Mechanical
Manufacturer / Model:	Ubiquiti / U7-Lite
EAN:	0810084698747
Dimensions:	Ø 171.5 x 33 mm (Ultra-Slim Design)
Weight:	approx. 313 g
Mounting:	Wall or Ceiling (Bracket included)
Hardware & Connectivity
Network Interface:	1x 1/2.5 GbE RJ45 Port
Power Supply:	PoE (802.3af/at) - passive cooling
Power Consumption:	Max. 13 Watt
WiFi Specifications
WiFi Standards:	WiFi 7 (802.11be) - Dual Band
Total Throughput:	5.0 Gbps (Aggregate)
Frequency Bands:	2.4 GHz / 5 GHz (NO 6 GHz!)
MIMO Configuration:	2x2 MIMO on both bands
Max. Throughput Rate:	2.4 GHz: 688 Mbps 5 GHz: 4,324 Mbps (BW240 Support)
Antenna Gain:	2.4 GHz: 4.0 dBi 5 GHz: 5.0 dBi
TX Power:	2.4 GHz: 23 dBm 5 GHz: 24 dBm
Software & Features
Security:	WPA-PSK, WPA-Enterprise (WPA2/WPA3)
BSSID:	Up to 8 per radio
Concurrent Clients:	200+

Scope of Delivery

1 x Ubiquiti U7-Lite Access Point

1 x Mounting Plate (Plastic)

1 x Screw Kit

Note: PoE Injector is NOT included!
