The Whisper-Quiet Core of Your UniFi Network
The USW-Lite-16-PoE is more than just a distributor for your Network Cabling. It is an intelligent, fully Managed Network Switch, specifically designed for seamless integration into the Ubiquiti UniFi ecosystem. Forget complicated command lines or different web interfaces for each device. With the UniFi Network Controller, you manage this UniFi Switch, your UniFi Access Points, and gateways centrally in one place – whether from a PC or via an app on your smartphone. This gives you full control and overview, anytime and from anywhere.
Compact Design, Strong Performance for Small Offices
Specifically designed for environments where no dedicated Network cabinet or 19-Inch Racks are present, the USW-Lite-16-PoE shines with its compact housing and wall-mounting capability. Its biggest advantage for the workplace or living room, however, is its absolutely silent operation. Thanks to the passive, fanless design, there are no disturbing fan noises. Eight of the sixteen Gigabit ports deliver PoE+ power, ideal for operating a small number of UniFi Access Points, IP Cameras, or phones. Note the total PoE budget of 45 Watts to optimally plan your devices using PoE Injectors / Power Supplies.
Strengths & Notes at a Glance
- Pro: Seamless integration into the Ubiquiti UniFi ecosystem for central, intuitive management of the entire Network.
- Pro: Absolutely silent operation due to fanless design, perfect for noise-sensitive environments like offices or living spaces.
- Pro: Compact, space-saving housing with included wall mount for flexible Mounting Systems.
- Pro: Extensive professional Layer-2 features like VLANs, LACP, and Port Isolation for granular Network control.
- Note: The PoE budget of 45 Watts is very limited and can quickly be exhausted with several power-hungry devices.
- Note: As a pure Layer-2 Ethernet Switch, it offers no routing functions; Inter-VLAN routing must be handled by a separate device.
Specifications & Features
| Manufacturer: | Ubiquiti |
| Model: | UniFi USW-Lite-16-PoE |
| EAN: | 0810010071163 |
| MPN/HAN: | USW-Lite-16-PoE |
| Product Type: | Managed Network Switch |
| Management Level: | Layer 2 |
| Dimensions: | 191.7 x 185 x 43.7 mm |
| Weight: | 1.2 kg |
| Housing Material: | Polycarbonate |
| Mounting: | Desktop, Wall mount (Kit included) |
| Cooling: | Passive (fanless) |
| Network Ports: | 16x GbE RJ45 (10/100/1000 Mbps) |
| PoE Ports: | 8x PoE+ (Ports 9-16) |
| PoE Standard: | IEEE 802.3af/at (auto-sensing) |
| Max. PoE+ Power per Port: | 30W |
| Total PoE Budget: | 45W |
| PoE Voltage Range (802.3at): | 50-57V |
| PoE Pinout: | Pins 1, 2+; 3, 6- |
| Switching Capacity: | 32 Gbps |
| Total Non-Blocking Throughput: | 16 Gbps |
| Forwarding Rate: | 24 Mpps |
| MAC Address Table: | 8,000 entries |
| Jumbo Frames: | Supported |
| Packet Buffer Size: | 0.5 MB |
| Management Interface: | Ethernet In-Band |
| Management Platform: | UniFi Network Controller, UniFi Mobile App |
| Power Supply: | Internal Power Supply |
| Input Voltage: | 100-240VAC, 50/60 Hz |
| Power Supply Output: | 60W |
| Max. Power Consumption (without PoE): | 15W |
| Max. Power Consumption (with PoE): | 60W |
| Operating Temperature: | -15°C to 40°C |
| Humidity (Operating): | 10% to 90% (non-condensing) |
| Certifications: | CE, FCC, IC |
| LED Indicator (System): | Status (Boot, Upgrade, Adopted) |
| LED Indicator (Ethernet): | Green (1 Gbps), Yellow (10/100 Mbps) |
| LED Indicator (PoE): | Yellow (IEEE 802.3af/at Activity) |
Scope of Delivery
| 1 x Ubiquiti UniFi USW-Lite-16-PoE |
| 1 x Wall Mount Kit |
| 1 x Power Cable |
Frequently Asked Questions (FAQ)
Do I need a UniFi Controller to use the USW-Lite-16-PoE?
Yes, an instance of the UniFi Network Controller is required for configuring and managing advanced functions such as VLANs or port settings. This can run on a computer, a server, or dedicated UniFi hardware like a Cloud Key or a Dream Machine. Without a controller, the UniFi Switch functions only as an unmanaged Ethernet Switch with basic functionality.
How many UniFi Access Points can I operate with the USW-Lite-16-PoE?
This heavily depends on the UniFi Access Point model. A typical UniFi AP like the U6+ requires approx. 9W. Theoretically, you could operate up to 5 such WiFi Access Points (5 x 9W = 45W). For more power-hungry models like the U6 Pro (approx. 13W), the number reduces to about 3 devices. It is crucial to calculate the total consumption of the planned PoE Injectors / Power Supplies devices and compare it with the 45W budget.
Is the UniFi Switch suitable for rack mounting?
No, the USW-Lite-16-PoE is designed for desktop use or wall mounting and does not have the standard 19-Inch Racks width for direct rack mounting. It would need to be placed on a rack shelf.
Does the UniFi Switch support 10-Gigabit uplinks (SFP+)?
No, this model exclusively features 1-Gigabit Ethernet Ports and does not have SFP / SFP\+ Modules slots for fiber optic or faster copper uplinks.
Can I configure the UniFi Switch without an internet connection?
Yes, the initial configuration can be done in a local Network without an active internet connection. However, you need a device on the same Network running the UniFi Network Controller to 'adopt' and configure the UniFi Switch. The UniFi Switch has the standard fallback IP address 192.168.1.20 if it does not find a DHCP server.
Is the UniFi Switch suitable for operating IP Cameras?
Yes, as long as the IP Cameras comply with the 802.3af/at PoE standard and their total power consumption does not exceed the 45W budget. A typical IP Camera consumes between 4 and 12 watts, so operating 3 to 8 IP Cameras is possible depending on the model.
