Your Reliable Partner for Power over Ethernet
The Ubiquiti U-POE-af is not just a PoE Injector, but your smart solution for flexibly powering Network devices such as WiFi Access Points and IP Cameras. It strictly adheres to the IEEE 802.3af PoE standard and delivers constant 48V DC at 0.32A, which corresponds to a power output of up to 15.4 Watts. This means for you: a stable and secure power supply via a single Ethernet cable, without the need for additional outlets or power adapters at the installation site. This is particularly practical for many Ubiquiti UniFi Access Points like the U6 Lite or U6 Mesh, as well as for UniFi Protect IP Cameras like the G4 Pro, which require exactly this standard. This way, you avoid incorrect purchases and ensure that your devices function optimally.
Convincing Security: Protection for Your Devices
We know how important the protection of your investments is. That's why the Ubiquiti U-POE-af PoE Injector offers comprehensive security features that are often overlooked but are crucial. With integrated overvoltage protection, protection against peak current and overcurrent, as well as effective ESD protection (electrostatic discharge), your connected devices are optimally secured. Particularly noteworthy is the grounding via the AC cable. This function is invaluable, especially for outdoor installations of WiFi Access Points or IP Cameras. It safely dissipates potentially harmful voltage spikes, for example from lightning strikes or static electricity, thereby protecting the longevity and operational safety of your entire Network.
Gigabit Speed Meets Effortless Installation
No desire for complicated configurations? You don't have to! The Ubiquiti U-POE-af is a true Plug-and-Play device. You simply connect it, and it works – entirely without software or elaborate settings. This makes it an ideal solution for home users or small offices who want a straightforward Network expansion. And don't worry about speed: with a Gigabit LAN Port, the injector ensures that your data is transmitted at lightning speed. This way, you benefit from full network performance while your devices are reliably powered. Whether you're integrating a new WiFi Access Point or installing an IP Camera, the setup is done in no time.
Everything You Need to Know: Frequently Asked Questions about the U-POE-af
You might be wondering what distinguishes the Ubiquiti U-POE-af from other PoE Injectors. The crucial point is its 802.3af compliance with 48V and 15.4 Watts. This is important because Ubiquiti also offers injectors for other standards or older 24V passive PoE devices. The U-POE-af is *not* suitable for these passive 24V devices and could damage them. So always pay attention to the specifications of your end device! Installation is extremely simple: connect your network device to 'PoE Out', your router/switch to 'Data In', and plug in the AC cable. For optimal safety, especially outdoors, we recommend shielded Ethernet Cables, which perfectly complement the injector's integrated ESD protection and grounding. This way, your Network remains stable and protected.
Strengths & Notes at a Glance
- Pro: Standard-compliant and reliable power supply according to IEEE 802.3af with 48V DC and up to 15.4 Watts.
- Pro: Comprehensive protection for connected devices through integrated overvoltage, peak current, overcurrent, and ESD protection, as well as grounding.
- Pro: Gigabit Ethernet support for fast data transmission and easy Plug-and-Play installation without software.
- Note: Limited power to 15.4 Watts (802.3af), not suitable for higher PoE standards (802.3at/bt).
- Note: No remote reset function or LAN activity indicator, which can complicate remote maintenance.
Specifications & Features
| Manufacturer: | Ubiquiti |
| Model: | U-POE-af |
| Product Type: | PoE Injector / PoE Adapter |
| EAN: | 0817882024976 |
| PoE Standard: | IEEE 802.3af |
| Output Voltage: | 48V DC |
| Output Current: | 0.32A |
| Max. Power: | 15.4 Watt |
| Data Rate: | Gigabit Ethernet (10/100/1000 Mbps) |
| Protection Features: | Overvoltage, Peak Current, Overcurrent, ESD, Grounding |
| Ports: | 1x Data In (RJ45), 1x PoE Out (RJ45), AC Power |
| Compatibility: | Many Ubiquiti UniFi Access Points & IP Cameras (802.3af) |
| Installation: | Plug-and-Play, no software configuration |
| Operating Temperature: | 0 to 40°C |
| Dimensions (L x W x H): | 87 x 44 x 29 mm |
| Weight: | 0.15 kg |
| LED Indicators: | Power |
Scope of Delivery
| 1 x Ubiquiti U-POE-af PoE Injector |
| 1 x AC Power Cable (with grounding) |
Frequently Asked Questions (FAQ)
What is the difference between the Ubiquiti U-POE-af and other Ubiquiti PoE Injectors?
The Ubiquiti U-POE-af is an 802.3af-compliant PoE injector that delivers up to 15.4 watts of power and supports Gigabit Ethernet. Ubiquiti also offers other injectors that support higher standards like 802.3at (PoE+) or 802.3bt (PoE++) for devices with higher power consumption, or power older 24V passive PoE devices.
Which devices can I power with the Ubiquiti U-POE-af PoE Injector?
The U-POE-af is ideal for all devices that support the IEEE 802.3af PoE standard and require a maximum of 15.4 watts of power. These include many Ubiquiti UniFi Access Points (such as U6 Lite, U6 Mesh) and IP Cameras (e.g., UniFi G4 Pro), as well as VoIP phones.
Do I need a special cable for the Ubiquiti U-POE-af?
No, the U-POE-af uses standard Ethernet Cables (RJ45) for data and power transmission. However, it is recommended to use shielded cables, especially in conjunction with the integrated ESD protection, to ensure optimal performance and protection.
How do I install the Ubiquiti U-POE-af PoE Injector?
Installation is plug-and-play. Simply connect an Ethernet Cable from your network device (e.g., UniFi Access Points) to the "PoE Out" port of the injector and another Ethernet Cable from your router/switch to the "Data In" port. Then connect the included AC cable to a power outlet. No software configuration is required.
Can the Ubiquiti U-POE-af also power 24V passive PoE devices?
No, the Ubiquiti U-POE-af is an active 802.3af PoE Injector that delivers 48V DC. It is not designed to power 24V passive PoE devices and could damage them if they are not rated for 48V. Specific 24V passive PoE Injectors / Power Supplies are required for 24V passive devices.
What role does the grounding connection on the AC cable of the U-POE-af play for network security?
The grounding connection on the AC cable of the U-POE-af is crucial for comprehensive protection against overvoltage and electrostatic discharge (ESD). It safely dissipates potentially harmful voltage spikes before they can reach and damage connected Network devices, which is particularly important in environments with a high risk of Lightning Protection or static charge.
