U7-LR: When Range is Everything
The name 'Long Range' is truly descriptive of the U7-LR. While other WiFi Access Points reach their limits, this model shines with a superior Antenna design (6 dBi on 5 GHz Components) and optimized transmit power. The result? A WiFi signal that effortlessly covers larger areas and even more effectively penetrates concrete ceilings and multiple walls. If you're looking for a reliable UniFi Access Point for a large house and want to minimize the number of devices, the U7-LR is the top choice for seamless and stable Network connectivity in every corner.
Future-Proof with Wi-Fi 7 – Intelligently Focused on 5 GHz
The U7-LR brings the power of Wi-Fi 7 specifically to the most widely used frequency bands. By implementing features like 4096-QAM modulation and 160 MHz wide channels on the 5 GHz Components band, you achieve drastically higher efficiency and speed compared to older Wi-Fi 6 devices. Paired with the fast 2.5 GbE Uplink Port, it ensures that the full performance of this WiFi Access Point can be utilized without bottlenecks. It is fully backward compatible and integrates seamlessly into your existing UniFi Network, optimally serving all your devices – from old to new.
Strengths & Considerations at a Glance
- Pro: Excellent range and penetration, ideal for large or complex buildings.
- Pro: Future-proof Wi-Fi 7 technology on the stable 5 GHz Components band for higher data rates.
- Pro: Fast 2.5 GbE port prevents performance bottlenecks in the uplink.
- Pro: Very high client capacity of over 300 devices for dense Networks.
- Note: Does not have a 6 GHz frequency band, thus not utilizing the full Wi-Fi 7 spectrum.
- Note: Requires the UniFi Ecosystem (e.g., UniFi Network Controller) for full utilization.
Specifications & Features
| Manufacturer: | Ubiquiti |
| Model: | UniFi U7 Long-Range |
| Manufacturer Part Number (MPN): | U7-LR |
| EAN/GTIN: | 0810177161929 |
| Device Class: | WiFi Access Point |
| Dimensions: | Ø 175.7 x 43 mm |
| Weight: | 448 g |
| Housing Material: | Polycarbonate, Aluminum Alloy |
| Mounting Material: | Polycarbonate, Galvanized Steel (SGCC) |
| Mounting Options: | Ceiling and Wall Mounting |
| LED Indicator: | System LED (White/Blue) |
| Network Interface: | 1x 2.5 GbE RJ45 Port |
| Management Interface: | Ethernet |
| Power Supply Method: | Power over Ethernet (PoE) |
| Supported Voltage Range: | 42.5–57V DC |
| Max. Power Consumption: | 14W |
| WiFi Standard: | Wi-Fi 7 (IEEE 802.11be) |
| Backward Compatibility: | 802.11a/b/g/n/ac/ax |
| Frequency Bands: | 2.4 GHz, 5 GHz |
| MIMO Configuration (5 GHz): | 3x3 (DL/UL MU-MIMO) |
| MIMO Configuration (2.4 GHz): | 2x2 (DL/UL MU-MIMO) |
| Spatial Streams (Total): | 5 |
| Max. Data Rate (5 GHz): | 4.3 Gbps |
| Max. Data Rate (2.4 GHz): | 688 Mbps |
| Antenna Gain (5 GHz): | 6 dBi |
| Antenna Gain (2.4 GHz): | 4 dBi |
| Max. Transmit Power (5 GHz): | 27 dBm |
| Max. Transmit Power (2.4 GHz): | 26 dBm |
| Supported Channel Bandwidths: | 20/40/80/160 MHz |
| Recommended Coverage: | approx. 160 m² |
| Max. Client Count: | 300+ |
| WiFi Security: | WPA, WPA2, WPA3, RADIUS, PPSK |
| Roaming Standards: | 802.11k, 802.11r, 802.11v |
| Network Management: | Band Steering, Wireless Meshing, VLANs, QoS |
| Operating Temperature: | -30 to 50° C |
| Operating Humidity: | 5 to 95 % non-condensing |
| Certifications: | CE, FCC, IC |
| NDAA Compliance: | Yes |
Scope of Delivery
| 1 x Ubiquiti UniFi U7 Long-Range Access Point (U7-LR) |
| 1 x Mounting Kit for Wall and Ceiling Mounting |
Frequently Asked Questions (FAQ)
Is the UniFi U7 Long Range really a 'true' Wi-Fi 7 Access Point, even though it doesn't have a 6 GHz band?
Yes, technically it is a Wi-Fi 7 Access Point. The Wi-Fi 7 standard (IEEE 802.11be) defines improvements for the 2.4, 5, and 6 GHz bands. The U7-LR implements these improvements, such as 4K-QAM modulation and 160 MHz channel width on the 5 GHz band, which significantly boosts performance compared to Wi-Fi 6. However, the absence of the 6 GHz band means it does not fully utilize the standard's potential for your Network.
Do I need a special PoE Injector for the U7-LR?
The U7-LR is powered via Power over Ethernet (PoE), but it does not require a special PoE Injector if you have a compatible UniFi Switch or other Ethernet Switch. It consumes a maximum of 14 watts. A PoE+ (802.3at) capable switch port is a safe choice to deliver the required power. A PoE Injector is not included in the scope of delivery, but various PoE Injectors / Power Supplies are available.
Who is the U7 Long Range better suited for than the U7-Pro?
The U7 Long Range is ideal for users whose priority is maximum coverage and range in the common 2.4 GHz and 5 GHz bands. If you want to cover a large, complex house or a big office space with as few UniFi Access Points as possible and do not necessarily need the 6 GHz band, the U7-LR is the more cost-effective and often more practical choice for your Network, utilizing its 2.4 GHz Components and 5 GHz Components.
Can I use the U7-LR with my old Wi-Fi 5 and Wi-Fi 6 devices?
Yes, absolutely. The U7-LR is fully backward compatible with all older Wi-Fi standards, including Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), and older ones. Your existing devices will connect seamlessly and benefit from the strong transmission power of this WiFi Access Point, enhancing your overall Network experience.
How many U7-LRs do I need for my house?
This depends heavily on the size, layout, and building materials of your house. As a rule of thumb, a centrally placed U7-LR WiFi Access Point can cover an area of up to 160 m². For reinforced concrete walls or multiple floors, it is recommended to plan one Access Point per critical area to ensure seamless Network coverage.
What is the difference between the 3x3 MIMO of the U7-LR and the 2x2 MIMO of the U7-Pro on the 5 GHz band?
The U7-LR features a 3x3 MIMO configuration on the 5 GHz band, whereas the U7-Pro only offers 2x2 MIMO there. Theoretically, a 3x3 configuration can process more data streams simultaneously, offering higher robustness and potentially higher throughput for compatible clients in the most frequently used 5 GHz frequency band, optimizing your Network performance with these 5 GHz Components.
