The Problem: Slow and Unreliable Connectivity in Industrial Environments?
In today's fast-paced industry, slow internet connections and unstable networks are a real productivity killer. Especially in remote areas or for mobile applications, the lack of reliability of conventional routers can lead to costly downtime and inefficient processes. You need a solution that is not only fast but also withstands extreme conditions and guarantees continuous connectivity.
The Solution: The Teltonika RUTX50 – Your 5G Powerhouse for Maximum Performance
The Teltonika RUTX50 is precisely the answer to these challenges. As a state-of-the-art 5G industrial router, it offers you not only breathtaking speeds of up to 3.3 Gbit/s but also unparalleled robustness and reliability. Thanks to Dual-SIM with Auto-Failover, it seamlessly switches between mobile networks to ensure a constant connection. This way, your critical applications always stay online, no matter where you are.
Impressive Details: Technology That Sets Standards
The RUTX50 is equipped with a powerful Quad-Core ARM Cortex A7 processor at 717 MHz, 256 MB RAM, and 256 MB Flash memory to effortlessly handle even demanding tasks. The WLAN 5 (802.11ac Wave 2) interface supports Dual-Band (2.4 GHz and 5 GHz) and MU-MIMO for efficient wireless communication at up to 867 Mbit/s. Five Gigabit Ethernet ports (one of which is configurable as WAN) and passive PoE support on the LAN1 port offer maximum flexibility for integration into existing networks. The robust aluminum casing with IP30 protection class and the wide operating temperature range of -40 °C to 75 °C make it the ideal companion for any industrial environment.
Your Advantage: Future-Proof Connectivity and Easy Management
With the Teltonika RUTX50, you invest in a future-proof Network solution that supports both 5G NSA and 5G SA architectures. The proven RutOS operating system offers advanced security features and a variety of industrial protocols, while compatibility with the Teltonika Remote Management System (RMS) enables easy remote management and monitoring of your device fleet. This gives you full control at all times, allowing you to focus on what matters most: the success of your business.
Technical Specifications
| Model: | Teltonika RUTX50 |
| Cellular Module: | 5G Sub-6GHz SA/NSA, 4G (LTE Cat 20), 3G |
| 5G Download Speed: | Up to 3.3 Gbit/s (4x4 MIMO) |
| 5G Upload Speed: | Up to 900 Mbit/s (2x2 MIMO) |
| LTE Download Speed: | Up to 2.0 Gbit/s (Cat 20) |
| LTE Upload Speed: | Up to 200 Mbit/s |
| SIM Slots: | 2 x Mini SIM (2FF), 1.8 V/3 V, Dual-SIM with Auto-Failover |
| WLAN Standard: | 802.11b/g/n/ac Wave 2 (WLAN 5), Dual-Band (2.4 GHz / 5 GHz), MU-MIMO |
| WLAN Data Rate: | Up to 867 Mbit/s |
| Ethernet Ports: | 5 x RJ45 10/100/1000 Mbit/s (1x WAN, 4x LAN, configurable) |
| CPU: | Quad-core ARM Cortex A7, 717 MHz |
| RAM: | 256 MB |
| Flash Memory: | 256 MB |
| GNSS: | GPS, GLONASS, BeiDou, Galileo, QZSS |
| Antenna Connectors: | 4x SMA (Cellular), 2x RP-SMA (WLAN), 1x SMA (GNSS) |
| Power Supply: | 9 – 50 VDC, 4-Pin Industrial DC Socket, passive PoE (LAN1) |
| Max. Power Consumption: | <18 W |
| Casing Material: | Aluminum |
| Dimensions (W x H x D): | 132 x 44.2 x 95.1 mm |
| Operating Temperature: | -40 °C to 75 °C |
| Protection Class: | IP30 |
| Operating System: | RutOS (based on OpenWrt) |
Scope of Delivery
| 1 x Teltonika RUTX50 5G Industrial Router |
| 1 x 18 W Power Supply |
| 4 x Mobile Antennas (SMA connector) |
| 2 x WLAN Antennas (RP-SMA connector, 1.5 m cable) |
| 1 x GNSS Antenna (SMA connector, 3 m cable) |
| 1 x Ethernet Cable (1.5 m) |
| 1 x SIM Adapter Kit |
| 1 x Quick Start Guide (QSG) |
Häufig gestellte Fragen (FAQ)
What speeds does the Teltonika RUTX50 achieve?
The Teltonika RUTX50 achieves impressive download speeds of up to 3.3 Gbit/s and upload speeds of up to 900 Mbit/s in the 5G Network. When using LTE Cat 20, download speeds of up to 2.0 Gbit/s are still possible.
Is the RUTX50 suitable for use in harsh environments?
Yes, the Teltonika RUTX50 is specifically designed for industrial applications. It features a robust aluminum casing with IP30 protection class and can operate in a wide temperature range from -40 °C to 75 °C.
Does the RUTX50 support Dual-SIM and what does that mean?
Absolutely! The RUTX50 is equipped with two Mini-SIM slots. The Dual-SIM function enables auto-failover, meaning that if the primary mobile Network fails, the router automatically switches to the second SIM card to ensure an uninterrupted connection.
Which Wi-Fi standards are supported by the Teltonika RUTX50?
The Teltonika RUTX50 supports the Wi-Fi 5 (802.11ac Wave 2) standard and is dual-band capable (2.4 GHz and 5 GHz). Thanks to MU-MIMO technology, it can efficiently transmit data to up to 150 clients simultaneously, with a maximum data rate of 867 Mbit/s.
Can the RUTX50 be managed remotely?
Yes, the Teltonika RUTX50 is fully compatible with the Teltonika Remote Management System (RMS). This allows you optimized remote management, monitoring, and configuration of your device fleet, no matter where you are.
