This compact, weatherproof WiFi omnidirectional antenna (also known as omni or rod antenna) is designed for the 2.4 GHz frequency band (WiFi standard) and supports all common WiFi standards within this frequency band (IEEE 802.11 b/g/n). The antenna has a gain of 5 dBi, making it suitable for illuminating small outdoor areas.
The antenna features a weatherproof straight RP-SMA connector with a sealing ring (see product images) and is intended for direct screw-on attachment to your WiFi devices. An external antenna port is required for this purpose.
Technical Data:
| Type of Antenna: | Omnidirectional WiFi Antenna |
| Gain: | 5dBi |
| Impedance: | 50 Ohm |
| Frequency: | 2400 - 2485 MHz (IEEE802.11 b/g/n) |
| VSWR: | max. 1.5 |
| Polarisation: | Vertical (Linear) |
| Beam width: | 360° Horizontal 40° Vertical |
| Connector: | RP-SMA female connector |
| Appliance: | Indoor / Outdoor |
| Dimensions: | 158mm x 13mm |
| Weight: | 25g |
| Color: | Grey |
| Operating Temperature: | -20° to 60° C |
| Storage Temperature: | -30 bis 75° C |
Scope of delivery
| 1 x 2.4 5dBi Outdoor Omnidirectional WiFi Antenna |
