RUTX14 is the fastest single modem LTE router in TELTONIKA portfolio with a possible total bandwith of 1200Mbps. 5 x Gigabit Ethernet ports, Wave-2 802.11ac Dual-Band Wi-Fi, Bluetooth LE, USB interfaces, dual SIM for advanced throughput and ultra-reliable connectivity. Equipped with advanced security features like multiple VPN's, firewall & cyber attack prevention. Combination of fast LTE CAT12 connectivity, wide range of physical interfaces, extensive RutOS functionality and great remote management capabilities make this device an excellent choice for primary or backup connectivity. The RUTX14 can be easily managed using the TELTONIKA RMS system.
The integrated CAT12 LTE modem of the TELTONIKA RUTX14 allow a constant 4G connection with transmission rates of up to 600 MBit down- and 50 MBit upload each in LTE / 4G mode (according to CAT12 standard) and 42 MBit down - and 5.76 MBit upload (according to DC-HSPA + standard) in 3G operation. The integrated load balancer allows the simultaneous use of both connections. A total capacity of 1200 MBit down and 100 MBit upload can be achieved. The SIM card slots can be equipped with a SIM card from any provider. For example, you can use two SIM cards from different providers and thus avoid connection failures due to insufficient network coverage of one provider.
With the integrated high-speed 802.11ac / Wave2 dual-band Wi-Fi access point, data rates of up to 867 Mbit are available. The RUTX14 also has an integrated 5-port Gigabit Ethernet switch.
The user-friendly web interface allows all users to comfortably configure the router. The RUTX14 can also be managed using the TELTONIKA RMS system.
The rugged aluminum housing, solid engineering and the firmware ensure consistent performance and durability of TELTONIKA RUTX14.
Technical Data:
| Manufacturer / Model: |
TELTONIKA / RUTX14 |
| Modes: |
Router, NAT Router, Bridge, PPPoE Client |
| Processor: |
Quad-core ARM Cortex A7, 717MHz |
| Memory: |
256MB, DDR3 |
| FLASH memory: |
256MB SPI Flash |
| Integrated LTE Modems: |
1 |
| Frequency: |
LTE FDD B1, B3, B5, B7, B8, B20, B28, B32
LTE TDD: B38, B40, B41
3G: B1, B3, B5, B8 |
| Bandwidth 4G: |
Download: 600Mbps (CAT12)
Upload: 50 Mbps |
| Bandwidth 3G: |
Download: 42Mbps
Upload: 5.76Mbps |
| 4G/3G Antenna: |
4 x 3dBi Omni Antenna |
| GPS: |
GPS, GLONASS, BeiDou, Galileo and QZSS |
| WLAN: |
IEEE 802.11b (11 Mbps)
IEEE 802.11g (54 Mbps)
IEEE 802.11n (300 Mbps)
IEEE 802.11ac (867 Mbps) |
| Security: |
WPA3-EAP, WPA3-SAE, WPA2-Enterprise-PEAP, WPA2-PSK, WEP; AES-CCMP, TKIP, Auto Cipher modes, client separation |
| WiFi Antenna: |
2 x Dualband Omni Antenna (RP-SMA) |
| Features: |
NAT, DHCP Server/Client, Virtual Server, Port Forwarding, QOS, DMZ Host, Firewall mit IP-, MAC und Domain-Filter, OpenVPN, PPTP, L2TP, IPsec, VRRP, GRE Tunnel, SMS Control, DynDNS, RMS support, Input Triggers, Samba Share, Load Balancer |
| Interfaces: |
1 x USB 2.0 (A) |
| SIM Interface: |
2 x Standard Mini-SIM Slot |
| WAN Interface: |
1 x 10/100/1000 Mbps WAN Port |
| LAN Interface: |
4 x 10/100/1000 Mbps RJ45 Ports (Auto MDI-X, Auto-Negotiation) |
| Power Supply: |
9-50V |
| Power consumption: |
max. 22W |
| Appliance: |
Indoor |
| E-mark certification: |
Yes |
| Dimensions: |
13.2 x 9.5 x 4.4 cm |
| Casing: |
Aluminium |
| Weight: |
540g |
| Operating temperature: |
-40°C to 70°C |
| Humidity: |
10% ~ 90% non condensing |
Scope of delivery:
| 1 x TELTONIKA RUTX14 4G Router |
| 4 x 3dBi 3G/4G Antenna (SMA) |
| 2 x Dualband WiFi Antenna (RP-SMA) |
| 1 x Bluetooth Antenna (RP-SMA) |
| 1 x GPS Antenne (SMA) |
| 1 x 1m CAT5e Ethernet cable |
| 1 x 12V/1.5A Power Supply with terminal block |
| 1 x Manual |
