The Stable Power Source for Your Teltonika Network
The Teltonika PR3PDNP0 is more than just a Power Supply – it is the foundation for a stable and fail-safe Network. If you operate Teltonika Routers or Gateways in a professional environment such as a control cabinet or an industrial plant, you need a Power Supply you can blindly rely on. This Power Supply was developed precisely for this purpose. It precisely converts the incoming AC voltage into clean 12V DC voltage and ensures that your devices always receive the energy they need for maximum performance. It is the perfect addition for anyone who wants to professionally integrate their Teltonika 4G / 5G Routers.
Compact Design, Great Reliability: The 20W DIN-Rail Power Supply
Space is often at a premium in control cabinets. With a width of only 22.5 mm, the PR3PDNP0 is extremely narrow and can be seamlessly integrated into existing or new installations on a 35mm DIN rail. Despite its compact dimensions, it is a real workhorse. It consistently delivers 20 watts of power, making it the ideal, reliable 12V DIN-Rail Power Supply for a wide range of Teltonika devices, from the compact TRB gateway to the powerful RUTX router.
Globally Applicable and Maximally Compatible
Whether your project is realized in Europe (230V) or North America (115V) – thanks to the wide-range input of 85V to 264V AC, the PR3PDNP0 automatically adapts to the local power grid. This flexibility makes it the first choice for internationally active companies and system integrators. The compatibility list is impressive and covers almost the entire Teltonika portfolio. You can be sure that this power supply, as one of the most important Teltonika Accessories, harmonizes perfectly with your hardware.
Integrated Protection Mechanisms for Your Valuable Hardware
A power outage or voltage spike can damage expensive hardware. The PR3PDNP0 features essential protection circuits to prevent exactly that. Overload protection with automatic recovery switches off the output in case of excessive current draw and attempts a restart independently. Overvoltage protection immediately shuts down in case of dangerous voltage spikes, thus protecting the sensitive electronics of your connected Routers and Switches. An investment in this DIN-Rail Power Supply for Teltonika Routers is insurance for your entire Network.
Strengths & Notes at a Glance
- Pro: Specifically developed for the Teltonika ecosystem and tested for maximum compatibility and reliability.
- Pro: Worldwide use possible due to wide-range input voltage without manual switching.
- Pro: Very slim design (22.5 mm) for space-saving mounting on standard DIN rails.
- Pro: Important protection circuits against overload and overvoltage are already integrated.
- Note: The operating temperature range (-10°C to +50°C) is designed for standard applications, not for extreme cold or heat.
- Note: The efficiency of 80% is solid but generates more waste heat than high-end power supplies with over 90% efficiency.
Specifications & Features
| Manufacturer: | Teltonika |
| Model: | PR3PDNP0 |
| EAN: | 4779051841059 |
| Product Type: | DIN-Rail Power Supply |
| Mounting: | 35 mm DIN-Rail |
| Input Voltage Range (AC): | 85 - 264 V AC |
| Nominal Input Voltage (AC): | 100 - 240 V AC |
| Input Frequency: | 47 - 63 Hz |
| Efficiency: | 80 % |
| Inrush Current (115V AC): | 20 A (Cold Start) |
| Inrush Current (230V AC): | 40 A (Cold Start) |
| Output Power: | 20 W |
| Output Voltage (DC): | 12 V DC |
| Output Current: | 0 - 1.67 A |
| Ripple & Noise: | 120 mVp-p |
| Line Regulation: | ±1 % |
| Load Regulation: | ±1 % |
| Overload Protection: | 105% - 160% Rated Power, automatic recovery |
| Overvoltage Protection: | 120% - 140% Rated Voltage, shutdown (restart required) |
| Operating Temperature: | -10 °C to +50 °C |
| Dielectric Strength (I/P - O/P): | 1.5 kV |
| Isolation Resistance: | 1000 MΩ at 500 VDC |
| Safety Standard: | EN 60950-1 |
| EMC Standards: | EN 55022, EN 61000-3-2, EN 61000-3-3, EN 55024 |
| Dimensions (W x H x D): | 22.5 x 90 x 100 mm |
| Weight: | approx. 190 g |
Scope of Delivery
| 1 x Teltonika PR3PDNP0 DIN-Rail Power Supply |
Frequently Asked Questions (FAQ)
Is the Teltonika PR3PDNP0 a router?
No, the PR3PDNP0 is not a router. It is purely a power supply, specifically designed to power Teltonika routers, switches, and gateways with 12V DC via a DIN rail in a control cabinet.
Can I also use this power supply for devices from other manufacturers?
Technically yes, as long as the device to be powered requires a 12V DC input voltage and the power consumption does not exceed 20 watts (or 1.67 amperes). However, its use is primarily recommended for compatible Teltonika devices to ensure full system stability.
What does 'automatic recovery' mean for overload protection?
If a connected device draws too much current (overload), the power supply shuts down the output to protect itself. After a short pause, it automatically attempts to restore power. If the overload persists, this cycle repeats.
Do I need additional Accessories for mounting?
No, the power supply has an integrated clip for direct mounting on a standard 35mm DIN rail. No separate mounting kit is required.
For which application areas is the PR3PDNP0 ideal?
It is ideal for industrial automation, IoT applications, video surveillance (CCTV), and telecommunication setups where Teltonika devices need to be centrally mounted in a control cabinet or distribution box and supplied with a stable voltage.
How is the power supply connected to the mains?
Connection is made via screw terminals for the phase, neutral, and ground conductors of the 100-240V AC mains. Similarly, the 12V DC output is provided via separate screw terminals.
