The Shelly Pro 3 is a professional, intelligent 3-phase relay switch that was specially developed for DIN rail mounting in the distribution box. It is the perfect solution for your smart home or for commercial buildings, as it enables the control of three independent channels with up to 40A per channel. The heart of the Pro 3 is the new Gen3 platform, which, thanks to the more powerful ESP-Shelly-C38F processor, enables a response time of up to 30% faster than with previous models.
With the Shelly Pro 3, you have full control over your devices. It offers you the option of measuring and logging the energy consumption of each channel separately. This makes it easy to identify energy guzzlers and optimize your electricity consumption. Thanks to the integrated WiFi, LAN, and Bluetooth connectivity, it can be seamlessly integrated into your existing network and conveniently controlled via the Shelly Smart Control App, cloud platforms, or voice assistants. The extensive MQTT support and webhook functionality make it the ideal choice for professional system integrators and developers.
Technical Data:
| Model: | Shelly Pro 3 |
| Mounting: | DIN rail |
| Size (HxWxD): | 94x19x69 ±0.5 mm |
| Weight: | approx. 70g |
| Conductor cross-section: | 0.2 to 2.5 mm² / 24 to 14 AWG |
| Stripping length of conductor: | 6 to 7 mm |
| Housing material: | Plastic |
| Color: | Black |
| Ambient temperature: | -20 °C to 40 °C |
| Humidity: | 30 % to 70 % RH |
| Max. altitude: | 2000 m |
| Power supply: | 110-240 VAC, 50/60 Hz |
| Self-consumption: | < 3 W |
| Power measurement: | No |
| Max. switching voltage (AC): | 240 V |
| Max. switching current (AC): | 40 A |
| WiFi protocol: | 802.11 b/g/n |
| WiFi frequency band: | 2.4 GHz |
| WiFi radio power: | < 20 dBm |
| Bluetooth protocol: | 4.2 |
| Bluetooth frequency band: | 2.4 GHz |
| Processor: | ESP-Shelly-C38F |
| Flash: | 8 MB |
Scope of Delivery:
| 1x Shelly Pro 3 |
| 1x Quick start guide |
