Your Upgrade to Internet Light Speed
The Zyxel FWA510 is more than just a router – it's your declaration of independence from slow landline connections. Whether in the home office, a holiday apartment, or business premises without fiber optics: This WiFi Router with SIM card gets the maximum out of the 5G and 4G Network. Thanks to support for Standalone (SA) and Non-Standalone (NSA) 5G, you are ready for the future and can already benefit from breathtaking speeds today. 8K streaming, lag-free online gaming, and video conferences without stuttering become the new normal.
A High-Performance Network for Your Home
Inside the FWA510, state-of-the-art technology works to accelerate not only internet access but your entire Network. Wi-Fi 6 (AX3600) ensures higher efficiency and lower latency, even when dozens of devices are online simultaneously. The two 2.5-Gigabit LAN ports break the Gigabit sound barrier and provide the perfect foundation for data-intensive applications. Whether you operate a local media center or connect a professional workstation – this router delivers the necessary performance without bottlenecks.
Professional-Level Control and Flexibility
What sets the FWA510 apart from many other devices is its integration into the Zyxel Nebula Cloud. This powerful tool allows you to remotely manage your router as if you were on-site. Change configurations, monitor data traffic, or perform firmware updates – all conveniently via a central dashboard. This makes the FWA510 an ideal Internet Backup Solution for businesses or for tech-savvy users who want full control over their Network.
Maximum Reliability through Smart Features
A good connection is a stable connection. The Zyxel FWA510 provides you with all the tools for this. Use the dual-WAN failover function to ensure an uninterrupted internet connection. Should your landline fail, 5G access seamlessly takes over. Do you live in an area with a weak mobile signal? No problem. Via the four external TS9 connectors, you can specifically improve reception with suitable 5G Antennas / Outdoor Antennas and thus exploit the full potential of your connection.
Strengths & Notes at a Glance
- Pro: Future-proof connectivity with 5G (SA/NSA) and Wi-Fi 6 (AX3600).
- Pro: Two ultra-fast 2.5-Gigabit Ethernet ports for maximum wired performance.
- Pro: Professional remote management and monitoring via the Zyxel Nebula Cloud platform.
- Pro: Four TS9 connectors for optional connection of external Antennas for better reception.
- Pro: Dual-WAN failover function for maximum reliability.
- Note: Compared to other routers, some advanced software features, such as dedicated parental control on the firmware, are missing.
- Note: The Wi-Fi channel width in the 5 GHz band is limited to 80 MHz, which limits the maximum speed for individual clients.
Specifications & Features
| Manufacturer: | Zyxel |
| Model: | FWA510 |
| EAN: | 4718937631230 |
| Model Number: | FWA-510-EU0102F |
| Product Classification: | 4G / 5G Routers (Indoor) |
| CPU: | MediaTek T750, Quad-Core Arm CPU |
| 5G Standard: | 3GPP Release 15, NSA & SA Modes |
| 5G NR Frequency Bands: | n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n77, n78 |
| 5G Data Rate (max.): | 4.67 Gbit/s Download / 2.5 Gbit/s Upload |
| 5G Antenna Technology: | DL 4x4 MIMO |
| 4G Standard: | 3GPP UE Category 19 |
| 4G Frequency Bands: | B1, B3, B5, B7, B8, B20, B28, B32, B38, B40, B41, B42 |
| 4G Data Rate (max.): | 1.6 Gbit/s Download / 200 Mbit/s Upload |
| Wi-Fi Standard: | IEEE 802.11 b/g/n/a/ac/ax (Wi-Fi 6) |
| Wi-Fi Speed: | AX3600 (up to 2.4 Gbit/s on 5 GHz + 1.2 Gbit/s on 2.4 GHz) |
| Wi-Fi Security: | WPA2-Personal, WPA2+WPA3, WPA3 |
| LAN Ports: | 2 x 100/1000/2500 Mbps Ethernet RJ-45 |
| WAN Function: | LAN Port 2 configurable as WAN Port |
| SIM Card Slot: | 1 x Micro-SIM (3FF) |
| External Antenna Connectors: | 4 x TS9 for 5G/4G |
| USB Port: | 1 x USB 3.0 Host Port |
| Management: | Web Interface, Zyxel Nebula Cloud, Zyxel Air App (iOS/Android) |
| Operating Modes: | Router Mode, Bridge Mode |
| Dimensions (WxDxH): | 132.5 x 134 x 230 mm |
| Weight: | 1006 g |
| Operating Temperature: | 0 °C to 40 °C |
Scope of Delivery
| 1 x Zyxel FWA510 5G Router |
| 1 x Power Adapter |
| 1 x Ethernet Cable |
| 1 x Quick Start Guide |
Frequently Asked Questions (FAQ)
Can I use the Zyxel FWA510 as a replacement for my DSL or fiber optic connection?
Yes, the FWA510 is designed exactly for that. It uses the 5G or 4G mobile network to provide a fast broadband internet connection. It is ideal for locations without a fast fixed-line connection or as a fail-safe backup solution.
What SIM card size does the Zyxel FWA510 require?
The router uses a SIM card slot for a Micro-SIM (3FF). If you have a Nano-SIM card, you will need a suitable adapter.
Is it possible to connect external Antennas to improve 5G reception?
Yes, that is one of the main advantages of the device. The FWA510 has four TS9 connectors to which external 5G/4G antennas can be connected to improve signal strength and quality in areas with poor reception.
Does the router support management via a cloud platform?
Yes, the FWA510 is fully integrated into the Zyxel Nebula Cloud. This enables centralized configuration, monitoring, and remote management of the router, which is particularly useful for business users.
Does the Zyxel FWA510 offer a failover function?
Yes, the router features a Dual-WAN failover function. You can use a mobile connection and a wired internet connection (via the configurable 2.5G WAN port) simultaneously. If one connection fails, the router automatically switches to the other.
Which WiFi security standards is the FWA510 compatible with?
The router supports modern security standards, including WPA2 and the latest standard WPA3. This ensures high security for your wireless network.
