Maximum Reliability: Your Rock in the Digital Surf
The Teltonika RUTX09 is not just a router – it's an insurance for your connectivity. Developed for environments where failure is not an option, it is housed in a robust full aluminum casing that protects it from physical impacts. With an impressive operating temperature range of -40 °C to 75 °C and a flexible input voltage range of 9 to 50 VDC, it works reliably in control cabinets, vehicles, or remote locations. If you are looking for a Failover Router for critical applications that simply always works, the RUTX09 is the answer.
Uninterrupted Online: The Dual-SIM Failover Strategy
The core of its reliability is the intelligent Dual-SIM functionality. Equip the RUTX09 with SIM cards from two different providers and define precise rules for automatic switching. Whether due to a weak signal, reaching a data or SMS limit, roaming, or a complete Network outage – the router seamlessly switches to the backup connection. This ensures that your application, be it an IP camera, an industrial system, or a POS system, remains continuously online and accessible.
Concentrated Power for Professional Networks
Under the hood, a Quad-Core CPU provides plenty of processing power. In combination with the highly flexible RutOS, which is based on OpenWrt, all doors are open to you. Configure complex static and dynamic routing protocols (BGP, OSPF), build secure VPN tunnels with OpenVPN or IPsec, and protect your Network with an advanced firewall. The four Gigabit Ethernet ports ensure that the full mobile performance also reaches your LAN. This router is a real workhorse for Network professionals and belongs to the category of the best Teltonika 4G / 5G Routers.
The Specialist for Vehicles and M2M Applications
Thanks to its specific features, the RUTX09 is the perfect reliable 4G Router for vehicles and fleet management. The wide input voltage range easily handles the voltage fluctuations of a vehicle's electrical system. The integrated GNSS module supports GPS, GLONASS, BeiDou, and Galileo and provides precise location data for tracking applications. In combination with suitable Vehicle Antennas - 4G, 5G, WiFi, it becomes the ultimate connectivity hub for mobile deployments.
Strengths & Notes at a Glance
- Pro: Extremely robust design with aluminum casing and wide temperature range for the most demanding environments.
- Pro: Superior reliability through Dual-SIM functionality with automatic failover scenarios.
- Pro: Powerful hardware and the flexible RutOS enable complex network configurations and high data throughputs.
- Pro: Excellent remote maintenance options via the Teltonika RMS and numerous industrial protocols.
- Note: The device does not have integrated WiFi. An external Access Point must be connected for a wireless network.
- Note: The extensive configuration options require sound network knowledge to exploit the full potential.
Specifications & Features
| Manufacturer: | Teltonika |
| Model: | RUTX09 |
| EAN: | 4779027312460 |
| MPN: | RUTX09000000 / RUTX09 |
| Product Classification: | Industrial Cellular Router |
| Cellular Module: | 4G Cat 6 / 3G |
| 4G Speed: | Up to 300 Mbps Downlink, up to 50 Mbps Uplink |
| 3G Speed: | Up to 42 Mbps (DC-HSDPA) |
| Carrier Aggregation: | Yes, 2CA (2-Carrier Aggregation) |
| SIM Slots: | 2 x external SIM holders (Mini SIM - 2FF) |
| Dual-SIM Modes: | Auto-Failover, Backup-WAN, switching on weak signal, data limit, roaming, and more. |
| 4G-FDD Bands: | B1, B3, B5, B7, B8, B20, B28, B32 (Rx only) |
| 4G-TDD Bands: | B38, B40, B41 |
| 3G/WCDMA Bands: | B1, B5, B8 |
| CPU: | Quad-Core ARM Cortex A7, 717 MHz |
| RAM: | 256 MB DDR3 |
| Flash Memory: | 256 MB |
| Operating System: | RutOS (OpenWrt-based) |
| Ethernet Ports: | 4 x 10/100/1000 Mbps (1x WAN, 3x LAN) |
| USB Port: | 1 x USB A |
| Digital I/O: | 1 x Digital Input, 1 x Digital Open-Collector Output |
| Antenna Connectors: | 2 x SMA (4G), 1 x SMA (GNSS) |
| Input Voltage: | 9 – 50 VDC (4-Pin DC socket) |
| Passive PoE: | Yes, via LAN1 (Mode B, 9-30 VDC, not 802.3af/at compatible) |
| Power Consumption: | < 11 W (maximum) |
| Casing: | Full aluminum |
| Dimensions: | 115 x 95 x 44 mm |
| Weight: | 456 g |
| Protection Class: | IP30 |
| Operating Temperature: | -40 °C to 75 °C |
| Mounting: | DIN rail, flat surface |
| VPN Protocols: | OpenVPN, IPsec, GRE, L2TP, PPTP, Stunnel |
| GNSS Systems: | GPS, GLONASS, BeiDou, Galileo, QZSS |
| Management: | Web-UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS |
| Certifications: | CE/RED, EAC, RoHS, REACH, UL/CSA |
Scope of Delivery
| 1 x Teltonika RUTX09 Router |
| 2 x 4G Antennas (swivel, SMA) |
| 1 x GNSS Antenna (self-adhesive, SMA, 3m cable) |
| 1 x 4-Pin Power Supply |
| 1 x Ethernet Cable (1.5 m) |
| 1 x SIM adapter kit |
| 1 x Quick Start Guide |
Frequently Asked Questions (FAQ)
Can the Teltonika RUTX09 be used as a regular home router?
Although technically possible, the RUTX09 is oversized and not cost-effective for home use. It lacks important home features such as integrated WiFi Routers and a simplified user interface. It is specifically designed for industrial applications requiring high reliability and robustness.
What do "4G Cat 6" and "Carrier Aggregation" mean?
4G Cat 6 is a mobile communication standard that enables download speeds of up to 300 Mbps. This is achieved through "Carrier Aggregation" (CA), a technology that bundles multiple frequency bands to achieve higher data throughput and a more stable connection.
Do I need special SIM cards for the RUTX09?
No, the router uses standard Mini-SIM cards (2FF format). However, it is recommended to use M2M or IoT-specific tariffs, as these are often optimized for data-only traffic and are better supported by providers for use in routers.
How is the RUTX09 powered?
The router is powered by default via an included 4-pin Power Supply (9-50V DC). Alternatively, it can be powered via Passive PoE Injectors / Power Supplies on the LAN1 port, allowing for flexible installation. However, it is crucial not to use standard PoE (802.3af/at) as this can damage the device.
Is the RUTX09 suitable for use in vehicles?
Yes, absolutely. The wide input voltage range (9-50V) tolerates voltage fluctuations in vehicle electrical systems, the robust housing withstands vibrations, and the integrated GNSS (GPS) module enables location tracking, making it ideal for fleet management and logistics applications.
What is the difference between the RUTX09 and the RUTX11?
The main difference is that the RUTX11 additionally features an integrated dual-band WiFi module (WiFi 5, 802.11ac) and Bluetooth LE. The RUTX09 has no WiFi or Bluetooth and is a pure cellular-to-Ethernet solution.
