Your Network Powerhouse for Every Challenge
Are you looking for a robust cellular router that won't give up even under extreme conditions? The Teltonika RUT951 PoE+ is exactly what you need. This industrial 4G router was specifically developed to guarantee you a reliable and uninterrupted connection in demanding IoT and M2M Communication scenarios. Imagine operating a surveillance system in a remote area or controlling machines in Industrial Automation – the RUT951 PoE+ is your rock in the surf. It supports 4G Cat 4, offering download speeds of up to 150 Mbps and upload speeds of up to 50 Mbps, naturally backward compatible with 3G and 2G networks.
Power Supply and Connectivity Reimagined: PoE+ and eSIM
No more cable clutter and complicated installations! The RUT951 PoE+ revolutionizes your infrastructure thanks to its clever PoE+ Router functionality. You can conveniently power the router itself via the LAN1 port with Power over Ethernet. The best part: It simultaneously acts as PoE Injectors / Power Supplies for your end devices. Via the three PoE-Out ports (LAN2, LAN3, WAN), it powers other PoE-capable devices such as IP Cameras or WiFi Access Points with up to 30W per port and an impressive total budget of 90W. This saves you separate power cables and power supplies. But that's not all: For maximum flexibility in cellular connectivity, the RUT951 PoE+ offers not only two physical SIM card slots but also eSIM Router support with up to 7 eSIM profiles. This allows you to quickly switch providers, ideal for cross-border deployments or changing Network coverages.
Always Connected: Reliability through Dual-SIM and WAN Failover
Interruptions are not an option. The Teltonika RUT951 PoE+ ensures that your connection never breaks. Thanks to the integrated Dual SIM Router function and extended eSIM Router support with automatic WAN Failover, the router seamlessly switches to an alternative connection in case of a primary cellular Network failure or when a data limit is reached. This means continuous connectivity for critical applications. Whether you are providing a WiFi Hotspot for your employees or transmitting important sensor data – your data flows reliably. The heart of the router, the Linux-based RutOS, also offers advanced customization options, automation functions, and the highest security standards. You can even create custom firmware and web UI versions with your own logos and colors – a huge advantage for system integrators and Managed Service Providers.
Easy Management, Maximum Control – Anywhere
With the Teltonika RUT951 PoE+, you always maintain full control over your Network. The intuitive RutOS allows for easy configuration directly on the device. For remote management and monitoring, the router is fully compatible with Teltonika's Remote Management System (RMS). With RMS, you can centrally monitor, configure, and maintain your device fleet – from anywhere in the world. This saves you valuable time and significantly reduces maintenance efforts. This Ethernet Router is not only robust and flexible but also a true VPN Router, supporting common protocols such as OpenVPN, IPsec, GRE, L2TPv3, and L2TP to ensure secure connections. You can also easily use Ethernet Cables for your local connections.
Strengths & Notes at a Glance
- Pro: High reliability and failover capability through Dual-SIM, eSIM, and WAN-Failover for continuous network connectivity.
- Pro: Flexible power supply and device integration thanks to integrated PoE+ functionality (PoE-In and 3x PoE-Out) for IP Cameras or WiFi Access Points.
- Pro: Industrial robustness and efficient remote management via the Teltonika Remote Management System (RMS) for demanding IoT environments.
- Note: The Ethernet ports are limited to 10/100 Mbps, which can be limiting for very high data throughputs.
- Note: The router uses the Wi-Fi 4 (802.11 b/g/n) standard, which offers lower speeds compared to newer WLAN standards.
Specifications & Features
| Manufacturer: | Teltonika |
| Model: | RUT951 PoE+ |
| Product Type: | Industrial 4G 4G Router |
| EAN: | 4779051843701 |
| Cellular Standard: | 4G (4G Cat 4), 3G (UMTS/HSPA+), 2G (GPRS/EDGE) |
| 4G Download/Upload: | Up to 150 Mbit/s / 50 Mbit/s |
| SIM Slots: | 2 x Mini-SIM (2FF) with external holders |
| eSIM Support: | Yes, up to 7 eSIM profiles |
| WiFi Standard: | IEEE 802.11b/g/n (WLAN 4) |
| WiFi Frequency: | 2.4 GHz |
| WiFi Speed: | Up to 300 Mbit/s |
| Ethernet Ports: | 4 x RJ45 10/100 Mbit/s (1x WAN/LAN, 3x LAN) |
| PoE-In: | Yes, 802.3at (30W Input) |
| PoE-Out: | 3 x 802.3af/at (30W per port, 90W total budget) |
| CPU: | Mediatek MIPS 24Kc, 580 MHz |
| RAM: | 128 MB |
| Flash Memory: | 16 MB |
| Operating System: | RutOS |
| Operating Temperature: | -40 °C to +75 °C |
| Casing: | Aluminum with plastic panels, IP30 |
| Dimensions (WxHxD): | 110 x 50 x 100 mm |
| Mounting Options: | DIN rail, wall mount, desk |
Scope of Delivery
| 1 x Teltonika RUT951 PoE+ Router |
| 1 x 9W Power Supply |
| 2 x 4G Antennas (SMA connector) |
| 2 x WiFi Antennas (RP-SMA connector) |
| 1 x Ethernet Cable (1.5 m) |
| 1 x SIM Adapter Kit |
| 1 x Quick Start Guide (QSG) |
Frequently Asked Questions (FAQ)
Which mobile communication standards does the Teltonika RUT951 PoE+ support?
Your Teltonika RUT951 PoE+ supports 4G LTE (Category 4) with download speeds of up to 150 Mbps and upload speeds of up to 50 Mbps, as well as backward compatibility with 3G and 2G networks.
How does the PoE+ function of the RUT951 PoE+ work?
Your router can be powered via the LAN1 port using PoE+ (PoE-In). Additionally, it features three PoE-Out ports (LAN2, LAN3, WAN) that can power other PoE-enabled devices according to the IEEE 802.3af/at standard, with a maximum total budget of 90 W and 30 W per port.
Does the Teltonika RUT951 PoE+ offer a solution for uninterrupted connectivity?
Yes, your router is equipped with Dual-SIM and eSIM functionality, as well as automatic WAN failover. This allows for automatic switching to an available backup connection in case of signal loss or data limit, to minimize network outages.
Which management options does the Teltonika RUT951 PoE+ offer?
Your router is powered by RutOS and is fully compatible with the Teltonika Remote Management System (RMS), which enables secure remote management, monitoring, and troubleshooting.
For which application areas is the Teltonika RUT951 PoE+ particularly suitable?
Your RUT951 PoE+ is ideal for various IoT applications, including Smart City monitoring, fleet management, digital signage, manufacturing automation, retail kiosks, and remote monitoring in industrial and commercial environments.
Does the router support WLAN and hotspot functions?
Yes, your Teltonika RUT951 PoE+ supports Wi-Fi 4 (802.11 b/g/n) and offers hotspot functionality with customizable captive portals and authentication options.
