Your Power Package for Industrial IoT Applications
The Teltonika TRB140 is more than just an 4G / 5G Router – it is a specially developed IoT Gateway that offers you maximum performance in the smallest space. If you need a reliable and secure connection for your M2M applications, this device is the perfect choice. It was designed for industrial use and can withstand harsh conditions. Whether it's remote monitoring, asset tracking, or industrial automation – the TRB140 provides the necessary connectivity.
Fast and Stable Data Connection with 4G Cat 4
Forget slow connections! With the Teltonika TRB140, you benefit from the speed and stability of 4G Cat 4. This means for you: downloads of up to 150 Mbps and uploads of up to 50 Mbps. This ensures that your data always arrives on time and reliably. The integrated SIM card holder allows you flexible use of various mobile Network providers to always ensure the best coverage.
Easy Integration and Flexible Configuration
The TRB140 scores with its user-friendliness. Thanks to the powerful RutOS, a Linux-based operating system, you can flexibly adapt the device to your specific requirements. The intuitive web interface makes setup a breeze, while extensive VPN functions and firewall options provide the necessary security. The single Ethernet port simplifies connection to your existing infrastructure or directly to an end device.
Robustness and Reliability for Demanding Environments
Industrial environments place high demands on hardware. The Teltonika TRB140 is perfectly equipped for this. Its compact and robust design reliably protects the internal technology from external influences. With a wide operating temperature range and stable power supply, it is designed for continuous operation and minimizes downtime. Rely on a device that performs even under extreme conditions.
Strengths & Notes at a Glance
- Pro: Extremely compact design, ideal for confined spaces.
- Pro: Fast and reliable 4G Cat 4 connectivity.
- Pro: Robust metal housing for industrial applications.
- Pro: Powerful RutOS with many configuration options.
- Pro: Easy installation and maintenance.
- Note: Only one Ethernet port, expansion may be necessary for more complex networks.
- Note: No integrated WLAN function, focus on mobile communication and Ethernet.
Specifications & Features
| Manufacturer: | Teltonika |
| Model: | TRB140 |
| Product Type: | IoT Gateway |
| Mobile: | 4G Cat 4 (up to 150 Mbps DL / 50 Mbps UL) |
| Frequency Bands: | EMEA/APAC/LATAM (B1, B3, B5, B7, B8, B20, B28, B38, B40, B41) |
| SIM Slot: | 1 x Mini SIM (2FF) |
| Antenna Connectors: | 1 x SMA for 4G |
| Ethernet: | 1 x 10/100 Mbps RJ45 Port |
| Connections: | 1 x 4-Pin Power Input, 1 x USB (Service) |
| Operating System: | RutOS (Linux-based) |
| Processor: | ARM Cortex-A7 1.2 GHz |
| RAM: | 128 MB DDR3 |
| Flash Memory: | 512 MB SPI Flash |
| Voltage Range: | 9-30 VDC |
| Power Consumption: | Max. 5 W |
| Operating Temperature: | -40 °C to 75 °C |
| Housing Material: | Aluminum |
| Dimensions: | 60 x 70 x 30 mm |
| Mounting: | DIN Rail (optional adapter) |
Scope of Delivery
| 1 x Teltonika TRB140 IoT Gateway |
| 1 x 1.5 m Ethernet Cable |
| 1 x 4G Antenna (Magnetic Mount, SMA Connector) |
| 1 x Power Adapter (EU) |
| 1 x QSG (Quick Start Guide) |
Frequently Asked Questions (FAQ)
What is the Teltonika TRB140?
The Teltonika TRB140 is a compact and powerful LTE Cat 4 IoT gateway, specifically designed for industrial applications requiring reliable and secure connectivity.
What connectivity options does the TRB140 offer?
The TRB140 offers LTE Cat 4 connectivity for fast mobile data transmission and features an Ethernet port as well as digital inputs and outputs for integrating various devices and sensors.
For which applications is the TRB140 IoT gateway suitable?
The TRB140 IoT gateway is ideal for applications such as remote monitoring, industrial automation, Smart City solutions, asset tracking, and M2M communication in critical infrastructures.
Is the Teltonika TRB140 easy to install?
Yes, the TRB140 is designed for quick and straightforward installation thanks to its compact design, easy DIN rail mounting, and intuitive web interface.
What security features does the TRB140 have?
The TRB140 features robust security functions such as VPN (OpenVPN, IPsec, PPTP, L2TP), firewall, and access control to ensure secure data transmission and Network protection.
Can the TRB140 be used in harsh environments?
Absolutely. The TRB140 is designed for use in demanding industrial environments and offers a wide operating temperature range as well as a robust construction.
Homepage: https://teltonika-iot-group.com/
