Maximum Performance for Your 5G Network
No more slow connections and unstable internet! The Poynting XPOL-1-5G PLUS v3 (A-XPOL-0001-V3-41) is the ultimate 5G Antennas / Outdoor Antennas to unleash the full potential of your 4G / 5G Routers. Imagine your data highway not only getting more lanes but also smarter traffic management. That's exactly what the integrated 4x4 MIMO Antenna does: it quadruples the transmission paths, leading to massively increased stability and speed. Especially in urban areas, where signals are scattered by reflections from buildings, this Omni-Directional Antennas actively utilizes these effects to guarantee you consistent coverage without you having to painstakingly align it.
Stability and Speed, Where You Need Them
No matter if you live in the city or in the countryside – the Poynting XPOL-1-5G PLUS v3 provides you with reliable broadband connectivity. Its Ultra-Wideband Antenna covers an impressive frequency range from 410 to 6000 MHz. This means you are not only well-equipped for current 2G, 3G, 4G, and 5G networks, but also for future technologies up to 6 GHz. With a peak gain of 7 dBi at lower frequencies, it is particularly predestined for rural areas or fringe areas of Network coverage, where it significantly improves the range of your cellular router. Experience Fixed Wireless Access (FWA) in a new dimension, be it for your Home & Office 5G.
Robust, Flexible, Future-Proof
The Poynting XPOL-1-5G PLUS v3 is not only a high-performer but also a true outdoor talent. Its IP65 weather protection housing is robust, dustproof, and even vandal-proof. This makes it the ideal choice for permanent outdoor use, without you having to worry about wind and weather. And the installation? Child's play! Thanks to the flexible mounting options – including Accessories for wall, pole, and window mounting (using suction cups) – you will always find the optimal place. The included Antenna Mounting Accessories enable quick and easy setup.
Your Connection, Always Reliable
Imagine your internet never going down. The Poynting XPOL-1-5G PLUS v3 can serve as reliable backup connectivity if your primary fiber optic or Starlink connection fails. It bridges outages and ensures continuous internet access. Its carefully developed omnidirectional radiation patterns ensure consistent coverage in urban, suburban, and commercial environments. This is particularly advantageous when a direct line of sight to the base station is difficult or you want to benefit from multipath propagation. With this antenna, you have a reliable connection that won't let you down.
Strengths & Notes at a Glance
- Pro: Ultra-wideband coverage (410-6000 MHz) and future-proofing for 2G, 3G, 4G, and 5G up to 6 GHz.
- Pro: High data throughput through 4x4 MIMO and cross-polarized elements for improved signal reliability.
- Pro: Robust IP65 weather protection design and vandal-proof housing, ideal for harsh outdoor environments.
- Pro: Improved performance in rural areas thanks to higher gain at lower frequencies (410-960 MHz).
- Pro: Consistent coverage in complex environments through optimized omnidirectional radiation patterns.
- Note: Omnidirectionality may be less efficient in extremely remote areas with very weak signals than a highly directional antenna.
- Note: Signal losses may occur in installations with significantly longer cable runs than the included 5m HDF 195 cables.
Specifications & Features
| Manufacturer: | Poynting |
| Model: | XPOL-1-5G PLUS v3 (A-XPOL-0001-V3-41) |
| Product Type: | 4x4 MIMO 5G 4G Omni-Directional Antenna |
| MIMO Configuration: | 4x4 MIMO (4 antennas in one housing) |
| Frequency Range: | 410 – 6000 MHz |
| Gain: | Max. 7 dBi (frequency dependent) |
| Characteristic: | Omni-Directional |
| Cables: | 4x 5m HDF-195 (Fixed connection) |
| Connector: | 4x SMA Male Connector |
| Protection Class: | IP65 (Weatherproof) |
| Mounting: | Wall, Pole, Window (Accessories incl.) |
| Dimensions: | approx. 247 x 157 x 88 mm |
Scope of Delivery
| 1x Poynting XPOL-1-5G PLUS v3 Antenna (A-XPOL-0001-V3-41) with 4x 5m Cables |
| 1x Universal Mounting Bracket (Z-bracket) |
| 1x Pipe Clamp |
| 1x Window Suction Cups |
Frequently Asked Questions (FAQ)
What does 4x4 MIMO mean for the Poynting XPOL-1-5G PLUS v3 antenna?
The 4x4 MIMO (Multiple-Input Multiple-Output) configuration means that your antenna contains four separate antenna elements in one enclosure that can transmit and receive simultaneously. This leads to a significant increase in your data transfer rates, better signal stability, and increased capacity compared to 2x2 MIMO or SISO (Single-Input Single-Output) systems.
Can the Poynting XPOL-1-5G PLUS v3 be used for both 4G and 5G?
Yes, the Poynting XPOL-1-5G PLUS v3 is an ultra-wideband antenna covering a frequency range from 410 to 6000 MHz. This makes it compatible with all common 2G, 3G, 4G-LTE, and future 5G networks up to 6 GHz, ensuring you remain flexible.
Is the Poynting XPOL-1-5G PLUS v3 suitable for outdoor use?
Yes, your antenna is equipped with a robust, IP65-certified enclosure, making it weather, dust, and vandalism resistant. It is explicitly designed for outdoor use, and you can mount it on walls, poles, or even windows.
What gain (dBi) does the Poynting XPOL-1-5G PLUS v3 offer?
The 4x4 MIMO version of the Poynting XPOL-1-5G PLUS v3 (A-XPOL-0001-V3-41) offers you a peak gain of 7 dBi.
What mounting options are available for the Poynting XPOL-1-5G PLUS v3?
Your antenna offers versatile mounting options and comes with accessories for pole, wall, and window mounting (using suction cups), allowing for flexible installation.
Is the Poynting XPOL-1-5G PLUS v3 better suited for urban or rural areas?
Thanks to its high gain at lower frequencies, the XPOL-1-5G PLUS v3 is particularly well-suited for rural and suburban areas to extend your range. However, it also performs well in urban environments, especially if you prefer omnidirectional coverage due to obstacles or reliability requirements.
