Your Reliable Core for IoT Solutions
The Teltonika TRB160 is more than just a gateway – it is the central command unit for your demanding IoT projects. Imagine being able to monitor machines in real-time, transmit sensor data without delay, and control your systems from anywhere. This powerful 4G Cat 6 IoT Gateway makes exactly that possible. It was developed to offer you maximum reliability and performance in industrial and professional environments. With the TRB160, you lay the foundation for efficient and future-proof networking of your devices.
High-Speed Connectivity, Wherever You Need It
Forget slow connections! Thanks to 4G Cat 6, the TRB160 brings you impressive speeds of up to 300 Mbit/s for downloads and 50 Mbit/s for uploads. This means for you: fast data transfer, smooth communication, and no waiting times. Whether you want to send large amounts of data or access complex cloud services, this gateway keeps pace. In addition, the Gigabit Ethernet port ensures an extremely stable and fast wired connection to your local Network or connected devices. This way, you are always optimally connected, even when no WiFi is available.
Robustness Meets Modern Flexibility
The TRB160 is not only fast but also extremely resilient. Its robust aluminum housing reliably protects the sensitive electronics from external influences, making it the ideal choice for harsh industrial environments. The modern USB-C interface offers you not only a flexible power supply but also additional options for data transfer and configuration. Easy installation and intuitive operation complete the overall package and make the TRB160 a true all-rounder for your IoT requirements.
Versatile Applications for Your Business
Whether in automation technology, in the smart city sector, for remote maintenance of systems, or as a reliable Teltonika 4G / 5G Routers for mobile applications – the TRB160 adapts to your needs. It supports a variety of protocols and offers extensive management functions that facilitate integration into existing systems. With this IoT Gateway, you are well equipped to advance the digitalization of your processes and unlock new potential. Use the power of Teltonika for your connectivity.
Strengths & Notes at a Glance
- Pro: High 4G Cat 6 speed for fast data transmission.
- Pro: Robust Gigabit Ethernet port for stable wired connections.
- Pro: Modern USB-C interface for flexible power supply and data.
- Pro: Compact and robust aluminum housing, ideal for industrial use.
- Pro: Extensive software functions for management and security.
- Note: Requires a SIM card for 4G functionality (not included).
Specifications & Features
| Manufacturer: | Teltonika |
| Model: | TRB160 |
| Product Type: | IoT Gateway |
| Cellular Standard: | 4G Cat 6 |
| Download Speed: | Up to 300 Mbit/s |
| Upload Speed: | Up to 50 Mbit/s |
| Ethernet Ports: | 1 x Gigabit Ethernet (RJ45) |
| Connections: | 1 x USB-C (Power/Data), 2 x SMA (for 4G Antennas) |
| SIM Card Slots: | 1 x Mini-SIM (2FF) |
| Antennas: | 2 x external 4G antenna connectors |
| Power Supply: | 9-30 V DC (via USB-C or terminal block) |
| Operating Temperature: | -40°C to +75°C |
| Housing Material: | Aluminum |
| Dimensions (WxHxD): | approx. 75 x 25 x 65 mm |
| Mounting: | DIN rail (optional accessory) |
| Management: | RMS (Remote Management System), WebUI, CLI |
| Security Features: | Firewall, VPN (OpenVPN, IPsec, GRE, L2TP, PPTP) |
| Additional Functions: | SMS control, Bootloader, Watchdog |
Scope of Delivery
| 1 x Teltonika TRB160 IoT Gateway |
| 2 x 4G Antennas |
| 1 x USB-C Cable |
| 1 x QSG (Quick Start Guide) |
Frequently Asked Questions (FAQ)
What is the Teltonika Networks TRB160?
The Teltonika Networks TRB160 is a compact and powerful LTE Cat 6 IoT gateway, designed for reliable and fast data connectivity in various industrial and IoT applications.
What are the main features of the TRB160 IoT gateway?
Key features include LTE Cat 6 for fast mobile data transmission, a versatile USB-C port for power supply and data, and a Gigabit Ethernet port for high-speed wired connections.
What does LTE Cat 6 mean for the TRB160 and what advantages does it offer?
LTE Cat 6 enables download speeds of up to 300 Mbps, ensuring efficient data transmission and low latency, which are crucial for demanding IoT applications.
What connectivity options does the Teltonika TRB160 offer?
The TRB160 offers a Gigabit Ethernet port for integration into wired networks and a USB-C port that can be used for both power supply and potentially data transmission.
For which application areas is the Teltonika TRB160 particularly suitable?
It is ideal for industrial automation, smart city solutions, remote monitoring, digital signage, and other M2M applications that require robust and secure connectivity.
How is the Teltonika TRB160 powered?
The TRB160 is typically powered via its USB-C port, offering flexible power supply options and modern connectivity.
