Poynting MIMO-4-17 - 5G / 4G / GPS / WiFi Antenna, White, IP69K

The A-MIMO-0004-V1-17-W is a 7-in-1 high performance, multi frequency antenna within a single housing. The antenna provides four cellular, two Wi-Fi and a GPS/GLONASS antenna. The four cellular MIMO antennas offer wideband coverage from 617 to 6000 MHz, covering contemporary LTE/ 4G and 5G bands for future proof implementation. The ultra-wideband performance of the cellular antennas allows it to be used across different operators and technologies and is ready for future cellular technologies up to 6 GHz for 5G applications, as well as Wi-Fi application from 5 to 6 GHz. The housing of the MIMO-4-17 corresponds to the IP69K, UL 94-HB and IK10 class. Three mounting systems are included in the scope of delivery (adhesive pad, Sigpot / thread with lock nut, mount for wall or mast mounting.)

Areas of use
  • Private Vehicles, Campers, Caravans, RVs
  • Small boats, yachts near to coastlines or inner waters
  • Smart power, Gas & Water Metering
  • Climate control, access control, security, irrigation
  • Industrial factory automation, robotic machinery and other M2M systems
  • Warehouses & Logistic systems
  • Transport (Busses, Utility & Public Safety)
  • Mining Vehicles & Machinery communications, telemetry and automation (M2M & IoT)
  • Agricultural machinery
  • Digital Signage

ART7375 6009710925423 A-MIMO-0004-V1-17-W
234,99 €
incl. 19% VAT , plus shipping costs (Standard)
pcs
  • Available immediately
  • Delivery time: 2 - 3 Workdays (DE - int. shipments may differ)
Description

The MIMO-4-17 is a 7-in-1 high performance, multi frequency antenna within a single housing. The antenna provides four cellular, two Wi-Fi and a GPS/GLONASS antenna. The four cellular MIMO antennas offer wideband coverage from 617 to 6000 MHz, covering contemporary LTE/ 4G and 5G bands for future proof implementation. The ultra-wideband performance of the cellular antennas allows it to be used across different operators and technologies and is ready for future cellular technologies up to 6 GHz for 5G applications, as well as Wi-Fi application from 5 to 6 GHz.

The antenna also provides four dual-band Wi-Fi antennas, providing concurrent 2.4 GHz and 5 to 7.2 GHz on each antenna for 2x2 MIMO capability. The MIMO-4-17 exceeds the performance of most competitors due to the attention to the design of this high-performance antenna. The radiation patterns of all radiating elements, provide an excellent balance between omni-directionality, pattern diversity and good radiation abilities at the desired elevation. This is an important criterion for the transportation and marine market, which the antenna was specifically designed for. Main applications are for commercial/industrial vehicles, marine, M2M and other IoT systems using a wide range of radio technologies, while remaining futureproof over the wide frequency band.


Supplied mounting systems

  • Spigot Mount
  • Adhesive Tape Mount
  • Bracket Mount

Application Areas

  • Private Vehicles, Campers, Caravans, Motorhomes
  • Public Vehicles, Trucks, Tractors, Industrial Vehicles
  • Installations on ceilings, equipment cabinets or machines
  • M2M (Machine to Machine) and other IoT (Internet of Things) applications

Connector / Cable

  • 4 x 2m RTK-031 cable - 5G/4G with SMA plug
  • 2 x 2m RTK-031 cable - WiFi with RP-SMA plug
  • 1 x 2m RTK-031cable - GPS / GLONASS with SMA plug


Technical Data:

Manufacturer / Model:Poynting / A-MIMO-0004-V1-17-W
Antenna Type:Omnidirectional
Frequency 5G / 4G:698 - 960 MHz, 1427 -1517 MHz, 1710 - 2700 MHz, 3400 - 3200 MHz, 5000 - 6000 MHz
Gain 5G / 4G:max. 6dBi
Frequency WiFi:2400-2500 MHz, 5000-7200 MHz
Gain WiFi:max. 6.5dBi
Frequency GPS:1575.42 - 1600 MHz
Gain GPS:21 +-2 dB
Cable / Connection:4 x 2m cable / SMA male (4G / 5G)
2 x 2m cable / RP-SMA male (WiFi)
1 x 2m cable / SMA male (GPS)
Impedance50 Ohm
Appliance:In- and Outdoor
IP-Rating:IP69K (exclude cable outlet)
Temperature Range:-40° to 80° C
Humidity:up to 95%
Dimensions:Ø160 mm x 65 mm
Color:White


Scope of delivery:

Poynting MIMO-4-17 5G / 4G / GPS / WiFi Antenna, White
Set of mounting kits
