Absolutely Silent: The UniFi PoE Switch for your Office
Imagine a powerful Network hub that you don't hear. The USW-24-POE makes exactly that possible. Thanks to its well-thought-out passive cooling concept, it operates completely without fans. The result: zero noise pollution. This makes it the first choice for use directly at the workplace, in conference rooms, doctor's offices, or your home theater. Finally, full Network power without annoying humming – focus on what really matters.
Central Management with the UniFi Network Controller
The USW-24-POE is a true team player in the Ubiquiti ecosystem. Once integrated, you can conveniently configure and monitor it via the central UniFi Network Application. Whether on a Cloud Key, a local server, or a Dream Machine – you have full control. Manage VLANs, set up Link Aggregation, and analyze traffic. This UniFi Switch works perfectly with other components such as UniFi Access Points or IP Cameras from the UniFi Protect series, creating a harmonious, easy-to-manage overall system.
Innovative Touch-Display for a Quick Overview
Forget cryptic LED lights. The USW-24-POE features a brilliant 1.3-inch Touch-LCM-Display directly on the front. With a simple touch, you get immediate insight into important system statistics. Check the current PoE utilization, view connection details, or receive alerts – all directly on the device. This feature saves valuable time during troubleshooting and gives you quick, visual feedback on the status of your Network.
Flexible Power Supply for your Network Devices
With 16 PoE+ Ports according to the 802.3at standard, this Ethernet Switch is a true powerhouse for your end devices. Connect IP Cameras, VoIP phones, or WiFi Access Points and power them directly via the network cable. The total PoE Budget of 95 Watts offers sufficient reserves for most SOHO (Small Office/Home Office) and SME applications. Intelligent PoE management ensures a stable and secure Power Supply for your connected devices.
Strengths & Notes at a Glance
- Pro: Completely silent operation due to fanless design, ideal for offices and living spaces.
- Pro: Seamless and central management within the UniFi ecosystem.
- Pro: Innovative 1.3-inch Touch-Display for quick status checks directly on the device.
- Pro: Compact installation depth of only 200 mm, perfect for small 19-Inch Racks.
- Note: The PoE Budget of 95W can reach its limits when fully equipped with powerful PoE+ devices.
- Note: The SFP Uplink Ports are limited to 1 Gbps and do not offer 10G for future-proof high-speed connections.
Specifications & Features
| Manufacturer: | Ubiquiti |
| Model: | UniFi USW-24-POE |
| EAN: | 0817882028554 |
| Device Type: | Managed Gigabit Layer 2 Network Switch |
| Form Factor: | 1U Rack-mountable, Desktop-capable |
| Dimensions (W x D x H): | 442.4 x 200 x 43.7 mm |
| Weight (without Rackmount Brackets): | 3.00 kg |
| Weight (with Rackmount Brackets): | 3.09 kg |
| Housing Material: | SGCC Steel |
| Cooling: | Passive (fanless) |
| Display: | 1.3-inch Touch-LCM |
| Switching Capacity: | 52 Gbps |
| Total Non-Blocking Throughput: | 26 Gbps |
| Forwarding Rate: | 38.69 Mpps |
| MAC Address Table: | 8,000 entries |
| RJ45 Ports (PoE+): | 16x 10/100/1000 Mbps (Ports 1-16) |
| RJ45 Ports (Standard): | 8x 10/100/1000 Mbps (Ports 17-24) |
| SFP Ports: | 2x 1G SFP (no 10G SFP+) |
| Management Interface: | Ethernet In-Band |
| PoE Standard: | IEEE 802.3af (PoE) / 802.3at (PoE+) |
| Support for 24V Passive PoE: | No |
| Total PoE Budget: | 95W |
| Max. PoE Power per Port: | 32W (according to 802.3at) |
| PoE Voltage Range (802.3af): | 44-57V |
| PoE Voltage Range (802.3at): | 50-57V |
| PoE Pinout: | Pins 1, 2 (+) and 3, 6 (-) |
| Power Supply: | Internal Power Supply (100-240VAC, 50/60 Hz) |
| Max. Power Supply Output: | 120W |
| Max. Power Consumption (without PoE): | 25W |
| Max. Power Consumption (incl. PoE): | 120W |
| Management Software: | UniFi Network Application v5.11.x or newer |
| Layer 2 Features: | VLANs, LACP, STP/RSTP, Port Mirroring, Storm Control, Port Isolation, Jumbo Frames, 802.1X, DHCP Snooping |
| Operating Temperature: | -5°C to 40°C |
| Operating Humidity: | 10% to 90% non-condensing |
| ESD/EMP Protection: | Air: ± 16 kV, Contact: ± 12 kV |
| Certifications: | CE, FCC, IC |
Scope of Delivery
| 1 x Ubiquiti UniFi USW-24-POE Switch |
| 1 x Rack Mount Kit |
| 1 x Power Cord (EU) |
Frequently Asked Questions (FAQ)
Does the Ubiquiti USW-24-POE require a Cloud Key or software to function?
Yes, the UniFi Network Controller is required for configuration and management. This can be run for free on a local PC, a server, or dedicatedly on a Ubiquiti Cloud Key or a UniFi Dream Machine. The UniFi Switch itself does not have an integrated controller.
Is the USW-24-POE UniFi Switch loud?
No, the UniFi Switch is completely passively cooled due to its fanless design and is therefore completely silent during operation, making it ideal for office environments.
How many devices can I power with PoE?
The UniFi Switch features 16 ports (1-16) that support the PoE/PoE+ standard (802.3af/at). The total power consumption of all connected devices must not exceed the 95 Watt budget provided by the PoE Injectors / Power Supplies.
Can I also operate older Ubiquiti devices with 24V passive PoE with the USW-24-POE?
No, this second-generation (Gen2) UniFi Switch model exclusively supports the 802.3af/at standards and does not offer support for 24V passive PoE.
What is the difference between the USW-24-POE and the USW-Pro-24-POE?
The Pro UniFi Switch offers a significantly higher PoE budget (400W), PoE++ support, Layer-3 features, and faster 10G SFP+ Uplinks. The standard USW-24-POE is a pure Layer-2 UniFi Switch with 1G SFP / SFP\+ Modules and a 95W PoE budget.
How warm does the UniFi Switch get during operation?
Since the UniFi Switch is passively cooled, it can become noticeably warm under high PoE load. It is important to ensure adequate ventilation in the 19-Inch Racks or at the installation location and not to stack other devices directly on top of it.
