Is Your Network at Its Limit?
Do you know the feeling when your network buckles under increasing load? When more and more devices and users are online simultaneously, video streams stutter, and your network's security leaves much to be desired? Traditional routers and gateways quickly reach their limits when it comes to managing a large number of clients and UniFi devices stably and with high performance. Complexity grows, performance declines, and concerns about cyber threats increase. This is not only frustrating but can also severely disrupt business-critical processes.
The Solution: Ubiquiti UniFi Dream Machine Pro Max
The Ubiquiti UniFi Dream Machine Pro Max (UDM-Pro-Max) is the answer to all these challenges. As a high-performance 10G Cloud Gateway, it was specifically designed for demanding enterprise environments. With its superior processing power and 8 GB DDR4 RAM, it effortlessly manages over 200 UniFi devices and up to 2,000 clients. Enjoy impressive 5 Gbps IDS/IPS routing performance, which not only makes your network lightning-fast but also optimally protects it from threats. The UDM-Pro-Max integrates all UniFi applications for centralized, intuitive management of your entire network infrastructure.
Maximum Connectivity and Security
This Dream Machine offers comprehensive connectivity with one 10G SFP+ WAN port and one 2.5 GbE RJ45 WAN port for redundant internet connections with failover and load balancing. For your internal network, eight Gigabit RJ45 LAN ports and an additional 10G SFP+ LAN port are available to handle even bandwidth-intensive applications without issues. The integrated NVR functionality with two 3.5-inch HDD bays (RAID-capable) and a built-in 128 GB SSD ensures reliable and fast storage of your surveillance videos. With Shadow Mode (VRRP) and DC Power Backup, your network remains highly available even during outages.
Intelligent Management for Your Future
The UDM-Pro-Max is more than just hardware; it's an intelligent platform for your network management. Via the 1.3-inch touchscreen display, you always have an overview of device status and important diagnostic data. The full UniFi Application Suite enables centralized control of all UniFi devices, from WLAN Access Points to cameras and Access Hubs. Benefit from advanced security features such as application-based firewall rules, IDS/IPS threat detection, and content filtering. With license-free SD-WAN, WireGuard, L2TP, and OpenVPN Server functionalities, you are well-equipped for the future and can expand your network flexibly and securely.
Technical Specifications
| Model: | Ubiquiti UniFi Dream Machine Pro Max (UDM-Pro-Max) |
| Processor: | Quad-core ARM® Cortex®-A57 with 2.0 GHz |
| System Memory: | 8 GB DDR4 |
| On-Board Storage: | 32 GB eMMC, 128 GB integrated SSD |
| NVR HDD Bays: | (2) 3.5 inch (also supports 2.5 inch, RAID-capable) |
| WAN Ports: | (1) 10G SFP+, (1) 2.5 GbE RJ45 |
| LAN Ports: | (8) GbE RJ45, (1) 10G SFP+ |
| IDS/IPS Throughput: | 5 Gbps (measured with iPerf3) |
| Max. Managed UniFi Devices: | 200+ |
| Max. Concurrent Clients: | 2,000+ |
| Management Interface: | Ethernet, Bluetooth |
| Display: | 1.3 inch Touchscreen LCM |
| Power Supply: | Universal AC (100-240V AC), USP-RPS DC input |
| Max. Power Consumption: | 100W (AC/DC, internal, 100W power supply) |
| ESD/EMP Protection: | Air: ± 15kV, Contact: ± 8kV |
| Enclosure Material: | Aluminum CNC, SGCC steel |
| Dimensions (WxDxH): | 442.4 x 285.6 x 43.7 mm (17.4 x 11.2 x 1.7 inches) |
| Weight: | 4.7 kg (10.4 lb) |
| Operating Temperature: | -10° to 40° C (14° to 104° F) |
| Operating Humidity: | 5 to 95% non-condensing |
| Certifications: | CE, FCC, IC, SRRC, Anatel, NDAA Compliant |
Package Contents
| 1 x Ubiquiti UniFi Dream Machine Pro Max (UDM-Pro-Max) |
| 1 x Rackmount Ear Kit |
| 1 x Power Cord |
| 1 x Screw Set |
Häufig gestellte Fragen (FAQ)
What is the main difference between the UDM-Pro-Max and the UDM-Pro/SE?
The UDM-Pro-Max offers double the processing power and storage capacity compared to the UDM-Pro/SE, enabling it to manage over 200 UniFi devices and 2,000+ clients. Additionally, it features enhanced 5 Gbps IDS/IPS routing performance and advanced redundancy functions.
Which WAN and LAN ports are available on the UDM-Pro-Max?
The UDM-Pro-Max is equipped with a 10G SFP+ WAN port, a 2.5 GbE RJ45 WAN port, eight Gigabit RJ45 LAN ports, and an additional 10G SFP+ LAN port.
Does the UDM-Pro-Max support surveillance video storage?
Yes, the UDM-Pro-Max features two 3.5-inch HDD bays (also supporting 2.5-inch HDDs) with RAID data protection and an integrated 128 GB SSD specifically for NVR recordings.
What security features does the UDM-Pro-Max offer?
The UDM-Pro-Max provides 5 Gbps IDS/IPS threat detection, an application-based Layer 7 Firewall, Deep Packet Inspection (DPI), zone-based filtering, content filtering, and ad-blocking to comprehensively protect your network.
Is the UDM-Pro-Max suitable for use in large enterprise networks?
Absolutely. The UDM-Pro-Max is designed as an Enterprise-Grade Cloud Gateway, ideal for large businesses, campus networks, and high-density environments. It supports Shadow Mode (VRRP) for high availability and DC Power Backup for maximum reliability.
