Your Command Center for a Seamless Network
The UniFi Dream Machine is the ideal starting point to elevate your home or office Network to a new level. Forget complicated configurations and the need for multiple separate devices. The UDM integrates everything you need for a fast, stable, and secure Network. Thanks to the pre-installed UniFi Network Software, setting up your home office Network becomes child's play. Via the intuitive mobile app, your new Network is ready in minutes – without any technical expertise.
Scalability Meets Simplicity
The beauty of the UniFi ecosystem by Ubiquiti is its enormous flexibility. The UniFi Dream Machine is the perfect foundation. Is your need growing? Simply expand your WiFi by adding more UniFi Access Points to provide perfect signal to every corner of your home or office. Do you need more wired connections? Integrate a UniFi Switch. All devices are seamlessly recognized and centrally managed by your UDM. This way, you can scale your UniFi Network with the Dream Machine and adapt it to any requirement without losing central control.
Enterprise-Level Security for Your Home
In a connected world, security is not a luxury but a necessity. The UDM brings professional security features, otherwise found only in expensive enterprise Networks, directly to your home. The integrated Threat Management System with Intrusion Detection (IDS) and Intrusion Prevention (IPS) analyzes data traffic in real-time and blocks threats before they can cause damage. With Deep Packet Inspection (DPI), you see exactly which applications and clients are using your bandwidth, and you can ensure a clean separation of your devices with targeted Firewall rules and VLANs. This is the best All-in-One UniFi Setup for beginners who don't want to compromise on security.
Strengths & Notes at a Glance
- Pro: Combines four devices (Gateway, UniFi Switch, WiFi Access Point, UniFi Network Controller) in a compact design.
- Pro: Offers powerful Enterprise features like VLANs, DPI, and IPS/IDS with high throughput.
- Pro: Intuitive and centralized management of the entire Network via web UI or mobile app.
- Pro: Ideal and cost-effective entry into the scalable UniFi ecosystem.
- Note: Supports the Wi-Fi 5 (802.11ac) standard, not the newer Wi-Fi 6.
- Note: All Ethernet ports are limited to 1 Gbit/s; no Multi-Gig or PoE Injectors / Power Supplies ports available.
- Note: As an all-in-one device, it lacks the redundancy (e.g., Dual-WAN) of modular setups.
Specifications & Features
| Manufacturer: | Ubiquiti |
| Model: | UniFi Dream Machine (UDM) |
| Manufacturer Part Number (MPN): | UDM-EU |
| EAN: | 0817882025966 |
| Device Category: | All-in-One Network device (Router) |
| Integrated Components: | Security Gateway, 4x4 WiFi Access Point, 4-Port UniFi Switch, UniFi Network Controller |
| Form Factor: | Desktop / Cylinder |
| Dimensions (Ø x H): | 110 x 184.2 mm |
| Weight: | 1.05 kg |
| Housing Material: | Polycarbonate |
| Processor: | Arm Cortex-A57 Quad-Core with 1.7 GHz |
| System Memory: | 2 GB DDR RAM |
| On-Board Flash Memory: | 16 GB |
| IDS/IPS Throughput: | approx. 850 Mbps |
| LAN Ports: | (4) 10/100/1000 RJ45 Ports |
| WAN Port: | (1) 10/100/1000 RJ45 Port |
| Management Interface: | Ethernet, Bluetooth Low Energy (BLE) |
| WiFi Standards: | 802.11 a/b/g/n/ac/ac-wave2 |
| Frequency Bands: | Dual-Band (2.4 GHz & 5 GHz) |
| MIMO Technology 5 GHz: | 4x4 MU-MIMO |
| MIMO Technology 2.4 GHz: | 2x2 MIMO |
| Maximum Data Rate 5 GHz: | 1733 Mbit/s (1.7 Gbps) |
| Maximum Data Rate 2.4 GHz: | 300 Mbit/s |
| Antenna Type: | (1) Dual-Band, Quad-Polarity Antenna |
| Antenna Gain 2.4 GHz: | 3 dBi |
| Antenna Gain 5 GHz: | 4.5 dBi |
| Maximum Transmit Power 2.4 GHz: | 23 dBm |
| Maximum Transmit Power 5 GHz: | 26 dBm |
| WiFi Security: | WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11w/PMF |
| BSSID per Radio Module: | Up to 8 |
| WiFi Features: | Beamforming |
| Power Supply: | Internal AC/DC Power Supply (100 - 240VAC) |
| Maximum Power Consumption: | 26W |
| Pre-installed Software: | UniFi Network Application (UniFi OS) |
| Security Features: | Gateway Firewall, IDS/IPS, DPI, Content Filtering, VPN Server |
| Network Functions: | VLAN, QoS, DHCP Server, mDNS, Dynamic DNS |
| Operating Temperature: | -10°C to 45° C |
| Operating Humidity: | 5 to 95% non-condensing |
| Certifications: | CE, FCC, IC |
Scope of Delivery
| 1 x Ubiquiti UniFi Dream Machine (UDM-EU) |
| 1 x AC Power Cable |
Frequently Asked Questions (FAQ)
Can the Ubiquiti UniFi Dream Machine replace an existing modem/router from the internet provider?
Yes, in most cases, the UDM can replace the internet provider's router. You connect your provider's modem (in 'bridge mode', if possible) to the WAN port of the UDM. The UDM then handles all
How many devices can the UniFi Dream Machine manage?
The UDM is designed for small to medium-sized environments. It can easily manage dozens of
Is setting up the UniFi Dream Machine complicated for beginners?
No, the initial setup for a device with this range of functions is remarkably simple. It can be done via the
Can I extend the of the Dream Machine?
Yes, this is one of its core strengths. You can seamlessly extend the
What is the difference between IDS and IPS on the Dream Machine?
IDS (Intrusion Detection System) detects potentially malicious
Do I need a account to use the Dream Machine?
For full functionality, especially for easy remote access (Cloud Access), a free
