Welcome to the Future: The UniFi U7 Pro with WiFi 7
The Ubiquiti U7 Pro is more than just an upgrade – it's a leap into the next generation of Network technology. As a high-performance WiFi 7 Access Point, it uses the 802.11be standard to deliver previously unattainable wireless performance. The centerpiece is the new 6 GHz frequency band, exclusively reserved for state-of-the-art devices. The result? An interference-free connection with extremely low latency, perfect for 4K/8K streaming, online gaming, and demanding business applications. With channel bandwidths of up to 320 MHz, the U7 Pro maximizes data throughput and gets your Network ready for the devices of tomorrow.
Built for Performance: 2.5 GbE and PoE+
What good is the fastest WiFi if the cable connection slows it down? Ubiquiti has thought ahead and equipped the U7 Pro with a 2.5 Gigabit Ethernet port. This crucial advantage ensures that the gigantic data rates of WiFi 7 actually arrive in your wired Network. Power is supplied elegantly and simply via PoE+ (Power over Ethernet Plus). This means you only need a single network cable for data and power, which drastically simplifies installation on ceilings or walls. This professional Wireless Access Point is designed for maximum efficiency and easy implementation.
The UniFi Ecosystem: Central Management Made Easy
The U7 Pro unfolds its full potential in conjunction with the UniFi Network Application. This powerful software allows you to centrally control your entire Network through a single, intuitive interface. Configure WiFi settings, monitor network traffic in real-time, set up guest networks, or use advanced features like Wireless Meshing and Fast Roaming (802.11r/k/v). Whether you're managing a small business or a complex home Network – the UniFi ecosystem provides you with the tools for a professional and scalable network solution.
Strengths & Notes at a Glance
- Pro: Future-proof WiFi 7 technology with 6 GHz band for superior performance.
- Pro: Excellent price-performance ratio compared to other enterprise WiFi 7 devices.
- Pro: 2.5 GbE uplink port prevents performance bottlenecks to the wired Network.
- Pro: Perfect and seamless integration into the UniFi ecosystem for central management.
- Note: A PoE+ injector or a compatible switch is required for power and is not included in the scope of delivery.
- Note: To utilize the full potential, end devices with WiFi 7 support are required.
Specifications & Features
| Manufacturer: | Ubiquiti |
| Model: | UniFi U7 Pro |
| HAN/MPN: | U7-Pro |
| EAN: | 0810084693650 |
| Device Type: | Wireless Access Point |
| Dimensions: | ⌀ 206 x 46 mm |
| Weight: | 680 g |
| Enclosure Material: | Polycarbonate, Metal |
| Mounting Material: | Stainless steel (SUS304), galvanized steel (SGCC) |
| Mounting Options: | Ceiling and wall mounting |
| Networking Interface: | (1) 2.5 GbE RJ45 Port |
| Power Method: | PoE+ (Power over Ethernet Plus) |
| Supported Voltage Range: | 44–57V DC |
| Max. Power Consumption: | 21W |
| WiFi Standards: | 802.11a/b/g/n/ac/ax/be |
| Supported Protocols: | WiFi 4, WiFi 5, WiFi 6, WiFi 6E, WiFi 7 |
| Radio Bands: | Tri-Radio (2.4 GHz, 5 GHz, 6 GHz) |
| MIMO 6 GHz: | 2x2 (DL/UL MU-MIMO) |
| MIMO 5 GHz: | 2x2 (DL/UL MU-MIMO) |
| MIMO 2.4 GHz: | 2x2 (DL/UL MU-MIMO) |
| Number of Spatial Streams: | 6 |
| Maximum Aggregate Data Rate: | 9.3 Gbps |
| Data Rate 6 GHz: | up to 5765 Mbps |
| Data Rate 5 GHz: | up to 2882 Mbps |
| Data Rate 2.4 GHz: | up to 688 Mbps |
| Antenna Gain 6 GHz: | 5.8 dBi |
| Antenna Gain 5 GHz: | 6 dBi |
| Antenna Gain 2.4 GHz: | 4 dBi |
| Max. TX Power 6 GHz: | 23 dBm |
| Max. TX Power 5 GHz: | 26 dBm |
| Max. TX Power 2.4 GHz: | 22 dBm |
| Supported Channel Bandwidths: | 20/40/80/160/240/320 MHz |
| Wireless Security: | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
| BSSIDs: | 8 per radio |
| VLAN: | 802.1Q |
| Advanced QoS: | Per-User Rate Limiting |
| Guest Traffic Isolation: | Supported |
| Recommended Client Count: | 300+ |
| Coverage Area: | approx. 140 m² |
| Wireless Meshing: | Supported |
| Fast Roaming: | 802.11r/k/v |
| Operating Temperature: | -30 to 60° C |
| Operating Humidity: | 5 to 95% noncondensing |
| Certifications: | CE, FCC, IC |
Scope of Delivery
| 1 x Ubiquiti UniFi U7 Pro Access Point |
| 1 x Pro Mount Kit (Wall/Ceiling Mount) |
Frequently Asked Questions (FAQ)
Do I need a special controller to operate the Ubiquiti U7 Pro?
Yes, the UniFi Network Application is required for configuring and managing the U7 Pro. It can be hosted for free on your own server (PC, Mac, Linux), a UniFi Cloud Console (e.g., UniFi Dream Machine, Cloud Key), or in the cloud.
Is the U7 Pro backward compatible with older WiFi devices?
Yes, absolutely. The U7 Pro is fully backward compatible with all older WiFi standards such as WiFi 6E, WiFi 6 (802.11ax), WiFi 5 (802.11ac), and WiFi 4 (802.11n). Older devices can connect without any issues but will not utilize the new WiFi 7-specific features.
What is the main advantage of the 6 GHz band on the U7 Pro?
The 6 GHz band is a new, exclusive frequency range for WiFi 6E and WiFi 7. The main advantage is that it is free from interference from older WiFi devices, microwaves, or baby monitors. This results in a more stable, faster, and more reliable connection, especially in environments with many networks.
Can I use the U7 Pro outdoors?
No, the U7 Pro is designed exclusively for indoor use. It does not have an appropriate IP rating against water or dust, and its operating temperatures are designed for protected use.
What does 'PoE+' mean and why is it important?
PoE+ (Power over Ethernet Plus, standard 802.3at) allows the access point to be powered over the same Ethernet Cable that carries the data. This significantly simplifies installation, as no separate power outlet is needed at the mounting location (e.g., on the ceiling).
Does the U7 Pro support 'Wireless Meshing'?
Yes, the U7 Pro supports Wireless Meshing. This means it can wirelessly connect to other UniFi Access Points to extend the WiFi signal to areas where Ethernet Cabling is not possible.
