The Command Center for your Omada Network
The TP-Link OC300 is more than just a controller – it's the brain of your entire Omada Software Defined Networking (SDN) setup. Instead of configuring each device individually, the OC300 provides central control. It automatically detects new Omada devices, enables click-based configuration, and gives you a complete overview of the Network topology in real-time. This makes managing even the most complex networks child's play.
Central WiFi Management System: Efficiency Redefined
Imagine being able to update the firmware of 300 WiFi Access Points with a single click. Or changing the WiFi settings for an entire hotel building in minutes. This is exactly what the OC300 enables. As a dedicated WiFi Controller for many Access Points, it is the perfect solution for high-density environments such as offices, schools, or hospitality. Create guest networks with Captive Portal, schedule automatic restarts, and ensure seamless roaming – all from a central dashboard.
Hybrid Cloud Flexibility without License Costs
With the OC300, you decide how to manage your Network. Maintain full control and security by working locally via the web interface. Or take advantage of the crucial benefit of free hybrid cloud access. Simply link your controller to your TP-Link ID and access it from anywhere in the world via the Omada Cloud portal or the intuitive smartphone app. Whether you're in the office, at home, or traveling – your network is always just a tap away, with no ongoing costs.
Built for Performance: Hardware that Impresses
The OC300 was developed for demanding continuous operation. Its robust metal housing can be easily mounted in a 19-inch server cabinet and ensures optimal heat dissipation. The fanless design guarantees absolutely silent operation, ideal for use in office environments. The powerful quad-core processor ensures that the management interface remains fluid even with thousands of connected clients. This is professional hardware for professional Omada network central management.
Strengths & Notes at a Glance
- Pro: Enormous scalability for up to 500 Access Points and 15,000 clients.
- Pro: Free Hybrid Cloud access for maximum flexibility without license fees.
- Pro: 100% centralized management saves massive time in configuration and maintenance.
- Pro: Robust, rack-mountable hardware with fanless design for professional use.
- Pro: USB 3.0 port for automatic configuration backups increases reliability.
- Note: Works exclusively with devices from the TP-Link Omada ecosystem.
- Note: During migrations, appropriate firmware versions must be observed to avoid backup incompatibilities.
Specifications & Features
| Manufacturer: | TP-Link |
| Model: | OC300 Omada |
| EAN: | 6935364089863 |
| Product Type: | Hardware Controller |
| Processor: | Quad-Core Cortex-A72 @ 1.2 GHz |
| RAM: | 2 GB DDR4 |
| Internal Storage: | 8 GB eMMC, 2MB Nor Flash |
| Network Ports: | 2x 10/100/1000 Mbps Ethernet RJ45 Ports |
| Other Ports: | 1x USB 3.0 Port (for Auto-Backup) |
| Security: | 1x Kensington Lock Slot |
| Power Supply: | External Power Adapter (100-240 V ~ 50/60 Hz, 0.6 A) |
| Max. Power Consumption: | 9.0 W (without USB) / 14.8 W (with USB 3.0 device) |
| Dimensions (W x D x H): | 294 × 180 × 44 mm |
| Housing & Mounting: | Durable metal housing, fanless, 19-Inch Rack-mountable / Desktop |
| Management Capacity (APs): | Up to 500 Omada Access Points |
| Management Capacity (Switches): | Up to 100 Omada JetStream Switches |
| Management Capacity (Routers): | Up to 100 Omada Routers |
| Management Capacity (Clients): | Up to 15,000 Clients |
| Management Access: | Web Browser (Local UI), Omada App (iOS/Android), Cloud portal |
| Management Functions: | Automatic Device Discovery, Batch Configuration & Upgrades, Intelligent Network Monitoring, Real-time Topology, Multi-Site Management, Captive Portal, L3 Management |
| Certificates: | CE, FCC, RoHS |
| Operating Temperature: | 0–50 °C (32–122 °F) |
| Storage Temperature: | -40–70 °C (-40–158 °F) |
| Operating Humidity: | 10–90% RH non-condensing |
| Storage Humidity: | 5–90% RH non-condensing |
Scope of Delivery
| 1 x TP-Link OC300 Omada Hardware Controller |
| 1 x Power Adapter |
| 1 x Rackmount Kit |
| 1 x Quick Start Guide |
Frequently Asked Questions (FAQ)
What is the difference between the TP-Link OC200 and OC300?
The main difference lies in performance and scalability. The OC300 features a faster processor, more RAM, Gigabit Ethernet ports (unlike the 100 Mbps ports of the OC200), and can manage up to 500 Access Points (vs. 100 for the OC200). Additionally, the OC300 is designed for 19-Inch Rack mounting, while the OC200 is a smaller desktop device.
Do I need an Omada Controller to operate TP-Link Access Points?
No, Omada Access Points can also be configured and operated individually in 'standalone mode'. However, a Controller is absolutely necessary to utilize central management functions and advanced features such as seamless roaming, a Captive Portal for guests, or managing multiple devices through a single interface.
Are there license fees for the OC300's cloud access?
No, remote access via the Omada Cloud Portal and the Omada App is completely free for managing the OC300 and its connected devices.
Can the OC300 replace a router?
No. The OC300 is purely a controller for network management. It requires a separate router, ideally an Omada-compatible router, for internet access, firewall functions, and IP address assignment (DHCP).
How do I access the OC300's management interface?
Access is done locally by entering the controller's IP address in a web browser on the same network. Alternatively, remote access can be done via the Omada Cloud Portal or the Omada smartphone app after the device has been linked to a TP-Link ID.
What happens to my network if the OC300 fails?
If the OC300 fails, basic network traffic continues to function. The Access Points, Switches, and Routers retain their last applied configuration. However, during the outage, no configuration changes, no monitoring, and no controller-dependent functions such as the Captive Portal or seamless roaming are available.
