One Cable, Full Power: Your Upgrade for Teltonika & QuWireless
No more unnecessary cable clutter! The QuWireless QuPSU-GP241E PoE Injector is the ideal solution to efficiently power your Teltonika 4G / 5G Routers in combination with QuWireless Antennas (such as QuSpot, QuMax, QuMini) with power and data. Imagine needing only a single Ethernet Cable to operate your outdoor devices. This not only saves time during installation but also minimizes potential sources of error. This injector is specifically designed for a seamless 'plug-and-play' experience, allowing you to focus on what matters most: a stable and fast connection.
Gigabit Speed that Your 4G / 5G Routers Will Love
In today's world, where 4G / 5G Routers are becoming increasingly powerful, fast data transfer is essential. Many conventional PoE injectors slow down modern routers with only 100 Mbps. Not so the QuWireless QuPSU-GP241E! With full Gigabit speed (1000 Mbps), it ensures that your high-speed applications are not hindered by the injector. Whether you are transferring large amounts of data or relying on extremely low latency – this injector delivers the performance you need.
Safety That Counts: Overvoltage Protection & Grounding for Your Outdoor Devices
Even though the QuWireless QuPSU-GP241E itself is designed for indoor use, it often powers devices exposed to wind and weather outdoors. This is where its intelligent features come into play: The integrated Overvoltage Protection and Grounding on the connector are not a gimmick, but crucial safety features. They protect your valuable hardware, especially in outdoor installations, from damage due to electrical overvoltages or static discharges. A small investment in safety that pays off in the long run and saves you headaches. Think about the Lightning Protection for your devices!
Passive PoE 24V: Why it's Perfect for Your Network
The QuWireless QuPSU-GP241E uses passive PoE with 24V. This means it consistently delivers 24V to the end device without performing complex power negotiation beforehand. This simplicity is often an advantage, especially when operating devices such as QuWireless Antennas or certain Teltonika Routers that require precisely this specification. It is important to know that this injector is specifically designed for passive 24V PoE devices and is not compatible with active PoE standards (such as 802.3af/at) or devices requiring 48V. This ensures that your Network functions smoothly.
Strengths & Notes at a Glance
- Pro: Gigabit speed (1000 Mbps) ensures full data transfer rates and prevents bandwidth bottlenecks for modern 4G and 5G Routers.
- Pro: Optimal compatibility and integration, specially developed for QuWireless Antennas and a wide range of Teltonika Routers, offers a seamless 'one-cable-solution' for power and data.
- Pro: Increased safety and easy installation through Overvoltage Protection, Grounding for the connected hardware, and integrated tabs for easy wall mounting.
- Note: For indoor use only – the injector itself is explicitly designed for indoor use ('Indoor use only'), which must be considered during installation planning.
- Note: Passive PoE (24V) – exclusively supports passive 24V PoE and is not compatible with active PoE standards (e.g., 802.3af/at) or devices requiring 48V PoE.
Specifications & Features
| Manufacturer: | QuWireless |
| Model: | QuPSU-GP241E |
| Product Type: | PoE Injector / Passive PoE Power Supply |
| PoE Standard: | Passive PoE 24V |
| Output Voltage: | 24V DC |
| Output Current: | 1A |
| Output Power: | 24 Watt |
| Data Rate: | 10/100/1000 Mbps (Gigabit Ethernet) |
| Ports: | 2x RJ45 (Data In, PoE Out) |
| Compatibility: | QuWireless QuSpot, QuMax, QuMini Antennas; Teltonika RUTX, RUTM, RUT2xx, RUT9xx Series |
| Protection Features: | Overvoltage Protection, Grounding |
| Mounting: | Wall-mountable |
| Area of Use: | For indoor use only ('Indoor use only') |
| EAN: | 5907772035726 |
| Color: | Black |
| Dimensions (L x W x H): | approx. 85 x 45 x 30 mm |
| Weight: | 0.15 kg |
Scope of Delivery
| 1 x QuWireless QuPSU-GP241E Gigabit Passive PoE Injector |
| 1 x Power Cable (EU Plug) |
Frequently Asked Questions (FAQ)
What is a PoE injector and what is it used for?
A PoE injector (Power over Ethernet Injector) is a device that feeds power into a Network via an Ethernet cable to power compatible end devices such as IP Cameras, WiFi Access Points, or routers. This enables data transmission and power supply over a single cable, simplifying installation, especially in locations without power outlets.
Which devices are compatible with the QuWireless QuPSU-GP241E?
The QuWireless QuPSU-GP241E is specifically designed for all QuSpot, QuMax, and QuMini antennas with integrated Gigabit Ethernet Teltonika routers (e.g., RUTX50, RUTM50, RUTX09, RUTX11, RUTX12, RUTX14, RUT2xx, RUT9xx series). It is also compatible with other Gigabit devices that support passive PoE with 24V.
Does the QuWireless QuPSU-GP241E support Gigabit speed?
Yes, the QuWireless QuPSU-GP241E is a Gigabit PoE injector and supports a data rate of 1000 Mbps. This ensures that fast LTE or 5G routers are not slowed down by the injector.
Can the QuWireless QuPSU-GP241E be used outdoors?
No, the QuWireless QuPSU-GP241E is explicitly intended for indoor use only.
What is the difference between passive and active PoE, and why is this important for the QuPSU-GP241E?
Passive PoE, as used by the QuPSU-GP241E, delivers a constant voltage (here 24V) to the end device without prior negotiation of the power supply. Active PoE (e.g., IEEE 802.3af/at), on the other hand, communicates with the end device to negotiate the required voltage and power. For the QuPSU-GP241E, it is important to know that it only works with passive 24V PoE devices and not with active PoE standards or devices that require other voltages (e.g., 48V).
What protection features does the QuWireless QuPSU-GP241E offer for connected devices?
The QuWireless QuPSU-GP241E offers overvoltage protection and grounding at the connector. These functions help protect connected hardware, especially in outdoor installations of antennas and routers, from damage caused by electrical overvoltages and electrostatic discharges.
