Precision for your 5 GHz Components: The GigaEter 13 in Detail
If you are looking for a reliable and straightforward solution to set up a 5 GHz Directional Antennas for point-to-point connections, the Cyberbajt GigaEter 13 is the perfect choice. This passive panel Antennas was specifically designed as a client Antennas (CPE) to significantly improve signal quality over short to medium distances. With its precise 33° beamwidth, it effectively filters out interference signals from the environment and concentrates transmit and receive power exactly where it is needed. The result is a more stable connection, fewer disconnections, and noticeably higher data throughput.
Compact Design Meets Robust Outdoor Performance
Don't be fooled by its compact dimensions. The GigaEter 13 is a thoroughly weatherproof WiFi Antennas with 13dBi. The housing (radome) is made of UV-resistant ABS plastic, which will not become brittle even after years of direct sunlight. The solid galvanized steel bracket and aluminum backplate ensure maximum stability, even with high wind loads of up to 201 km/h. With a total weight of under 500 grams, installation is easily possible even on less massive masts or directly on a house wall.
Installation and Compatibility: Flexible and Uncomplicated
The GigaEter 13 is designed as a passive component and does not require its own Power Supply. It is connected directly to the external Antennas port of your WiFi Routers or WiFi Access Points via a coaxial cable. Thanks to the standardized N-female connector, you can use high-quality, low-loss Antenna Cables and have maximum flexibility. As one of the most proven 5 GHz Directional Antennas in its class, it is the ideal complement for many radio devices, for example as a passive panel Antennas for MikroTik Routers, and can be quickly and securely attached to any mast thanks to the included clamp.
Strengths & Notes at a Glance
- Pro: High signal quality and interference immunity over short to medium distances.
- Pro: Very compact, lightweight, and discreet design with minimal wind load.
- Pro: Robust, weatherproof construction for a long Service life in outdoor use.
- Pro: Universal N-connector for broad compatibility with 5 GHz Components radio devices.
- Note: As a single-polarity Antennas, not suitable for 2x2 MIMO applications (the Duo variant is required for this).
- Note: The narrow beamwidth requires precise and careful alignment with the opposing station.
Specifications & Features
| Manufacturer: | Cyberbajt |
| Model: | GigaEter 13 |
| EAN / GTIN: | 5907776046070 |
| Manufacturer Part Number (MPN): | GigaEter 13 |
| Shop SKU: | ART1385 |
| Antennas Type: | Panel 5 GHz Directional Antennas / Patch Array |
| Technology: | Microstrip Technology |
| Frequency Range: | 5.45 - 5.75 GHz |
| Supported WiFi Standards: | IEEE 802.11a / 802.11n / 802.11ac |
| Antennas Gain: | 13 dBi |
| Polarization: | Linear: Vertical or Horizontal (depending on mounting) |
| Beamwidth (-3dB), horizontal: | 33° |
| Beamwidth (-3dB), vertical: | 33° |
| VSWR (Voltage Standing Wave Ratio): | ≤ 1.5:1 |
| Impedance: | 50 Ohm |
| Connector: | N-Female |
| Protection against static discharge: | DC Short Circuit (DC Ground) |
| Radome Material: | UV-resistant ABS Plastic |
| Backplate Material: | Aluminum |
| Bracket Material: | Galvanized Steel |
| Dimensions (Antennas only): | 140 x 123 x 17 mm |
| Weight (Antennas only): | 147 g |
| Total Weight (with bracket): | 441 g |
| Maximum Wind Load: | 56 m/s (approx. 201 km/h) |
| Suitable Mast Diameter: | 38 - 51 mm |
| Application Area: | Outdoor & Indoor |
| Manufacturer Warranty: | 36 Months |
Scope of Delivery
| 1 x Cyberbajt GigaEter 13 Antennas |
| 1 x Mast/Wall Mount including Pipe Clamp |
Frequently Asked Questions (FAQ)
What range can I expect from the Cyberbajt GigaEter 13 Antenna?
The range heavily depends on the transmit power of the connected device, line of sight, and environmental interference. Realistically, this 5 GHz Directional Antenna is designed for stable connections over distances of a few hundred meters up to a few kilometers under optimal conditions, making it ideal for short point-to-point 5 GHz Antennas connections within a Network.
Can I use this antenna to improve my WiFi signal throughout the house?
No, it is unsuitable for that. As a directional antenna, it focuses the signal in a specific direction. For comprehensive coverage, omni-directional Antennas, such as 5 GHz Omni-Directional Antennas, or Mesh WiFi systems with WiFi Access Points are the correct choice, rather than trying to boost a WiFi Router with this type of WiFi Antennas.
Is the antenna compatible with a 2.4 GHz router?
No, this Antenna is exclusively optimized for the 5 GHz frequency band (5.45 - 5.75 GHz). Operating it with a 2.4 GHz router or other 2.4 GHz Components would lead to extremely poor performance, as it is designed for 5 GHz Components.
What does 'passive antenna' mean, and does it require power?
'Passive' means that the Antenna does not contain electronic components for signal amplification and therefore does not require its own Power Supply. It focuses and radiates the signal from the connected radio device, unlike devices that might need PoE Injectors / Power Supplies.
Which cable do I need to connect the antenna?
You need a Coaxial Cable with an N-Male connector for the antenna side. The connection on the WiFi Router is often an RP-SMA or SMA connector. Use the shortest possible, low-loss WiFi Antenna Cables, possibly with Coaxial Pigtails, Coaxial Adapters, or Coaxial Connectors, to ensure optimal signal integrity.
Can I use two of these antennas for a point-to-point connection?
Yes, this is a typical application for these Antennas. For a stable Network connection, the 5 GHz Antennas must be precisely aligned with each other. Depending on the environment, different polarization (horizontal/vertical) per antenna can be advantageous, often facilitated by robust Mounting Systems.
