Precision and Power: Your 23dBi Directional Antenna for 5 GHz
If you are looking for an uncompromising solution for a stable long-range wireless connection, the Cyberbajt GigaEter 23 is the answer. This passive Antenna is not ordinary Accessories, but a specialized tool to get the most out of your 5 GHz Network. With a massive Antenna gain of 23 dBi and an extremely focused beamwidth of only 10°, you build an extremely low-interference and powerful connection to a remote station. Whether as a classic point-to-point WiFi Antenna 23dBi or as a Client Antenna (CPE) – the GigaEter 23 delivers superior signal quality where Others have long given up.
Built to Last: Robustness Meets Performance
The GigaEter 23 is designed as a weatherproof Panel Antenna for 5 GHz bridge and developed for years of outdoor use under the harshest conditions. The cover (radome) is made of UV-stable ABS plastic that does not yellow or become brittle. The internal aluminum reflector ensures maximum efficiency. The entire system is designed to withstand wind speeds of up to 306 km/h. The professional N-connector is also weatherproof and ensures a low-loss connection to your radio module. Additionally, the integrated DC Ground Lightning Protection protects your sensitive electronics from static charges.
Easy Installation, Demanding Alignment
Included in the delivery, you will find everything you need for secure pole mounting. The robust bracket with U-bolts fits all common masts with a diameter of 38 to 51 mm and allows for precise tilt adjustment. Note, however: The enormous performance of this Directional Antenna requires very precise alignment. The narrow 10° beam forgives no errors. So take your time for adjustment – the result will reward you with an extremely stable and fast connection.
Strengths & Notes at a Glance
- Pro: Excellent 23 dBi gain for maximum range and signal stability.
- Pro: Extremely narrow beamwidth minimizes interference from other Networks.
- Pro: Very robust and durable construction from UV-stable ABS and aluminum.
- Pro: Enormous wind stability up to 306 km/h for exposed mounting locations.
- Pro: Integrated Lightning Protection (DC Ground) to protect connected devices.
- Note: The narrow beamwidth requires extremely precise and stable alignment to the remote station.
- Note: As an Antenna with only one connector, it is not suitable for MIMO systems.
Specifications & Features
| Manufacturer: | Cyberbajt |
| Model: | GigaEter 23 |
| EAN: | 5907776046155 |
| Manufacturer Part Number (MPN): | GigaEter 23 |
| Product Type: | Passive, directional Panel Antenna |
| Technology: | Microwave Microstrip |
| Frequency Range: | 5.1 GHz - 5.9 GHz |
| Antenna Gain: | 23 dBi |
| Polarization: | Linear (Horizontal or Vertical, depending on mounting) |
| Beamwidth (-3dB), horizontal: | 10° |
| Beamwidth (-3dB), vertical: | 10° |
| VSWR (Standing Wave Ratio): | < 1.4 |
| Impedance: | 50 Ohm |
| Connector: | 1x N-Female |
| Lightning Protection: | DC Ground (Direct Current Short Circuit) |
| Radome Material (Cover): | UV-resistant ABS Plastic |
| Reflector Material: | Aluminum |
| Maximum Wind Load: | 85 m/s (approx. 306 km/h) |
| Dimensions (W x H): | 390 x 430 mm |
| Weight (with bracket): | 1800 g |
| Mounting: | Pole Mounting |
| Supported Pole Diameter: | 38 mm - 51 mm |
| Tilt Adjustment: | Yes, via included bracket |
Scope of Delivery
| 1 x Cyberbajt GigaEter 23 Panel Antenna |
| 1 x Robust Pole Mount including U-bolts and tilt adjustment |
Frequently Asked Questions (FAQ)
Is the Cyberbajt GigaEter 23 a WiFi Router?
No, the GigaEter 23 is a passive antenna. It requires a separate WiFi Router, WiFi Access Point, or a WiFi Bridge Set with an external N-connector to send or receive a signal. It merely improves the range and signal quality of that device.
What distance is the GigaEter 23 Antenna suitable for?
The maximum distance depends on many factors, such as the transmitting power of the radio device, the antenna of the remote station, and especially a clear line-of-sight. Thanks to its high gain of 23 dBi, connections over several kilometers are possible under ideal conditions.
Can I use this antenna for my 2.4 GHz WiFi at home?
What does 'horizontal or vertical polarization' mean?
Polarization describes the oscillation plane of radio waves. For this antenna, polarization is determined by its mounting: horizontally mounted for horizontal polarization, vertically mounted for vertical polarization. For an optimal connection, both Antennas of a radio bridge must have the same polarization.
Is the Mounting Systems material included?
Yes, a robust mast bracket including U-bolts for masts with a diameter of 38 to 51 mm is included. This bracket also allows for tilt adjustment, making it a key piece of Antenna Mounting Accessories.
What is the difference between the GigaEter 23 and the GigaEter 23 Econo?
The 'Econo' version is a lighter and more compact alternative. It has smaller dimensions (300x300 mm vs. 390x430 mm) and a lower weight. Although the Antenna gain is identical at 23 dBi, the standard version might offer slightly better performance due to its larger surface area.
