This coaxial antenna cable of type H-155 in Twin/Dual configuration is a low-loss, flexible, and cost-effective antenna cable. Due to its low attenuation (double shielding), the cable is highly suitable for 4G and 5G frequency bands. This coaxial cable is specifically designed for use as an extension or connection cable between an 4G or 5G antenna and a corresponding LTE/5G router.
With our cable configurator, you can customize your desired connection or extension cable. We provide you with a selection of commonly used connectors.
Simply select the desired length and connectors at the top of the page. The cable will be hand-assembled by us and delivered ready for use, so you can put it into operation immediately.
Note: Please note the separate right of withdrawal applicable to this item. This is an individually manufactured item made according to customer specifications and is excluded from withdrawal.
Technical Data:
| Cable Type: | H155 TWIN Coaxial Cable |
| Impedance: | 50 Ohm |
| Attenuation: | 0.21dB/m @ 900 MHz 0.42dB/m @ 1800 MHz 0.48db/m @ 2400 MHz |
| Capacity: | 82pF/m |
| Inner Conductor: | 19 x 0.28mm Copper Wire |
| Insulation: | 3.9mm PE |
| Outer Sheath: | PVC |
| Outer Diameter: | 5.4mm |
| Bending Radius: | 35mm |
| Color: | Black |
Scope of Delivery:
| Coaxial Antenna Cable H155 TWIN in selected length and connector combination |
