4K Brilliance Meets Unrivaled Night Vision
The G6 PRO Dome is not just another 4K camera. Its core is an exceptionally large 1/1.2-inch CMOS sensor, which, in combination with a fast ƒ/1.5 aperture, enables superior performance in low light conditions. The result: You get clear, low-noise, and colored images even at dusk or with minimal lighting, while Other Cameras have long since switched to black and white mode. The adaptive IR LED illumination with a range of up to 40 meters also ensures perfect illumination in absolute darkness.
Intelligent AI Recognition Directly on the Camera
Forget countless false alarms. The G6 PRO Dome features a powerful 'Multi-TOPS AI Engine' that performs complex analyses directly on the device. This on-board AI analysis precisely recognizes people, vehicles, and even animals. Furthermore, advanced functions such as face and license plate recognition enable detailed and efficient event searching. Since processing takes place directly on the camera, your Network Video Recorder is relieved, and you receive notifications faster and more reliably than ever before.
Optical Zoom and Extreme Robustness for Professionals
Where digital zoom reaches its limits, the G6 PRO Dome plays to its strengths. With the motorized, lossless optical zoom (2.36x), you can magnify distant objects like faces or license plates without any loss of quality. This technical finesse is paired with an extremely durable construction. The aluminum alloy housing is not only protected against dust and strong water jets according to IP66, but also certified according to IK10 – the highest level for vandal protection. This camera is built to last.
Seamless Integration into your UniFi Protect System
This camera was specifically developed for perfect collaboration with UniFi Protect software. Setup and management are child's play and fully integrated into the familiar UniFi interface. All your IP Cameras are centrally managed, recordings are securely stored, and intelligent events are clearly displayed. Please note that a PoE+-capable UniFi Switch or a corresponding PoE Injectors / Power Supplies is required for operation. The camera is exclusively designed for the UniFi Protect ecosystem and does not support standards like ONVIF for integration into third-party systems.
Strengths & Notes at a Glance
- Pro: Superior image quality in low light conditions thanks to a massive 1/1.2' sensor.
- Pro: Lossless 2.36x optical zoom for maximum detail recognition at a distance.
- Pro: Extremely robust with IP66 weather protection and the highest IK10 vandal protection class.
- Pro: Powerful on-board AI for precise recognition of people, vehicles, faces, and license plates.
- Note: Absolutely requires a PoE+ (802.3at) capable Switch-Port; standard PoE is not sufficient.
- Note: Exclusively compatible with the Ubiquiti UniFi Protect System; no support for third-party NVRs.
Specifications & Features
| Manufacturer: | Ubiquiti |
| Model: | UniFi Video Camera G6 PRO Dome |
| MPN: | UVC-G6-PRO-DOME-W |
| EAN / GTIN: | 0810177163268 |
| Shop SKU: | ART1098 |
| Optics & Sensor | |
| Sensor: | 1/1.2' CMOS Sensor |
| Sensor Resolution: | 8 Megapixel |
| Lens: | Motorized Varifocal Lens |
| Focal Length: | F 5.9 mm to 13.8 mm |
| Aperture: | ƒ/1.5 to ƒ/2.9 (variable) |
| Zoom: | 2.36x optical zoom |
| Field of View (Wide Angle): | Horizontal: 113.8°, Vertical: 61.9°, Diagonal: 134° |
| Field of View (Tele): | Horizontal: 45.5°, Vertical: 25.8°, Diagonal: 52° |
| Night Vision Mode: | Integrated adaptive IR LEDs with automatic IR cut filter |
| IR Range: | Up to 40 meters |
| Video & Audio | |
| Max Resolution: | 3840 x 2160 (4K UHD) |
| Aspect Ratio: | 16:9 |
| Max Frame Rate: | 30 FPS |
| Image Settings: | Color, Brightness, Sharpness, Contrast, White Balance, Exposure Control, 2DNR, 3DNR, NR by motion, Masking, Text Overlay, HDR |
| Audio: | Integrated Microphone |
| Hardware & Performance | |
| Processor: | Quad-Core Arm® Cortex®-A53 based chip |
| AI Engine: | Multi-TOPS AI Engine |
| Network Interface: | 1x Gigabit Ethernet RJ45 Port (10/100/1000Base-T) |
| Power Supply: | PoE+ (Power over Ethernet Plus) |
| PoE Standard: | IEEE 802.3at |
| Supported Voltage Range: | 42.5–57 V DC |
| Max Power Consumption: | 15 W |
| Storage Expansion: | microSD card slot (for Edge Recording) |
| Button: | 1x Reset Button (Factory Settings) |
| Physical Characteristics | |
| Housing Materials: | Aluminum alloy, Polycarbonate |
| Mounting Material: | Stainless steel |
| Dimensions: | Ø 163.8 × 108.8 mm |
| Weight: | 1.2 kg |
| Weather Protection Class: | IP66 |
| Vandalism Protection: | IK10 |
| Operating Temperature: | -20 °C to 50 °C |
| Operating Humidity: | 0 to 90 % (non-condensing) |
| Software & Features | |
| Software Integration: | UniFi Protect |
| Intelligent Detection: | People, Vehicles, Animals, Faces, License Plates |
| Certifications: | CE, FCC, IC |
| Compliance: | NDAA Compliant |
Scope of Delivery
| 1 x Ubiquiti UniFi Video Camera G6 PRO Dome |
Frequently Asked Questions (FAQ)
Does the UVC-G6-PRO-DOME require a separate Power Supply?
No, the camera is powered via Power over Ethernet Plus (PoE+). You only need a single Ethernet Cable connected to a PoE+-enabled Network Switch or PoE Injector / Power Supply to deliver both data and power.
Can I install the G6 Pro Dome outdoors?
Yes, absolutely. The camera is IP66 weatherproof and designed for outdoor use. It is protected against dust and strong water jets. An optional 'Weather Shield' is available for additional protection against weather influences.
What is the main difference between the G6 Pro Dome and the regular G6 Dome?
The G6 Pro Dome features three significant improvements: a significantly larger 1/1.2-inch image sensor for better low-light performance, a 2.36x optical zoom, and a greater IR range of 40 meters.
Does this camera work with my Synology Surveillance Station or another NVR?
No, the UniFi G6 Pro Dome is exclusively designed for use with Ubiquiti Networks' UniFi Protect software. It does not support third-party NVRs via standards like ONVIF or RTSP.
What does IK10 certification mean?
IK10 is the highest level of impact resistance classification. It means the camera's housing can withstand an impact of 20 joules, making it extremely resistant to vandalism.
Can the camera record without an internet connection?
Yes. Thanks to the integrated microSD card slot, the camera can store recordings locally ('Edge Recording') if the connection to the UniFi Protect NVR is interrupted. Once the connection is restored, the recordings are synchronized.
