Ubiquiti U7-Pro: The Dawn of a New Era
WiFi 6 was fast, but WiFi 7 changes the game completely.
The U7-Pro is Ubiquiti's answer to the extreme data hunger of modern applications. It utilizes the full spectrum (2.4, 5, and 6 GHz) to minimize latency and deliver data rates previously only known from fiber optic cables.
Performance Without Compromise: 9.3 Gbps
The numbers speak for themselves. The U7-Pro is designed to supply hundreds of devices simultaneously with high-speed internet. When you sum up all frequency bands, you reach a theoretical air capacity of **9.3 Gbps**:
* 6 GHz Band: Up to 5,765 Mbps – the free lane for the latest laptops and smartphones (WiFi 7/6E) using massive 320 MHz channel width.
* 5 GHz Band: Up to 2,882 Mbps – the turbo for your WiFi 6 and 5 devices.
* 2.4 GHz Band: Up to 688 Mbps – solid basic coverage for IoT and older hardware.
Important: The Right Switch
This Access Point has so much power under the hood that a standard Gigabit port would slow it down.
The U7-Pro features a 2.5 GbE Uplink Port. To unleash its full potential, you should ideally connect it to a switch that also offers 2.5G ports and PoE+ (802.3at) (e.g., the UniFi Enterprise Switch or Pro Max). It works on 1G ports too, but then you're driving a sports car in second gear.
Detailed Technical Data
| General & Mechanical | |
| Manufacturer / Model: | Ubiquiti / U7-Pro |
| Dimensions: | Ø 206 x 46 mm |
| Weight: | 680 g |
| Enclosure Material: | Polycarbonate, Metal |
| Mounting: | Wall or Ceiling (Bracket included) |
| Operating Temperature: | -30°C to +60°C |
| Hardware & Connectivity | |
| Network Interface: | 1x 1/2.5 GbE RJ45 Port |
| Power Supply: | PoE+ (802.3at) |
| Power Consumption: | Max. 21 Watt |
| LED: | White / Blue (Ring status) |
| WiFi Specifications | |
| WiFi Standards: | 802.11a/b/g/n/ac/ax/be (WiFi 7) |
| Total Throughput: | 9.3 Gbps (Aggregate) |
| Frequency Bands: | 2.4 GHz / 5 GHz / 6 GHz |
| MIMO Configuration: | 2.4 GHz: 2x2 5 GHz: 2x2 6 GHz: 2x2 |
| Antenna Gain: | 2.4 GHz: 4.0 dBi 5 GHz: 6.0 dBi 6 GHz: 5.8 dBi |
| Max. Throughput Rate: | 2.4 GHz: 688 Mbps 5 GHz: 2882 Mbps 6 GHz: 5765 Mbps |
| TX Power: | 2.4 GHz: 22 dBm 5 GHz: 26 dBm 6 GHz: 23 dBm |
| Channel Widths: | 2.4 GHz: 20, 40 MHz 5 GHz: 20, 40, 80, 160 MHz 6 GHz: 20, 40, 80, 160, 240, 320 MHz |
| Software & Features | |
| Security: | WPA-PSK, WPA-Enterprise (WPA2/WPA3) |
| BSSID: | Up to 8 per radio |
| VLAN: | 802.1Q |
| Client Isolation: | Supported |
| Concurrent Clients: | 300+ |
Scope of Delivery
| 1 x Ubiquiti U7-Pro Access Point |
| 1 x Mounting Plate (Metal) for Ceiling/Wall |
| 1 x Screw Kit & Anchors |
| Note: PoE Injector is NOT included (order separately)! |
