The Problem: Complicated Network Power Supply?
You're familiar with the scenario: Installing network devices like access points or surveillance cameras often presents the challenge of supplying both network connectivity and power. This results in unsightly cable clutter, extra power strips, and increased installation complexity. Particularly in areas with limited power outlets, device placement becomes a significant obstacle.
The Solution: Simplicity and Efficiency with PoE
The Ubiquiti U-POE-AF PoE Injector elegantly and efficiently resolves this issue. It enables you to power compatible devices with both data and electricity via a single Ethernet cable. This not only drastically simplifies installation but also minimizes cabling requirements, fostering a cleaner, more organized network environment. Position your devices precisely where they're needed, without any power supply compromises.
Details That Impress: Performance and Protection
This PoE Injector provides a stable output of 48V DC at 0.32A, totaling 15.4 Watts of power. It is fully compliant with the IEEE 802.3af Standard, making it perfect for a wide array of Ubiquiti UniFi devices. The integrated Gigabit LAN Port ensures your network performance remains unhindered by the power delivery. Additionally, the U-POE-AF safeguards your valuable equipment with comprehensive protection against overvoltage, peak current, and overcurrent.
Your Advantage: Reliability and Flexibility
With the Ubiquiti U-POE-AF, you're investing in a robust and long-lasting solution that provides maximum flexibility for your network setup. Its simple plug-and-play installation requires no complex configuration, allowing you to get started immediately. Trust in Ubiquiti's renowned quality to ensure a stable and secure power supply for your PoE-enabled devices, whether in the office or at home.
Technical Specifications
| Model: | Ubiquiti U-POE-AF |
| EAN: | 0817882024976 |
| Dimensions (L x W x H): | 86 x 46 x 33 mm (3.39 x 1.81 x 1.30 inches) |
| Weight: | 0.100 kg (100 g) |
| PoE Standard: | IEEE 802.3af |
| Output Voltage: | 48V DC |
| Output Current: | 0.32A |
| Max. PoE Power: | 15.4 Watts |
| Gigabit LAN Port: | Yes |
| LAN Activity Indicator: | No |
| Remote Reset Capability: | No |
| Reset Button: | No |
| Nominal Voltage (Input): | 100—240V AC @ 50/60Hz |
| Input Current: | 500mA Max. |
| Inrush Current: | <100A Peak at 25°C |
| Efficiency: | 84.25+% |
| Output Ripple: | 200mV p-p |
| Operating Temperature: | 0 to 40° C |
| Storage Temperature: | -30 to 70° C |
| Operating Humidity: | 10 to 95% non-condensing |
| Certifications: | CE, FCC, IC, UL |
Package Contents
| 1 x Ubiquiti U-POE-AF PoE Injector |
| 1 x Power Cord (with Ground) |
Häufig gestellte Fragen (FAQ)
Which devices can I power with the Ubiquiti U-POE-AF PoE Injector?
The Ubiquiti U-POE-AF PoE Injector is ideal for all devices that support the IEEE 802.3af PoE standard and require a maximum of 15.4 watts of power. This includes many Ubiquiti UniFi Access Points (such as U6 Lite, U6 Mesh), IP cameras (e.g., UniFi G4 Pro), and VoIP phones. Always check your end device's specifications to ensure compatibility.
Does the U-POE-AF also deliver Gigabit speed?
Yes, absolutely! The Ubiquiti U-POE-AF is equipped with a Gigabit LAN port. This means it can transmit data at speeds of up to 1000 Mbps without compromising your network's performance, while simultaneously providing power.
Is the PoE Injector protected against overvoltage?
Yes, the Ubiquiti U-POE-AF PoE Injector offers comprehensive protection features. It includes integrated overvoltage protection, peak current protection, and overcurrent protection to safeguard both the injector itself and connected devices from electrical damage.
Is software required to configure the U-POE-AF?
No, the Ubiquiti U-POE-AF PoE Injector is a true plug-and-play device. You do not need any additional software or complicated configurations. Simply connect it, and your PoE-enabled devices will immediately receive power and data.
What is the maximum cable length for the U-POE-AF?
For the IEEE 802.3af PoE standard used by the U-POE-AF, the maximum recommended cable length for reliable power and data transmission over an Ethernet cable (Cat5e or higher) is typically 100 meters. This ensures optimal performance and stability for your connected devices.
