384 Watts of PoE+ Power for Your Entire Network
The TP-Link TL-SG3428MP is more than just a distributor – it's the powerhouse of your Network. With a massive total PoE budget of 384 watts and full PoE+ support (802.3at) on all 24 Gigabit ports, you can directly power even power-hungry devices like modern Wi-Fi 6 Access Points, high-resolution IP Cameras, or complete VoIP phone systems directly via the Network cable. This eliminates cable clutter and the need for countless individual power supplies. Each port delivers up to 30 watts, giving you maximum flexibility for your installations.
Central Management with Omada SDN
This JetStream Switch is fully integrated into the TP-Link Omada SDN (Software Defined Networking) platform. This means for you: You can manage the switch, your Access Points, and Routers from a single, intuitive interface – whether via an on-site hardware controller or conveniently via the cloud. Features like Zero-Touch Provisioning enable easy commissioning at new locations without you having to be physically on site. Monitor status, configure settings, and gain important insights into your network, all from a central dashboard.
Intelligent L2+ Features & Static Routing
The TL-SG3428MP is a true Layer 2+ switch with static routing. This means it masters more than just the basics. With static routing, you can divide your network into different segments (VLANs) and route traffic between them directly on the switch. This relieves your router and ensures significantly more efficient communication within the internal network. Together with comprehensive security functions such as Access Control Lists (ACLs), Port Security, Storm Control, and 802.1X authentication, you build a network that is not only fast but also extremely secure.
Flexible Uplinks and Robust Performance
When the amount of data grows, you need a stable connection to the core of your network. The TL-SG3428MP offers you four dedicated 1-Gigabit SFP slots for this. These enable fast and interference-free fiber-optic uplinks to other switches or servers. With an impressive switching capacity of 56 Gbps and a packet forwarding rate of 41.66 Mpps, this Ethernet Switch will never be a bottleneck in your network. It is designed as a reliable network switch for IP Cameras and other bandwidth-intensive applications and delivers consistently high performance.
Strengths & Notes at a Glance
- Pro: Very high PoE power budget of 384W for demanding devices.
- Pro: Seamless integration into the Omada SDN platform for central cloud management.
- Pro: Extensive L2+ functions including static routing for network segmentation.
- Pro: Four dedicated 1G SFP slots for flexible and fast fiber-optic uplinks.
- Note: The two active fans can be loud under load, making the switch unsuitable for noise-sensitive environments (e.g., open-plan offices).
- Note: The abundance of professional functions can be overwhelming for network beginners without training.
Specifications & Features
| Manufacturer: | TP-Link |
| Model: | TL-SG3428MP |
| EAN: | 6935364010737 |
| Product Family: | JetStream |
| Device Type: | Managed L2+ Switch |
| Omada SDN Integration: | Yes, fully integrated |
| Switching Capacity: | 56 Gbps |
| Packet Forwarding Rate: | 41.66 Mpps |
| MAC Address Table: | 16K entries |
| Packet Buffer Memory: | 4.1 Mbit |
| Jumbo Frames: | 9 KB |
| RJ45 Ports: | 24 × 10/100/1000 Mbps |
| SFP Slots: | 4 × 1 Gigabit SFP Slots (dedicated) |
| Console Ports: | 1x RJ45, 1x Micro-USB |
| PoE Standard: | IEEE 802.3af/at (PoE+) |
| PoE+ Ports: | 24 |
| Total PoE Budget: | 384 W |
| Max. Power per Port: | 30 W |
| Management: | Omada SDN, Web-GUI, CLI, SNMP, RMON |
| L3 Features: | Static Routing (48 routes), DHCP Server/Relay |
| Fans: | 2 (actively cooled) |
| Power Supply: | 100-240 V AC, 50/60 Hz (internal) |
| Max. Power Consumption: | 456.4 W (with 384 W PoE load) |
| Dimensions (W x D x H): | 440 × 330 × 44 mm |
| Form Factor: | 1U Rack-mountable, Desktop |
| Operating Temperature: | 0℃ to 45℃ |
Scope of Delivery
| 1 x TP-Link TL-SG3428MP Switch |
| 1 x C13 Power Cable (power cord) |
| 1 x Rackmount Kit |
| 1 x Rubber Feet |
| 1 x Installation Guide |
Frequently Asked Questions (FAQ)
Is the TP-Link TL-SG3428MP a Router?
No, the TL-SG3428MP is a Managed Layer-2+ Switch, not a Router. Its main task is to distribute data traffic and power (PoE) within a local area network (LAN). It has basic routing functions (static routing) to direct traffic between different VLANs, but it does not replace a full-fledged router for internet connection.
Can I use the Switch without the Omada Controller?
Yes, absolutely. The Switch can be operated completely as a standalone device. You can configure and manage it via an intuitive web-based user interface (Web-GUI) or a command-line interface (CLI). The Omada SDN integration is an optional but powerful management option.
What is the actual PoE power I can use?
The total PoE budget is 384 watts. You can power up to 24 devices with PoE, as long as their total consumption does not exceed 384 W. Each individual port can deliver up to 30 watts according to the 802.3at (PoE+) standard.
What does "Layer 2+" (L2+) mean?
L2+ means that the Switch primarily operates on the second layer (data link layer) of the OSI model (MAC address-based), but additionally has some basic functions of the third layer (network layer). For the TL-SG3428MP, this is mainly static routing, which allows the Switch to direct traffic between different IP subnets (VLANs) without the need for an external router.
Are the SFP ports suitable for 10G connections?
No, the four SFP slots of this model are designed for Gigabit speeds (1 Gbps). They are intended for 1G fiber uplinks. For 10G uplinks, you would need to consider another model from the TP-Link JetStream series.
Is the Switch suitable for home use?
Due to its performance, high port count, and PoE budget, it is more designed for small to medium-sized enterprise networks (SMBs), offices, hotels, or demanding "prosumer" home labs. For typical home use, it is oversized and often not ideal due to fan noise.
