Your Upgrade for a Professional Network: The Omada EAP245
Say goodbye to unstable consumer Wi-Fi and take your Network to the next level. The TP-Link EAP245 is more than just a signal booster – it is the heart of a scalable and professionally managed Network. As part of the TP-Link Omada ecosystem, it seamlessly integrates into a central SDN (Software-Defined Networking) platform. This means for you: Zero-Touch Provisioning, intelligent monitoring, and full control over all your WiFi Access Points, Ethernet Switch, and gateways from a single interface – no matter where you are.
AC1750 Speed and MU-MIMO for Maximum Performance
The EAP245 delivers combined speeds of up to 1750 Mbps with the Wi-Fi 5 standard (802.11ac Wave 2). But speed isn't everything. Thanks to 3x3 MU-MIMO technology, the WiFi Access Point can communicate with multiple devices simultaneously, which drastically reduces waiting times and increases overall throughput. Technologies like Beamforming focus the Wi-Fi signal specifically on connected clients, while Band Steering automatically directs devices to the faster 5 GHz band. The result is an extremely powerful WiFi Access Point for many devices, which ensures a stable and fast connection even in demanding environments.
Maximum Flexibility in Installation and Power Supply
No power outlet near the optimal mounting location? No problem! The EAP245 supports both the common 802.3af/at PoE standard and passive PoE. This means you can power it and provide data via a single Ethernet Cable. A suitable Gigabit PoE Injector is even included in the scope of delivery, so you don't have to buy additional PoE Injectors / Power Supplies. With its elegant design and simple mounting kit, it blends inconspicuously into any ceiling or wall and ensures perfect illumination.
Intelligent Management and Seamless Roaming
For its full range of functions, the EAP245 unfolds its potential in conjunction with an Omada Controller. Then it becomes an WiFi Access Point with Seamless Roaming (802.11k/v), which seamlessly hands over your devices to the next WiFi Access Point without dropping the connection – ideal for VoIP calls or video conferences while you move through the building. Features like Airtime Fairness and Load Balancing further optimize Network performance. But even without a controller, the AP can be conveniently configured in standalone mode via its own web interface.
Strengths & Notes at a Glance
- Pro: Offers enterprise features like MU-MIMO and central management at an excellent price-performance ratio.
- Pro: Extremely flexible management options (standalone, software, hardware, or cloud controller).
- Pro: Strong and stable performance thanks to Qualcomm chipset and intelligent Wi-Fi optimizations.
- Pro: Easy installation due to dual PoE support and included PoE adapter.
- Note: Supports the Wi-Fi 5 (802.11ac) standard, not the newer Wi-Fi 6 (802.11ax).
- Note: Full functionality like Seamless Roaming is only available with an Omada Controller.
Specifications & Features
| Manufacturer: | TP-Link |
| Model: | EAP245 |
| EAN: | 6935364096663 |
| Product Class: | AC1750 Wireless MU-MIMO Gigabit Ceiling Mount WiFi Access Point |
| Chipset: | Qualcomm Atheros (QCA) Enterprise-Class |
| RAM: | 128 MB DDR2 |
| Flash Memory: | 16 MB |
| Ports: | 2 x Gigabit Ethernet (RJ-45) Ports |
| Power Supply: | 802.3af/at PoE and 48V Passive PoE |
| Max. Power Consumption: | 12.3 W |
| Wi-Fi Standards: | IEEE 802.11ac/n/g/b/a (Wi-Fi 5) |
| Frequency Bands: | Dual-Band (2.4 GHz and 5 GHz) |
| Max. Data Rate 5 GHz: | Up to 1300 Mbps |
| Max. Data Rate 2.4 GHz: | Up to 450 Mbps |
| Antennas: | 6 x internal Omni-Directional Antennas (3x 4dBi for 2.4GHz, 3x 4dBi for 5GHz) |
| Transmit Power (CE): | <20 dBm (2.4 GHz), <23 dBm (5 GHz) |
| Wi-Fi Features: | 3x3 MU-MIMO, Seamless Roaming (802.11k/v), Omada Mesh, Band Steering, Airtime Fairness, Beamforming, Load Balancing |
| Wi-Fi Security: | WPA/WPA2-Enterprise, WPA/WPA2-PSK, 64/128/152-bit WEP |
| Management: | Omada SDN Platform (Hardware/Software/Cloud Controller), Standalone Mode via Web-Interface, Omada App |
| Guest Network: | Yes, with Captive Portal (SMS, Facebook Wi-Fi, Voucher) |
| SSIDs: | Up to 16 SSIDs (8 per frequency band) |
| Mounting: | Ceiling or Wall Mount (Kit included) |
| Dimensions (W x D x H): | 205.5 x 181.5 x 37.1 mm |
| Operating Temperature: | 0°C to 40°C |
| Certifications: | CE, FCC, RoHS |
Scope of Delivery
| 1 x TP-Link EAP245 AC1750 WiFi Access Point |
| 1 x Passive Gigabit PoE Adapter |
| 1 x Power Cord |
| 1 x Mounting Kit for Ceiling/Wall |
| 1 x Installation Guide |
Frequently Asked Questions (FAQ)
Can the TP-Link EAP245 replace a router?
No, the EAP245 is purely an Access Point. It generates a WiFi signal but does not have router functions such as a DHCP server or NAT. It must be connected by cable to an existing router or switch to function.
Do I absolutely need an Omada Controller for operation?
No, the EAP245 can be operated in 'Standalone Mode' and configured via its own web interface. However, an Omada Controller is required for using central management functions, cloud access, and seamless roaming across multiple APs.
Does the EAP245 support Mesh WiFi?
Yes, the EAP245 is integrated into the Omada SDN system and supports Omada Mesh technology. This allows multiple Access Points to be wirelessly connected to each other to extend range without each AP needing to be cabled.
How is the EAP245 powered?
The Access Point is primarily powered via Power over Ethernet (PoE). It supports both the 802.3af/at standard and 48V passive PoE. A suitable passive Gigabit PoE Injector is included in the scope of delivery.
How many devices can connect simultaneously?
The TP-Link EAP245 is designed for high-density environments. In practice, over 100 clients can easily connect, although performance per client decreases with an increasing number. Some sources state a capacity of over 200 simultaneous clients.
Is the Access Point suitable for outdoor use?
No, the EAP245 is designed exclusively for indoor use. The housing is not weatherproof, and the operating temperature is specified from 0°C to 40°C.
