The Shelly Pro 1PM is a professional, intelligent 1-channel relay switch with integrated power metering, developed specifically for DIN rail mounting. It is the ideal solution for integrating a single electrical device into your smart home while precisely monitoring its energy consumption. Based on the new Gen3 platform with the powerful ESP-Shelly-C38F processor, it is lightning-fast and reliable. It can switch devices with up to 16A and provides you with precise real-time data on power consumption.
The integrated WiFi, LAN, and Bluetooth connectivity makes integration into your network a breeze. You can conveniently control the Shelly Pro 1PM via the Shelly Smart Control App, cloud platforms, or voice assistants and create automated scenarios based on your energy consumption. Thanks to its versatile functions, it is ideal for controlling lighting, sockets, or other devices. With its low self-consumption of less than 3W, it is also an efficient and reliable partner for your home automation.
Technical Data:
| Model: | Shelly Pro 1PM |
| Mounting: | DIN rail |
| Size (HxWxD): | 18.5x89.5x68.5 ±0.5 mm |
| Weight: | approx. 70g |
| Conductor cross-section: | 0.2 to 2.5 mm² / 24 to 14 AWG |
| Stripping length of conductor: | 6 to 7 mm |
| Housing material: | Plastic |
| Color: | Black |
| Ambient temperature: | -20 °C to 40 °C |
| Humidity: | 30 % to 70 % RH |
| Max. altitude: | 2000 m |
| Power supply: | 110-240 VAC, 50/60 Hz |
| Self-consumption: | < 3 W |
| Power measurement: | Yes |
| Max. switching voltage (AC): | 240 V |
| Max. switching current (AC): | 16 A |
| WiFi protocol: | 802.11 b/g/n |
| WiFi frequency band: | 2.4 GHz |
| WiFi radio power: | < 20 dBm |
| Bluetooth protocol: | 4.2 |
| Bluetooth frequency band: | 2.4 GHz |
| Processor: | ESP-Shelly-C38F |
| Flash: | 8 MB |
Scope of Delivery:
| 1x Shelly Pro 1PM |
| 1x Quick start guide |
