An Antenna for All Networks: Your Upgrade for 5G, 4G and More
Stop searching for the best signal. The Panorama DMM-6-60-2SP is a true multi-talent. With its huge frequency range from 617 MHz to 6000 MHz, it not only covers all common 4G and 5G bands in Europe but is also perfectly prepared for future standards and worldwide use. Whether you're surfing in an urban 5G Network or relying on a stable 4G connection in the countryside – this Antenna ensures optimal reception. It is the perfect addition for powerful 4G / 5G Routers and extracts the last bit of performance from your plan.
True 2x2 MIMO Power for Maximum Stability and Speed
Why two cables? Because modern mobile routers use 2x2 MIMO Technology (Multiple Input, Multiple Output) to drastically increase performance. The DMM-6-60-2SP has two separate, highly efficient Antenna elements in one housing. Each cable supplies one element, enabling two parallel data streams to your router. The result is not only a higher download and upload speed but, above all, a significantly more stable and robust connection, even with a weaker signal.
Maximum Flexibility: Your Signal Boost for Home and On the Go
The best reception is often exactly where the router cannot be placed. Panorama has cleverly solved this problem. The DMM-6-60-2SP comes with a complete mounting kit: use the fold-out feet for the desk, the strong suction cup for direct placement on the window, or the clips to attach it directly to the laptop screen. Thanks to its lightweight and flat design, it is the ideal 4G Indoor Antennas solution and an indispensable companion for anyone who needs a reliable internet connection, even in the Yacht / Camper / Motorhome sector.
Plug & Play: Signal Improvement Couldn't Be Easier
Complicated installations are a thing of the past. The DMM-6-60-2SP is a purely passive device – meaning no software, no drivers, no Power Supply. Simply screw the two SMA connectors onto the corresponding jacks of your router, position the antenna optimally, and immediately benefit from a better signal. It is operating system independent and compatible with a variety of devices that support external Antennas.
Strengths & Notes at a Glance
- Pro: Excellent frequency coverage for worldwide 5G/4G use.
- Pro: True 2x2 MIMO performance for higher data rates and stability.
- Pro: Extremely flexible mounting options (table, window, clip).
- Pro: Very compact and portable design, ideal for travel.
- Note: Designed exclusively for indoor use and not weatherproof.
- Note: The permanently installed 2-meter cables may limit placement.
Specifications & Features
| Manufacturer: | Panorama Antennas |
| Model: | DMM-6-60-2SP |
| EAN: | 5055416037930 |
| Device Classification: | Passive Antenna Client |
| Device Type: | Passive 2x2 MIMO Antenna |
| Supported Mobile Networks: | 2G, 3G, 4G, 5G (Sub-6 GHz) |
| Frequency Range Band 1: | 617-960 MHz |
| Frequency Range Band 2: | 1710-6000 MHz |
| Antenna Gain (617–960MHz): | 3 dBi |
| Antenna Gain (1427–2700MHz): | 5 dBi |
| Antenna Gain (3400–6000MHz): | 6 dBi |
| MIMO Capability: | 2x2 MIMO |
| Polarization: | Omnidirectional |
| Impedance: | 50 Ohm |
| VSWR: | < 2.5:1 |
| Maximum Input Power: | 20 Watt |
| Connectors: | 2 x SMA (male) connectors |
| Cable Type: | 2 x RG174 Coaxial Cable (twin) |
| Cable Length: | 2 Meter |
| Dimensions (H x W x D): | 185 mm x 175 mm x 4 mm (without stands) |
| Weight: | approx. 255 g |
| Mounting Options: | Integrated stands, suction cup, screws & adhesive pad |
| Application Area: | Indoor use |
| Operating Temperature: | -40°C to +80°C |
| Certifications: | RoHS, REACH compliant |
| Chipset: | None (passive device) |
| Power Supply: | Not required |
| Compatibility: | Operating system independent |
Scope of Delivery
| 1 x Panorama DMM-6-60-2SP Antenna with integrated stands |
| 1 x Suction cup for window mounting |
| 1 x Set with screws & adhesive pad for wall/laptop mounting |
Frequently Asked Questions (FAQ)
Is the Panorama DMM-6-60-2SP compatible with my Fritz!Box?
Yes, if your Router has two external mobile 4G/5G Antenna ports of the SMA female type. This is the case with many common 4G / 5G Routers. The antenna is brand-independent.
Does this antenna also improve my WiFi signal?
No. This is purely a mobile antenna for 2G, 3G, 4G, and 5G signals. It has no influence on your router's WiFi performance.
What does 2x2 MIMO mean and why are two cables necessary?
2x2 MIMO means that the antenna can send and receive two signals simultaneously. Each cable is connected to a separate antenna element inside. Modern Routers use this technology to significantly increase data rates and connection stability.
How do I align the antenna for the best reception?
Since the antenna is omni-directional, exact alignment is not necessary. For optimal results, you should place it as high as possible and ideally near a window facing the nearest cell tower.
Can I extend the Antenna Cables?
Technically yes, with SMA extension cables. However, it is not recommended, as each additional cable slightly attenuates the signal (damping). Longer Antenna Cables should be high-quality and as short as possible.
Does the antenna require software installation or power?
No. It is a passive plug-and-play device. You simply need to connect the two cables to your Router. No software or Power Supply is required.
