Your Network, Your Rules: The Power of the hEX S
The MikroTik hEX S is more than just a router – it's the command center for your Network. Thanks to the powerful RouterOS operating system, you have full control over every data packet. Create complex firewall rules, segment your Network with VLANs for more security, or set up a fail-safe internet connection with two ports (Multi-WAN). This MikroTik Router is designed for users who are not satisfied with the limitations of standard devices.
Maximum Flexibility: Fiber Optic, PoE, and Gigabit Ports
The hardware features of the hEX S leave nothing to be desired. In addition to five 10/100/1000 Mbit/s Ethernet Ports, it offers a decisive advantage: an SFP-Port. With the appropriate SFP / SFP\+ Modules, you can establish a direct fiber optic connection – ideal for modern FTTH connections. Another highlight is the PoE output on Port 5. It powers another device, making a separate PoE Injector / Power Supply unnecessary. This creates order and simplifies your installation.
RouterOS: The Operating System for Professionals and Ambitious Users
What truly distinguishes the hEX S is its software. RouterOS (license level 4) is an extremely comprehensive operating system that enjoys a legendary reputation in the world of Network technology. Whether you want to set up secure VPN access for your home office, prioritize bandwidth for various applications (QoS), or simply operate an extremely stable and fast network – the hEX S provides the tools for it. Configuration can be done via the web interface, the command line, or the convenient Winbox software.
For Whom is the MikroTik hEX S the Perfect Choice?
This MikroTik Router is aimed at power users, small businesses, and tech enthusiasts looking for a reliable and highly customizable network solution. It is the ideal basis for building a wired network that can later be expanded with separate WiFi Access Points. If you are willing to delve a little into the subject, you will be rewarded with performance and stability that is unparalleled in this price range. It is the perfect alternative to a simple Ethernet Switch when routing functions are required.
Strengths & Notes at a Glance
- Pro: Extreme configurability and functional diversity thanks to RouterOS Level 4.
- Pro: Outstanding price-performance ratio for the hardware power offered.
- Pro: Flexible connectivity options through SFP-Port for fiber optic and PoE output.
- Pro: Compact, fanless, and robust design for silent, reliable operation.
- Note: RouterOS configuration has a steep learning curve and is challenging for absolute beginners.
- Note: The device has no integrated WiFi; an external WiFi Access Point is absolutely necessary.
Specifications & Features
| Manufacturer: | MikroTik |
| Model: | hEX S |
| Product Code: | RB760iGS |
| CPU: | MediaTek MT7621A |
| CPU Architecture: | MMIPS |
| CPU Cores: | 2 |
| CPU Threads: | 4 |
| CPU Clock Frequency: | 880 MHz |
| Switch-Chip Model: | MT7621A |
| RAM: | 256 MB |
| Internal Storage: | 16 MB |
| Storage Type: | FLASH |
| Hardware Encryption: | IPsec Hardware Acceleration (~470 Mbit/s) |
| Gigabit Ethernet Ports: | 5 x 10/100/1000 Mbit/s |
| SFP Port: | 1 x 1.25 Gbit/s SFP |
| USB Port: | 1 x USB 2.0 Type A |
| MicroSD Slot: | Yes, 1x |
| PoE-In: | On Port 1 (Ether1) |
| PoE-In Standards: | 802.3af/at, Passive PoE |
| PoE-In Voltage: | 12-57 V |
| PoE-Out: | On Port 5 (Ether5), passive PoE only |
| PoE-Out Max. Current per Port: | 500 mA |
| PoE-Out Max. Total Current: | 500 mA |
| Operating System: | MikroTik RouterOS |
| RouterOS License: | Level 4 |
| Number of DC Inputs: | 2 (DC jack, PoE-IN) |
| Voltage (DC Jack): | 12-57 V |
| Max. Power Consumption (without PoE-Out): | 6 W |
| Max. Power Consumption (total): | 24 W |
| Dimensions: | 113 x 89 x 28 mm |
| Cooling: | Passive (fanless) |
| Tested Ambient Temperature: | -40°C to 70°C |
| MTBF: | approx. 100,000 hours at 25°C |
| Hardware Monitoring: | PCB Temperature, Voltage |
| Certificates: | CE, EAC, ROHS |
| EAN: | 4251028602783 |
Scope of Delivery
| 1 x MikroTik hEX S (RB760iGS) Router |
| 1 x 24V 1.2A Power Supply |
Frequently Asked Questions (FAQ)
Can the MikroTik hEX S fully utilize a 1-Gbit/s internet connection?
Yes, with its 880 MHz dual-core CPU, the hEX S is capable of fully utilizing a Gigabit internet connection for standard routing and firewall configurations. However, throughput may decrease with very complex rules or intensive VPN usage, impacting your overall Network performance. This MikroTik Router is designed for robust performance.
What can I do with the SFP port on the hEX S?
The 1.25-Gbit/s SFP port allows direct connection of a fiber optic cable via a suitable SFP / SFP+ Module. This is ideal for FTTH (Fiber-to-the-Home) connections to replace the internet provider's media converter, or to establish a fast fiber connection to another Ethernet Switch. This enhances your Network Cabling options with MikroTik Routers.
Which device can I power via the PoE-Out port?
The PoE output on Port 5 provides passive Power over Ethernet. The output voltage matches the router's input voltage. It can power devices such as WiFi Access Points or IP Cameras that support passive PoE with the corresponding voltage. This is a convenient feature for your Network setup, utilizing PoE Injectors / Power Supplies.
Is the MikroTik hEX S suitable for beginners?
For absolute Network beginners, the hEX S is only conditionally suitable. While a basic configuration is possible, utilizing the advanced functions requires learning time and fundamental Network understanding. MikroTik Routers offer extensive capabilities, but some features require familiarity with Network concepts.
Do I need a separate license for the hEX S?
No, the device comes with a pre-installed RouterOS Level 4 license. No additional costs are necessary for the software or its extensive features. The license is valid for the lifetime of the device, making MikroTik Routers a cost-effective solution for your Network.
Can I use the hEX S as a VPN server for my home Network?
Yes, absolutely. RouterOS supports a variety of VPN protocols such as IPsec, L2TP, OpenVPN, and WireGuard. The hEX S features hardware acceleration for IPsec, making it a very capable VPN solution for secure remote access to your home Network. This MikroTik Router is excellent for enhancing your Network security.
