Your 10G Gateway: The RB4011iGS+RM in Detail
If your Network needs to do more, the MikroTik RB4011iGS+RM is the answer. This powerhouse is designed to excel as a central hub in small to medium-sized business environments (SMBs) or in your ambitious Home Lab. The combination of a powerful Annapurna Quad-Core processor and 1 GB RAM ensures that everything runs smoothly, even with many simultaneous connections and complex firewall rules. The 10G SFP+ Port is the absolute highlight and makes this MikroTik Router future-proof. It allows you to directly connect to fiber optic internet or establish a high-speed connection to a central Ethernet Switch, utilizing SFP / SFP\+ Modules, making Network bottlenecks a thing of the past.
RouterOS: Limitless Control for Your Network
The heart of every MikroTik Router is the RouterOS operating system with license level 5. Forget the limited interfaces of consumer devices. With RouterOS, you dive deep into the matter and configure every aspect of your Network down to the smallest detail. Easily set up VLANs to logically separate your Networks, use dynamic routing protocols like OSPF or BGP, and build extremely high-performance VPN tunnels thanks to hardware-accelerated IPsec. Whether you manage a complex corporate Network or simply want full control – RouterOS provides you with the tools you need as a professional.
Built for Performance: Hardware That Convinces
The RB4011iGS+RM is housed in a solid, matte black metal casing that not only looks good but also ensures optimal passive cooling. Since the Router operates completely without fans, it is absolutely silent. This makes it the perfect choice for use in the office or home study. With the included mounting brackets, it can also be neatly installed in a 1U 19-Inch Rack space, part of comprehensive Mounting Systems. The ten Gigabit Ethernet Ports are cleverly divided internally into two Switch-chips to ensure maximum throughput to the CPU. This well-thought-out design makes the RB4011iGS+RM one of the most reliable devices in its class.
Pure Flexibility: Ports and PoE Options
Versatility is key. The RB4011iGS+RM offers you not only high port density but also flexible Power Supply options. You can power it via the classic DC barrel jack or, alternatively, via Passive PoE on Port 1. The best part: A PoE output is available on Port 10, allowing you to power another device – for example, a WiFi Access Point or an IP Camera – directly via the Network Cabling. This saves an additional Power Supply and significantly simplifies Cabling. This Router is a prime example of a modern and flexible MikroTik Router that integrates seamlessly into any professional Network.
Strengths & Notes at a Glance
- Pro: Excellent price-performance ratio with enterprise features.
- Pro: High performance thanks to Quad-Core CPU, 1 GB RAM, and 10G SFP+ Port, supporting SFP / SFP\+ Modules.
- Pro: Extremely customizable and stable RouterOS for full Network control.
- Pro: Robust, fanless design for absolutely silent operation.
- Pro: High connectivity with 10 Gigabit Ethernet Ports and flexible PoE options, using PoE Injectors / Power Supplies.
- Note: The complexity of RouterOS presents a steep learning curve for beginners.
- Note: The SFP+ Port has specific compatibility requirements (no passive DAC Cable, no 1G copper modules).
Specifications & Features
| Manufacturer: | MikroTik |
| Model: | RB4011iGS+RM |
| Product Code: | RB4011iGS+RM |
| EAN: | 4251028602806 / 4752224002730 |
| CPU Model: | Annapurna Labs Alpine AL21400 |
| CPU Architecture: | ARM 32bit |
| CPU Cores: | 4 (Quad-Core) |
| CPU Clock Frequency: | 1.4 GHz |
| RAM: | 1 GB |
| Storage Size: | 512 MB |
| Storage Type: | NAND |
| Hardware Acceleration: | IPsec |
| Operating System: | MikroTik RouterOS |
| RouterOS License Level: | 5 |
| Gigabit Ethernet Ports: | 10 x 10/100/1000 Mbit/s |
| SFP+ Ports: | 1 x 10 Gbit/s |
| Serial Console Port: | 1 x RJ45 |
| PoE Input: | Yes, on Port 1 (Passive PoE) |
| PoE Input Voltage: | 18-57 V |
| PoE Output: | Yes, on Port 10 (Passive PoE) |
| Max. Output Current (PoE): | 600 mA (< 30V), 420 mA (> 30V) |
| Max. Total Output (PoE): | 600 mA |
| Number of DC Inputs: | 2 (DC Barrel Jack, PoE-IN) |
| DC Input Voltage: | 12-57 V |
| Max. Power Consumption: | 18 W (without PoE-Out) |
| Max. Power Consumption: | 33 W (with PoE-Out) |
| Included Power Supply: | 24V / 1.5A |
| Cooling: | Passive (fanless) |
| Tested Ambient Temperature: | -40°C to 70°C |
| MTBF: | approx. 200,000 hours at 25°C |
| Dimensions: | 228 x 120 x 30 mm |
| Form Factor: | Desktop / 1U Rackmount (brackets included) for 19-Inch Racks |
| Certifications: | CE, EAC, ROHS |
| Protection Class: | IP20 |
| Monitoring: | PCB Temperature Monitor, Voltage Monitor |
Scope of Delivery
| 1 x MikroTik RB4011iGS+RM Router |
| 1 x 24V 1.5A Power Supply |
| 1 x Rack Mounting Bracket Set for Mounting Systems |
Frequently Asked Questions (FAQ)
Is the MikroTik RB4011iGS+RM suitable for beginners?
No, not really. Due to the complexity of RouterOS, this MikroTik Router is primarily aimed at Network administrators, IT professionals, and tech-savvy power-users, even though basic configurations are possible for the Network.
Does the RB4011iGS+RM have integrated WiFi?
No, this model is a pure Ethernet Switch. For WiFi functionality, a separate WiFi Access Point must be connected to one of the Ethernet ports.
Can I use a 10-Gbit/s internet connection with the RB4011iGS+RM?
Yes, the SFP+ port is specifically designed for this. It allows connection to a fiber optic modem or an Ethernet Switch with 10 Gbit/s and can serve as a gateway for very fast internet connections using SFP / SFP\+ Modules.
Does the MikroTik Router support hardware VPN?
Yes, the AL21400 processor features dedicated hardware acceleration for IPsec encryption. This enables high throughput rates for VPN connections without heavily burdening the CPU, enhancing your Network capabilities.
How is the RB4011iGS+RM powered?
It can be powered in two ways: via the included 24V power supply unit at the DC connection or via Passive PoE (18-57V) on Ethernet Port 1, utilizing PoE Injectors / Power Supplies.
Is the MikroTik Router noisy during operation?
No, the MikroTik Router is completely fanless and passively cooled. It therefore operates completely silently, making it ideal for use in offices or at home, contributing to a quiet Network environment.
