Unleashed Power: Quad-Core CPU and Wi-Fi 6 for your Home Network
The MikroTik hAP ax³ is the powerhouse your Network has been waiting for. At the heart of the device beats a modern 64-bit ARM architecture with a powerful Quad-Core CPU that dynamically clocks up to 1.8 GHz. Paired with a generous 1 GB RAM, this MikroTik Router masters every challenge with flying colors. Whether you want to set up a complex VPN for your home office, define demanding firewall rules, or simply stream in 4K without buffering – the hAP ax³ consistently delivers high performance without breaking a sweat. Thanks to hardware acceleration for IPsec, your secure connections are also lightning-fast.
Full Control: RouterOS – The Pro System Without Limits
What sets the hAP ax³ apart from the crowd is its operating system: RouterOS v7. Here you don't get a stripped-down consumer firmware, but a full-fledged Network operating system with a configuration depth usually only found in the Enterprise segment. Design your Network exactly to your specifications, from advanced routing protocols like BGP and OSPF to detailed Quality-of-Service rules. The best part: all features are unlocked from the start, without additional costs or subscriptions. This Router is a real tool for anyone who wants maximum control and transparency over their network.
Future-Proof Connectivity: With 2.5G Ethernet and USB 3.0
The hAP ax³ is not only fast today, but also ready for tomorrow. The dedicated 2.5-Gigabit Ethernet Port is the perfect input for modern fiber optic connections or connecting a fast NAS system. This is complemented by four additional Gigabit Ethernet Switch Ports for your wired devices. The modern Wi-Fi 6 Standard (802.11ax) ensures a highly efficient and fast WiFi network that remains stable even in households with countless smart devices. Thanks to the USB 3.0 Port, you can also connect a 4G modem as a backup internet connection or set up network storage. This WiFi Router is an investment in the future of your network.
For Power Users and Those Who Want to Become One
This MikroTik Router is aimed at demanding users who want more than just plug-and-play. If you want to improve your WiFi range at home, build a stable VPN, or simply understand what's happening in your Network, the hAP ax³ is ideal. It is the perfect bridge between consumer-friendliness and professional functionality. Even if RouterOS requires some getting used to, you will be rewarded with unparalleled stability and performance. It is more than just a simple WiFi Router; it is a central building block for a smart and powerful home and is among the best MikroTik Access Points & Router on the market.
Strengths & Notes at a Glance
- Pro: Extremely powerful Quad-Core CPU and 1 GB RAM for demanding tasks.
- Pro: Professional RouterOS v7 operating system with endless configuration possibilities.
- Pro: Future-proof connections with Wi-Fi 6, a 2.5G Ethernet-Port, and USB 3.0.
- Pro: Integrated hardware acceleration for IPsec-VPN tunnels.
- Pro: Excellent value for money compared to high-end consumer devices.
- Note: The complexity of RouterOS can be a challenge for absolute network beginners.
- Note: To achieve maximum WiFi performance, manual optimization of settings may be required.
Specifications & Features
| Manufacturer: | MikroTik |
| Model: | hAP ax³ |
| EAN: | 4752224007940 |
| Product Code: | C53UiG+5HPaxD2HPaxD |
| Device Classification: | WiFi Router, WiFi Access Point |
| CPU Architecture: | ARM 64bit |
| CPU Model: | Qualcomm IPQ-6010 |
| Number of CPU Cores: | 4 |
| CPU Clock Frequency: | Automatic (864 - 1800 MHz) |
| Switch Chip Model: | IPQ-6010 |
| RAM: | 1 GB |
| Storage Size: | 128 MB |
| Storage Type: | NAND |
| IPsec Hardware Acceleration: | Yes |
| WiFi Standard: | 802.11ax (Wi-Fi 6), Dual-Band |
| Combined WiFi Speed: | AX1800 |
| WiFi 2.4 GHz Standards: | 802.11b/g/n/ax |
| WiFi 2.4 GHz max. Data Rate: | 574 Mbit/s |
| WiFi 2.4 GHz Chains: | 2 |
| WiFi 2.4 GHz Antenna Gain: | 3.3 dBi |
| WiFi 2.4 GHz Chipset: | Qualcomm QCN-5022 |
| WiFi 5 GHz Standards: | 802.11a/n/ac/ax |
| WiFi 5 GHz max. Data Rate: | 1200 Mbit/s |
| WiFi 5 GHz Chains: | 2 |
| WiFi 5 GHz Antenna Gain: | 5.5 dBi |
| WiFi 5 GHz Chipset: | Qualcomm QCN-5052 |
| External Antenna Connectors: | Yes, 2x RP-SMA Female (2.4 GHz Antennas), 2x RP-SMA Female (5 GHz Antennas) |
| 2.5G Ethernet Ports: | 1 |
| 10/100/1000 Ethernet Ports: | 4 |
| USB Ports: | 1x USB 3.0 Type A |
| Max USB Current: | 1 A |
| USB Power Reset Function: | Yes |
| Number of DC Inputs: | 2 (DC Jack, PoE-IN) |
| DC Jack Voltage: | 12-28 V |
| PoE-In: | Passive PoE |
| PoE-In Input Voltage: | 18-28 V |
| PoE-Out: | Yes, on Port Ether1 (Passive PoE) |
| Max. PoE-Out per Port: | 0.625 A |
| Max. Total PoE-Out Power: | 15 W |
| Max. Power Consumption: | 15 W (without peripherals) |
| Max. Power Consumption (with PoE-Out): | 38 W |
| Operating System: | MikroTik RouterOS v7 |
| RouterOS License Level: | 6 |
| WiFi Encryption: | WPA2, WPA3 |
| Dimensions: | 251 x 130 x 39 mm |
| Tested Ambient Temperature: | -40°C to 70°C |
| MTBF: | approx. 200,000 hours at 25°C |
| Certifications: | CE, FCC, IC, EAC, ROHS |
| IP Protection Class: | IP20 |
Scope of Delivery
| 1 x MikroTik hAP ax³ (C53UiG+5HPaxD2HPaxD) |
| 1 x 24V 1.5A Power Adapter |
| 1 x Stand Base Set |
| 1 x Mounting Kit (Screws) |
Frequently Asked Questions (FAQ)
Is the MikroTik hAP ax³ suitable for beginners?
For absolute Network beginners, the hAP ax³ is only partially suitable. While a basic configuration is possible, the device only unfolds its full potential through the detailed settings in the RouterOS operating system. A certain amount of familiarization and willingness to learn are required for this MikroTik Router.
Can the hAP ax³ power another device via PoE?
Yes, the 2.5G Ethernet port (Ether1) supports passive PoE-Out. It can power another PoE-enabled device, such as an IP Camera or another WiFi Access Point, with up to 15 watts, provided the hAP ax³ itself is powered via the DC jack. This makes it a versatile PoE Injector / Power Supply.
Does the hAP ax³ support WPA3 encryption?
Yes, the hAP ax³ supports the modern and secure WPA3 encryption standard, thus offering a high level of security for the WiFi Network, a key feature for any modern WiFi Router.
What is the main difference between the hAP ax² and the hAP ax³?
The hAP ax³ is the more powerful model. It features a significantly higher-clocked CPU (1.8 GHz), more RAM (1 GB), external Antennas for potentially better range, and a fast USB 3.0 port, which the ax² lacks. These enhancements make it a superior MikroTik Router.
Can I operate the hAP ax³ as a pure Access Point behind another Router?
Yes, absolutely. The hAP ax³ can easily be set to "AP mode" or "Bridge mode". In this configuration, it merely provides the WiFi Network, while another Router handles tasks such as DHCP and routing, effectively functioning as a WiFi Access Point.
What is the real power consumption of the device?
The maximum power consumption is stated as 15 watts without and 38 watts with the use of the PoE output. User reports indicate a real consumption of about 7-8 watts at idle or low load, which is efficient for a device in this performance class, especially considering its PoE Injectors / Power Supplies capabilities.
