Gigabit Speed Without Cables: Your 60 GHz Wireless Link
Imagine being able to Network two buildings as easily as laying a long Ethernet Cable – but without all the hassle. That's exactly what the MikroTik Wireless Wire Cube Pro Set allows you to do. To buy a pre-configured WiFi wireless link means you get an immediately ready-to-use solution that provides a stable Gigabit connection over a distance of up to one kilometer. Thanks to the use of the 60 GHz frequency band, you operate in an area free from the usual interference of overcrowded WiFi Networks. The result is a lightning-fast, low-latency, and secure connection for your Network.
It Couldn't Be Easier: Unpack, Mount, Connect
The biggest advantage of this set is its extreme simplicity. MikroTik has done all the work for you: The two Cube 60Pro ac units are already factory-paired and configured as a transparent Layer 2 bridge. For you, this means: unpack, mount them on a mast or a Mounting System, roughly align them with each other, and power them via the included PoE Injectors / Power Supplies. The connection is established within minutes. It's the perfect building-to-building WiFi Bridge for system integrators, businesses, or demanding private users who want to minimize installation time and costs.
Maximum Reliability Thanks to Automatic 5 GHz Failover
What happens when the weather doesn't cooperate? While 60 GHz connections can reach their limits during extreme heavy rain or snowfall, the Wireless Wire Cube Pro won't let you down. The system features an intelligent, automatic failover function. Should the primary 60 GHz connection be impaired, it seamlessly switches to the integrated 5 GHz backup connection. This keeps your Network online, even if the bandwidth is temporarily reduced. This reliability makes the set one of the most dependable solutions in the category of 60 GHz Components.
Thoughtful Design for Professional Use
Every detail of the Cube Pro has been designed for continuous outdoor use. Its compact and inconspicuous form discreetly blends into the environment. The solid metal base not only provides stable Mounting Systems but also acts as a large heat sink, reliably cooling the quad-core CPU even at high outdoor temperatures. With an operating temperature range of -40°C to +70°C and the proven MikroTik RouterOS, this set from the MikroTik Wireless Systems range is an investment in a durable and low-maintenance Network infrastructure.
Strengths & Notes at a Glance
- Pro: Pre-configured and paired for extremely fast plug-and-play installation.
- Pro: Integrated 5 GHz failover ensures high reliability in bad weather.
- Pro: Interference-free operation in the 60 GHz band with Gigabit speed and low latency.
- Pro: Very robust and weatherproof Enclosures with thoughtful passive cooling.
- Note: The primary 60 GHz connection is susceptible to signal attenuation due to extreme precipitation (Rain Fade).
- Note: An absolutely clear line of sight between the two devices is mandatory.
Specifications & Features
| Manufacturer: | MikroTik |
| Model: | Wireless Wire Cube Pro (CUBEG-5AC60AYPAIR) |
| EAN: | 4752224006967 |
| Manufacturer Part Number (HAN/MPN): | CUBEG-5AC60AYPAIR |
| Product Type: | Pre-configured Point-to-Point Link Set (Wireless Bridge) |
| CPU Architecture: | ARM 32bit |
| CPU Model: | Qualcomm IPQ-4019 |
| CPU Cores: | 4 (Quad-Core) |
| CPU Clock Frequency: | 448 - 896 MHz (Automatic) |
| Random Access Memory (RAM): | 256 MB |
| Storage Size: | 64 MB |
| Storage Type: | FLASH |
| Main Radio Module Frequency: | 60 GHz (57-71 GHz) |
| Main Radio Module Standard: | 802.11ay (backward compatible with 802.11ad) |
| Main Radio Module Chipset: | Qualcomm QCA6438 |
| Main Radio Module Antenna Type: | Phased-Array-System (SWL-QD46) |
| Main Radio Module Beamwidth: | 11° |
| Main Radio Module Max. EIRP: | 40 dBm |
| Backup Radio Module Frequency: | 5 GHz (5150 - 5875 MHz) |
| Backup Radio Module Standard: | 802.11a/n/ac (Wi-Fi 5) |
| Backup Radio Module Chains: | 1 |
| Backup Radio Module Max. Data Rate: | 433 Mbit/s |
| Backup Radio Module Antenna Gain: | 11.5 dBi |
| Backup Radio Module Beamwidth: | 35° |
| Ethernet Ports: | 1x 10/100/1000 Mbit/s Gigabit Ethernet Port |
| Operating System: | MikroTik RouterOS |
| RouterOS License Level: | Level 4 |
| Power Supply: | Power over Ethernet (PoE) |
| PoE Standard: | 802.3af/at & Passive PoE |
| PoE Input Voltage: | 18 - 48 V DC |
| Maximum Power Consumption: | 10 W |
| GPS: | Integrated (Model: MT3337V) |
| Dimensions (per device): | 115 x 95 x 82 mm |
| Operating Temperature: | -40°C to +70°C |
| MTBF: | approx. 200,000 hours at 25°C |
| Certifications: | CE, FCC, IC, EAC, ROHS |
Scope of Delivery
| 2 x Pre-configured Cube 60Pro ac Devices |
| 2 x 24V 0.8A Power Supplies |
| 2 x Gigabit PoE Injectors |
| 2 x Cube Mount Brackets |
| 2 x Hose Clamps |
Frequently Asked Questions (FAQ)
How far does the MikroTik Wireless Wire Cube Pro reach?
The MikroTik Wireless Wire Cube Pro system is designed for stable Network connections up to 1 kilometer. However, in tests and with the use of 'Channel 5' (5 GHz Components), reliable connections could also be established over distances of up to 2.4 kilometers, showcasing the capabilities of MikroTik Wireless Systems.
Is the system complicated to set up?
No, the set is designed as a 'Plug-and-Play' solution. The two units are already factory-paired. You just need to use appropriate Mounting Systems, roughly align them, and provide power via PoE Injectors / Power Supplies to establish a working connection.
Does the connection also work in bad weather like rain or snow?
The primary 60 GHz Components connection can be affected by very heavy rain or snow. In this case, the system has an automatic 5 GHz Components backup connection that maintains the Network connection, albeit at a lower speed.
What is included in the CUBEG-5AC60AYPAIR set?
The set includes two pre-configured Cube 60Pro ac devices, two PoE Injectors, two 24V power supplies, and the necessary Mounting Systems (Cube mount) and hose clamps for mast mounting. These MikroTik Accessories ensure a complete setup.
Can I connect more than two of these devices together?
No, this specific set (CUBEG-5AC60AYPAIR) is designed as a dedicated point-to-point WiFi Bridge Set and consists of two already paired devices. For point-to-multipoint scenarios, MikroTik offers other MikroTik Routers or MikroTik Access Points & Router products.
What speed can I expect in practice?
Under ideal conditions, the 60 GHz Components connection enables a speed close to that of a Gigabit Ethernet Cable (approx. 1 GBit/s full-duplex). The actual speed depends on the distance, alignment, and weather conditions, impacting your overall Network performance.
