Technical Specifications:
| Manufacturer: | Interline |
| Model: | IP-G1010-F2458-HV-M |
| Antenna Type: | Directional Antenna |
| Frequency Range: | 2.4 GHz (IEEE802.11 b/g/n) 5 GHz (IEEE802.11a/n/ac/ax) WiFi 7 |
| Gain: | 2.4GHz: 10dBi 5GHz: 10dBi |
| Impedance: | 50 Ohms |
| VSWR: | max. 1.62 |
| Polarization: | Horizontal / Vertical (Dual-Polarization) |
| Beamwidth: | 45° Horizontal 45° Vertical |
| Front-to-Back Ratio: | min. 25dB |
| XPD (Cross Polarization Discrimination): | min. 18dB |
| Cable / Connector: | 0.9m RG174, RP-SMA female connector |
| Application: | Indoor and Outdoor |
| IP Class: | IP64 |
| Max Wind Load: | 50N (@170km/h) |
| Dimensions: | 22.5cm x 22.5cm x 3.2cm |
| Weight: | 900g incl. Mounting Accessories |
| Color: | White / Gray |
Delivery Contents:
| 1 x Interline IP-G1010-F2458-HV-M Antenna |
| 1 x Mounting Bracket incl. Pipe Clamp |
