Your Network Hub: Central, Clean, Structured
No more Cable chaos in the server cabinet! The Extralink EX.9816 is the heart of your Network infrastructure. As a central distribution point, it bundles all incoming installation cables and makes them accessible via 24 clearly numbered RJ45 ports. From here, you flexibly connect your devices to the Ethernet Switch via patch cables. The result: a professional, easy-to-maintain Network where you always keep track. This 19-Inch Rack 1U unshielded patch panel fits perfectly into any standard network cabinet and ensures a tidy appearance.
Installation Made Easy: CAT6 Performance Without Guesswork
Installing this panel is straightforward, even for beginners. The rear LSA connection strips are clearly marked with the color codes for TIA/EIA 568A and 568B. You just need to choose a standard and terminate the conductors of your CAT6 installation Cable with an LSA punch-down tool. This ensures a secure and standard-compliant connection that guarantees full Gigabit performance. The 24-Port CAT6 UTP Patch Panel is the basis for stable and fast data transmission.
Built to Last: Robust Steel for your Rack
When it comes to Network infrastructure, you shouldn't compromise. That's why the Extralink Patch Panel is made of 1.5 mm thick, cold-rolled, and powder-coated steel. This not only ensures high stability in the 19-Inch Rack but also protects against mechanical impacts. The RJ45 jacks are designed for over 1000 mating cycles, and the contacts are gold-plated to prevent corrosion and ensure minimal contact resistance for years to come.
Unshielded and Uncomplicated: The UTP Solution for Office & Home
This patch panel is designed as a UTP (Unshielded Twisted Pair) variant. This means it does not require additional metallic shielding. For 99% of all applications in offices, practices, and home Networks, this is the perfect and most economical choice. Only in industrial environments with strong electromagnetic interference (EMI) would a shielded STP panel be necessary. For your Gigabit Network, this panel offers everything you need for structured Cabling management and a reliable connection.
Strengths & Notes at a Glance
- Pro: Enables extremely clean and professional organization of Network Cabling in the 19-Inch Rack.
- Pro: Fully CAT6 compliant for reliable Gigabit Ethernet applications.
- Pro: Easy and error-free installation thanks to clear color coding (568A/B) for LSA tools.
- Pro: Very robust and durable construction made of 1.5 mm steel with gold-plated contacts.
- Pro: Integrated strain relief on the back protects connections and ensures tidiness.
- Note: As a UTP panel, it offers no protection against strong electromagnetic interference (EMI).
- Note: An LSA punch-down tool is absolutely necessary for installing the installation cables.
Specifications & Features
| Manufacturer: | Extralink |
| Model/MPN: | EX.9816 |
| EAN/GTIN: | 5902560369816 |
| Product Category: | Patch Panel / Distribution Panel |
| Number of Ports: | 24 x RJ45 Jacks |
| Network Standard: | CAT6 |
| Shielding: | U/UTP (Unshielded Twisted Pair), unshielded |
| Form Factor: | 19-Inch Rack Mount |
| Height Units (U): | 1U |
| Dimensions (W x H): | approx. 482.6 mm x 44.5 mm |
| Weight (Product): | approx. 1.5 kg |
| Weight (with Packaging): | approx. 1.67 kg |
| Color: | Black, powder-coated |
| Panel Material: | Cold-rolled steel, 1.5mm thickness |
| RJ45 Housing Material: | ABS Plastic |
| Contact Material: | Phosphor bronze with gold plating (3u' - 50u') |
| Rear Connection Technology: | LSA punch-down terminals |
| Cable Termination: | Color-coded according to TIA/EIA 568A and 568B |
| Supported Cable Types: | AWG 22-26 (Solid wire) |
| Rated Current: | 1.5 A |
| Insulation Resistance: | > 500 MΩ |
| Contact Resistance: | < 20 mΩ |
| DC Resistance: | < 0.1 Ω |
| Dielectric Strength: | 150 V (Maximum) |
| Mating Cycles (RJ45): | ≥ 1000 |
| Retention Force (Jack/Plug): | 89 N |
| Operating Temperature: | -10°C to +60°C |
| Operating Humidity: | 10% - 90% RH |
| Compliance & Standards: | TIA/EIA-568-A, TIA/EIA-568-B, ISO/IEC 11801, EN 50173 |
| Special Features: | Numbered ports, labeling fields, integrated strain relief (Back Bar) |
Scope of Delivery
| 1 x Extralink 24-Port CAT6 UTP Patch Panel (EX.9816) incl. Cable Management Bar |
Frequently Asked Questions (FAQ)
Do you absolutely need CAT6 cables for this CAT6 patch panel?
Absolutely! To unleash the full Gigabit power for your Network, the entire path must be consistent. So, from the patch panel to your Ethernet Outlets, use at least CAT6 quality for your Cabling. If you use older cables, you'll slow down your entire Network.
What does UTP mean, and is it a disadvantage for my home Network?
UTP stands for 'Unshielded Twisted Pair'. For your home or office Network, this is absolutely not a disadvantage; in fact, it's the standard. You only really need shielding (STP) in industrial environments with strong electrical interference sources.
What is the difference between T568A and T568B wiring?
These are simply two internationally standardized color codes for cable conductors. Technically, they are equivalent. The important thing is: choose one standard and consistently apply it throughout your entire Network – at the patch panel and at the outlets. This way, you avoid errors.
Can you plug your solid installation cable directly into the front of the panel?
No, absolutely not! The front RJ45 jacks are only for flexible Patch Cables to your Ethernet Switch or Router. Your solid installation cable always belongs on the back, where you neatly and securely terminate it onto the IDC terminals with an LSA tool.
Is this patch panel also suitable for my 10-Gigabit Network?
Yes and no. The CAT6 standard is designed for 10 Gbit/s only over short distances, up to about 55 meters. For a stable Gigabit Network, this panel is perfect. However, if you're planning a future-proof 10-Gigabit Network over longer distances, you should opt directly for CAT6a components.
What is the metal bar on the back of your patch panel for?
That's your integrated strain relief, also known as a cable management bar. Here, you secure the incoming installation cables with cable ties. This protects the sensitive contacts from damage due to pulling and ensures a rock-solid and tidy installation of your Cabling.
