Wi-Fi 6 for your DSL connection: Efficient and stable
The FRITZ!Box 7510 AX specifically brings the modern Wi-Fi 6 standard where it is most needed: into the long-range 2.4 GHz band. The result is significantly more stable and faster Wi-Fi that benefits all your devices – from the smartphone on the top floor to the Smart Home sensor in the basement. Especially when many devices are online simultaneously, Wi-Fi 6 demonstrates its strengths by distributing data packets more intelligently, thus ensuring fewer waiting times and more performance for everyone.
The complete home central: Telephony, Smart Home and Mesh
This device is much more than just a simple WiFi Router. With the integrated DECT base, the FRITZ!Box 7510 AX becomes a full-fledged telephone system for up to six cordless phones and simultaneously serves as a control center for your Smart Home devices. Thanks to intelligent Mesh technology, you can seamlessly expand your home Network with other FRITZ! products and enjoy the best reception throughout the house. This makes this DSL / VDSL Router the digital heart of your home.
FRITZ!OS: Easy operation, maximum control
The heart of every FRITZ!Box is the FRITZ!OS operating system. Via the intuitive user interface, you have full control over your Network. Set up secure guest access with just a few clicks, precisely define when and for how long your children can surf with parental control, or securely access your data on the go via VPN. Thanks to regular and free updates from AVM, your FRITZ!Box always remains up-to-date with the latest technology and maximally secure.
Consciously reduced: The focus on the essentials
The FRITZ!Box 7510 AX is deliberately designed as a highly efficient entry-level model. By omitting the 5 GHz band and reducing to one Gigabit LAN port, an extremely low power consumption of an average of only 6 watts is achieved. This not only protects the environment but also your wallet. For users who have a fast DSL connection and mainly go online via Wi-Fi, the 7510 AX offers exactly the right equipment – without unnecessary ballast.
Strengths & Notes at a glance
- Pro: Future-proof thanks to VDSL Supervectoring 35b for up to 300 MBit/s.
- Pro: Extremely energy-efficient with only approx. 6 watts average consumption.
- Pro: Efficient Wi-Fi 6 for more stability with many devices.
- Pro: Full FRITZ!OS functionality including Mesh, DECT, and Smart Home.
- Note: No 5 GHz Wi-Fi band, which can be a disadvantage in heavily utilized radio environments.
- Note: Only one Gigabit LAN port; a switch is required for multiple wired devices.
Specifications & Features
| Manufacturer: | AVM |
| Model: | FRITZ!Box 7510 AX |
| EAN: | 4023125029837 |
| Manufacturer item number: | 20002983 |
| Device type: | Wi-Fi router with integrated DSL modem and telephone system |
| DSL connection: | For VDSL or ADSL connection |
| DSL standards: | VDSL Supervectoring 35b, VDSL2, ADSL2+, Annex-J, VDSL Long Reach |
| Maximum internet speed: | Up to 300 MBit/s |
| Wi-Fi standard: | Wi-Fi 6 (Wi-Fi AX), backward compatible with IEEE 802.11n/g |
| Wi-Fi frequency band: | 2.4 GHz |
| Wi-Fi speed (gross): | Up to 600 MBit/s |
| Antenna configuration: | 2x2 MIMO (internal) |
| Wi-Fi encryption: | WPA3, WPA2, WPA3/2 Transition Mode |
| Wi-Fi features: | Wi-Fi Mesh, guest access, auto channel, Wi-Fi Eco, WPS button |
| Telephony: | For IP-based connections (VoIP) |
| DECT base: | Yes, for up to 6 cordless phones |
| DECT standards: | DECT, DECT-Eco, DECT ULE/HAN-FUN for Smart Home |
| Analog ports: | 1x a/b port (TAE/RJ11) for telephone, answering machine or fax |
| LAN ports: | 1x Gigabit LAN (10/100/1000 MBit/s) |
| USB port: | 1x USB 2.0 for printer or storage media (NAS) |
| Security: | Integrated firewall (SPI), port forwarding, VPN (IPSec) |
| Operating system: | FRITZ!OS with graphical user interface |
| Average power consumption: | approx. 6 watts |
| Dimensions (W x D x H): | 208 x 150 x 37 mm |
| Weight: | approx. 320 g |
Scope of delivery
| 1 x AVM FRITZ!Box 7510 AX |
| 1 x Power Supply unit |
| 1 x 4 m long DSL connection cable |
| 1 x Installation guide |
Frequently Asked Questions (FAQ)
Is the FRITZ!Box 7510 AX suitable for fiber optic connections?
No, the FRITZ!Box 7510 AX has an integrated DSL / VDSL modem and is exclusively designed for direct operation on a DSL or VDSL connection up to 300 Mbps. It cannot be directly connected to a fiber optic connection.
Does the FRITZ!Box 7510 AX support WiFi Mesh?
Yes, the FRITZ!Box 7510 AX is fully Mesh-capable. It can serve as a Mesh Master and be seamlessly connected with other FRITZ! products to form a unified, intelligent WiFi Network.
What WiFi speed does the FRITZ!Box 7510 AX offer?
Thanks to Wi-Fi 6, it offers a gross WiFi speed of up to 600 Mbps in the 2.4 GHz frequency band. The actual net speed depends on the end devices, distance, and environmental conditions.
How many phones can I connect to the FRITZ!Box 7510 AX?
You can register up to six cordless DECT phones with the integrated DECT base. Additionally, it has a connection for an analog device such as a telephone, fax machine, or answering machine.
Does the FRITZ!Box 7510 AX have parental controls?
Yes, the FRITZ!OS operating system includes comprehensive parental controls. This allows you to regulate internet access times using time budgets and filter or block access to specific websites.
Why does the FRITZ!Box 7510 AX only have 2.4 GHz WiFi?
The FRITZ!Box 7510 AX is designed as an energy-efficient entry-level model. The focus is on improving the long-range 2.4 GHz band through the new Wi-Fi 6 standard, which particularly benefits many older devices and smart home products.
