Fiber Speed Without Cables: The Wave AP Micro Makes It Possible
The Ubiquiti Wave AP Micro is the ultimate solution for transmitting fast internet over long distances. As the heart of your Point-to-Multipoint Network, this Access Point functions as a base station that delivers performance otherwise only known from fiber optics. With an aggregated capacity of 5 Gbps in the clean 60 GHz frequency band, you can offer your customers low-latency and extremely fast connections. Perfect for Internet Service Providers (ISPs) who want to open up rural or hard-to-reach areas without having to invest in expensive earthworks. This device belongs to the category of professional 60 GHz Components and sets new standards in wireless connectivity.
Maximum Reliability Through Intelligent 5 GHz Backup
What happens if heavy rain temporarily affects the 60 GHz connection? Ubiquiti has thought of this. The Wave AP Micro features an integrated 5 GHz backup radio based on the modern Wi-Fi 6 standard. If the primary connection fails, the system automatically and seamlessly switches to the more robust 5 GHz band. Although at a reduced speed of over 800 Mbps, the connection remains stable and your customers stay online. As soon as the 60 GHz link is clear again, the system intelligently switches back. This redundancy ensures carrier-grade availability you can rely on, utilizing efficient 5 GHz Components.
Wide Sector Coverage for Your WISP Network
Efficiency is key to success. Instead of countless individual connections, the 90° sector Antenna of the Wave AP Micro allows you to cover a wide area and supply up to 15 client devices simultaneously. This not only reduces infrastructure costs but also significantly simplifies the planning and maintenance of your Network. In combination with suitable client devices such as the Wave Nano or Wave Long-Range, you can build a powerful and scalable wireless Network. As one of the leading WiFi Access Points for outdoor use, it is the first choice for professional users, featuring advanced Antennas, including 5 GHz Antennas.
Thoughtful Design for Professional Use
From mounting to management, the Wave AP Micro is designed for professionals. The robust housing with IPX6 weather protection withstands extreme conditions. Power Supply and data transmission occur via a single network cable thanks to Power over Ethernet – the appropriate PoE Injectors / Power Supplies are already included in the scope of delivery. The integrated Bluetooth module ensures an effortless setup, allowing you to align and configure the Access Point directly via the UISP Mobile App on your smartphone. The integrated GPS synchronizes your devices and helps visualize your Network in the central UISP management software from Ubiquiti.
Strengths & Notes at a Glance
- Pro: Extremely high throughput of 5 Gbps, comparable to fiber.
- Pro: High reliability due to automatic 5 GHz backup radio (Wi-Fi 6).
- Pro: Wide 90° sector coverage for supplying multiple clients with just one device.
- Pro: Robust, weatherproof (IPX6) design for professional outdoor use.
- Pro: Easy setup and management via the free UISP platform.
- Note: An absolute clear line-of-sight is mandatory for 60 GHz operation.
- Note: Uses the proven WPA2-PSK encryption standard; WPA3 is not explicitly listed.
Specifications & Features
| Manufacturer: | Ubiquiti |
| Model: | Wave AP Micro (Wave-AP-Micro) |
| EAN: | 0810010079428 |
| Device Class: | 60 GHz Point-to-Multipoint (PtMP) Access Point, part of 60 GHz Components |
| Network Mode: | Bridge Mode |
| Processor: | Quad-Core ARM® Cortex®-A53 with 1.4 GHz |
| RAM: | 512 MB DDR3L |
| Ports: | (1) 2.5 GbE RJ45 Port |
| Max. Data Throughput (60 GHz): | 5 Gbps aggregated (2.5 Gbps Full-Duplex) |
| Max. Data Throughput (5 GHz): | 800+ Mbps |
| Maximum Client Capacity: | Up to 15 Stations |
| Maximum Range: | Up to 6 km (with Wave Pro/LR), up to 4 km (with Wave Nano) |
| Primary Radio Frequency Band: | 60 GHz (57 - 71 GHz), leveraging 60 GHz Components |
| Backup Radio Frequency Band: | 5 GHz (5.150 - 5.875 GHz), utilizing 5 GHz Components |
| WLAN Standard (60 GHz): | Ubiquiti Wave Technology (based on 802.11ay) |
| WLAN Standard (5 GHz): | 802.11ax (Wi-Fi 6) |
| Backward Compatibility (5 GHz): | 802.11a/b/g/n/ac |
| Channel Bandwidth (60 GHz): | 2160 MHz, 1080 MHz |
| Channel Bandwidth (5 GHz): | 20, 40, 80 MHz |
| Max. Transmit Power (EIRP): | 36.7 dBm |
| Antenna Gain (60 GHz): | 20 dBi, part of advanced Antennas |
| Antenna Gain (5 GHz): | 13.5 dBi, supporting 5 GHz Antennas |
| Antenna Beamwidth (60 GHz): | 90° Azimuth, 25° Elevation |
| Polarization (60 GHz): | Vertical-Linear |
| Polarization (5 GHz): | Dual-Linear |
| Encryption: | WPA2-PSK (AES) |
| Management Platform: | Ubiquiti ISP (UISP) Application (Web & Mobile App) |
| Additional Features: | Integrated GPS, Bluetooth for Setup |
| LED Indicators: | Power, Ethernet, GPS, Link |
| Power Supply Method: | Passive PoE |
| Supported PoE Voltage: | 22–27V DC (2-pair), 44–54V DC (2/4-pair) |
| Included Power Supply: | 48V DC, 0.65A, 2.5 GbE PoE Adapter, a key component for PoE Injectors / Power Supplies |
| Max. Power Consumption: | 24 W |
| Housing Material: | Aluminum Alloy, UV-stabilized Polycarbonate |
| Protection Class: | IPX6 |
| Operating Temperature: | -40 °C to 60 °C |
| Wind Load: | 87 N at 200 km/h |
| Certifications: | FCC, IC, CE |
| Dimensions: | 284 x 156 x 76 mm |
| Weight: | 1.3 kg |
Scope of Delivery
| 1 x Ubiquiti Wave AP Micro |
| 1 x 48V, 0.65A, 2.5 GbE PoE Adapter, essential for PoE Injectors / Power Supplies |
| 1 x Stainless Steel Mounting Hardware, part of our Mounting Systems |
Frequently Asked Questions (FAQ)
What is the range of the Ubiquiti Wave AP Micro?
The maximum range depends on the client device used. It is up to 6 km when connected to a Wave Pro or Wave Long-Range Client and up to 4 km with a Wave Nano Client. This Ubiquiti Networks Access Point is designed for robust Network performance.
Is the Wave AP Micro approved for use in Germany?
Yes, the device has CE certification, which confirms conformity with EU standards and allows operation in Germany. However, the exact frequency ranges may vary depending on regional regulation for this Network device.
Can I use the Wave AP Micro as a regular WiFi Router for home?
No, that is not possible. It is a specialized PtMP Access Point in bridge mode, designed for connecting with compatible Ubiquiti Wave Client devices over long distances. It does not offer WiFi Router functions or standard WiFi for laptops and smartphones, unlike typical WiFi Access Points.
What does '5 GHz Backup Radio' mean?
The device features a second radio module in the 5 GHz band. Should the primary 60 GHz connection, which is susceptible to heavy rain, fail, the system automatically and seamlessly switches to the more stable 5 GHz connection to maintain Network connectivity, albeit with lower throughput. This utilizes both 5 GHz Components and 60 GHz Components.
How is the Wave AP Micro powered?
Power is supplied exclusively via the included 48V Passive PoE Injector (Power over Ethernet). This means that power and data are transmitted to the device over a single Network cable, simplifying installation on masts and reducing Cabling needs. This is a common feature for many PoE Injectors / Power Supplies.
What software is needed to manage the device?
Management, configuration, and monitoring of the Wave AP Micro are centrally performed using the free Ubiquiti ISP (UISP) Software, available as a web application and a mobile app for iOS and Android. This provides comprehensive control over your Ubiquiti Networks devices and is part of the UISP / UniFi Cable ecosystem.
