Your Network, Your Rules: Maximum Control
Are you looking for a Network switch that offers you not only performance but also full control? The Ubiquiti UniFi Switch Pro 48 is exactly what you need. As a Managed Layer 3 Switch, it enables advanced functions such as Inter-VLAN Routing, static routing, and the provision of a DHCP Server. This allows you to design and manage your Enterprise Network exactly according to your ideas, without compromising on performance. Central control via the UniFi Network Controller makes configuration and monitoring a breeze and gives you a complete overview of your network infrastructure at all times.
Power for Your Data: Performance Without Compromise
With 48 Gigabit Ethernet Ports, the USW-Pro-48 offers you an enormous density of connections for all your wired devices. But that's not all: four additional 10G SFP+ Uplinks enable lightning-fast connections to servers, storage systems, or other switches via fiber optics. Whether you're moving large amounts of data or operating a high number of end devices simultaneously – this network switch handles data traffic with a switching capacity of 176 Gbit/s and a total throughput of 88 Gbit/s without blocking. Support for SFP / SFP\+ Modules gives you maximum flexibility in choosing your fiber connectivity.
Security and Overview: Intelligent Features
The USW-Pro-48 thinks along: For maximum reliability, it supports Ubiquiti's UniFi SmartPower RPS (USP-RPS) system, which provides you with redundant Power Supply. This ensures your network remains stable and available even in the event of an internal Power Supply failure. Another highlight is the integrated 1.3" Touchscreen Display. It shows you important status information in real-time and enables quick monitoring and troubleshooting directly on the device – a real advantage for daily administration.
Perfectly Integrated: Your UniFi Ecosystem
This Rackmount Switch (1U) is the ideal addition to your existing Ubiquiti UniFi ecosystem or the perfect starting point for a new, powerful Enterprise Network. Please note that the USW-Pro-48 does not offer Power over Ethernet (PoE) functions on its RJ45 ports. If you want to power PoE-enabled devices such as WiFi Access Points or IP Cameras directly via the switch, you will need the USW-Pro-48-PoE or separate PoE Injectors. For environments that do not require direct PoE power, however, the USW-Pro-48 is the cost-effective and powerful choice that seamlessly integrates into your UniFi environment and allows for central management via the UniFi Network application.
Strengths & Notes at a Glance
- Pro: Comprehensive Layer-3 functions such as Inter-VLAN routing, static routing, and DHCP server functionality for complex network architectures.
- Pro: High performance and capacity with 176 Gbit/s switching capacity and 88 Gbit/s total throughput for non-blocking data processing.
- Pro: Option for redundant Power Supply through support for the UniFi SmartPower RPS (USP-RPS) system for increased reliability.
- Note: No PoE functionality on the RJ45 ports, which requires separate PoE Injectors or a PoE-enabled switch for PoE devices.
- Note: Full functionality and management are tied to integration into the Ubiquiti UniFi ecosystem and the use of the UniFi Network Controller.
Specifications & Features
| Manufacturer: | Ubiquiti |
| Model: | UniFi Switch Pro 48 (USW-Pro-48) |
| Product Type: | Managed Layer 3 Switch |
| Number of RJ45 Ports: | 48x 10/100/1000 Mbit/s Gigabit Ethernet |
| Number of SFP+ Ports: | 4x 1/10G SFP+ |
| Switching Capacity: | 176 Gbit/s |
| Throughput: | 88 Gbit/s (non-blocking) |
| Layer Functions: | Layer 3 (Inter-VLAN Routing, Static Routing, DHCP Server) |
| Management: | UniFi Network Controller, In-Band Ethernet |
| Display: | 1.3" Touchscreen |
| Rack Mount: | Yes, 1U |
| PoE Functionality: | No (no PoE ports) |
| Redundant Power Supply: | Supports UniFi SmartPower RPS (USP-RPS) |
| Max. Power Consumption: | 60W |
| EAN: | 0810010070616 |
Scope of Delivery
| 1 x Ubiquiti UniFi Switch Pro 48 (USW-Pro-48) |
| 1 x Power Cable |
| 1 x Rackmount Kit |
Frequently Asked Questions (FAQ)
What is the difference between the Ubiquiti USW-Pro-48 and the USW-Pro-48-PoE?
The main difference is that the USW-Pro-48 does not offer Power over Ethernet (PoE) functions on its 48 Gigabit RJ45 ports, while the USW-Pro-48-PoE provides PoE+, PoE++, and higher total PoE power for your connected devices.
What management interfaces does the Ubiquiti USW-Pro-48 offer?
The Ubiquiti USW-Pro-48 is managed via an Ethernet in-band interface and is fully integrated into the UniFi Network application, which allows you central control and monitoring.
Can the Ubiquiti USW-Pro-48 be used in a data center?
Yes, the USW-Pro-48 is designed for rack mounting (1U) and offers features such as Layer 3 routing and 10G SFP+ uplinks, making it suitable for use in your data center or larger enterprise networks.
Does the USW-Pro-48 support redundant power supply?
Yes, the UniFi Pro Switch supports Ubiquiti's UniFi SmartPower RPS (USP-RPS) system, which provides redundant power supply for your network in case of internal power supply failure.
What Layer 3 features are included in the Ubiquiti USW-Pro-48?
The USW-Pro-48 offers Layer 3 features such as inter-VLAN routing, static routing, and DHCP server functionality for your local networks.
What is the maximum power consumption of the Ubiquiti USW-Pro-48?
The maximum power consumption of the Ubiquiti USW-Pro-48 is 60W (without PoE output, as it has no PoE ports). Please note that this is the power consumption of the switch itself.
