4K Precision that Hides No Details
The UniFi Protect G6 PTZ redefines what you can expect from an IP Camera. Forget pixelated footage where you can only guess at silhouettes. Thanks to the advanced Dual-Sensor System with 4K resolution, this camera delivers image quality that renders even the smallest details razor-sharp. Whether you want to read a license plate at the end of your driveway or recognize a face in the distance – the 10x Hybrid Zoom brings you right into the action without loss. The mechanical IR cut filter and powerful infrared LEDs also ensure excellent night vision up to 30 meters.
Intelligent Auto-Tracking: Your Digital Watchdog
What good is the best image quality if the most important thing happens outside the frame? The G6 PTZ is more than just a static camera – it's an active observer. Equipped with powerful on-device AI, it not only detects people, vehicles, or animals but can also automatically and smoothly track them. The Pan-Tilt-Zoom mechanism reacts to detected movements with extremely low latency and always keeps the target optimally in focus thanks to Smart Zoom. This provides you with seamless recordings of relevant events without manual intervention.
Built for All Weather: Robust Outdoor PTZ Technology
The UVC-G6-PTZ was designed for demanding outdoor use. The aluminum alloy and polycarbonate housing is IP66 certified, making it completely protected against dust and strong jet water. Even extreme temperatures from -30 °C to 50 °C cannot harm it. Additionally, the IK04 classification offers basic protection against vandalism. This weatherproof outdoor PTZ Camera is the perfect choice to reliably secure your property, parking lot, or company premises. It is one of the most powerful IP Cameras for your professional Network.
Seamless Integration into Your UniFi Protect System
As part of the Ubiquiti ecosystem, the G6 PTZ integrates perfectly into your existing UniFi Protect environment. Setup and management are central and intuitive via the familiar interface of your UniFi Dream Machine Pro or UNVR. Power is supplied simply via a single Ethernet Cable using PoE+ (802.3at). You only need a compatible UniFi Switch or separate PoE Injectors / Power Supplies. Experience a coherent and extremely powerful security system where all components work together perfectly.
Strengths & Notes at a Glance
- Pro: Exceptional 4K image quality with a powerful 10x Hybrid Zoom for maximum detail recognition.
- Pro: Advanced On-Device AI for precise detection and automatic tracking without a cloud subscription.
- Pro: Very robust and weather-resistant design (IP66/IK04), ideal for demanding outdoor areas.
- Pro: Easy integration and central management within the UniFi Protect ecosystem.
- Note: The camera can only be used with a UniFi Protect Host (e.g., UDM Pro, UNVR) and does not function standalone.
- Note: The Network connection is limited to 10/100 Mbps, which is generally sufficient for compressed 4K streams.
Specifications & Features
| Manufacturer: | Ubiquiti |
| Model: | UniFi Protect G6 PTZ (UVC-G6-PTZ) |
| EAN: | 0810177161493 |
| Device Class: | Network Security Camera (Client Device) |
| Sensor System: | Dual-Sensor |
| Wide-angle Sensor: | 1/1.8' 8MP Sensor |
| Telephoto Sensor: | 1/1.8' 8MP Sensor |
| Lens System: | Dual-Lens |
| Wide-angle Lens: | F 4.46 mm, ƒ/1.65 |
| Telephoto Lens: | F 16.3 mm, ƒ/2.4 |
| Max Resolution: | 3840 x 2160 (4K Ultra HD) |
| Max Frame Rate: | 30 FPS |
| Zoom: | 10x Hybrid Zoom |
| Field of View (Wide-angle): | 109.9° (H), 56.7° (V), 134.1° (D) |
| Field of View (Telephoto): | 26.6° (H), 15.1° (V), 30.4° (D) |
| Night Vision: | Integrated IR LEDs with mechanical IR cut filter |
| Night Vision Range: | Up to 30 m |
| Image Settings: | Color, Brightness, Sharpness, Contrast, White Balance, Exposure, 2DNR, 3DNR, NR by Motion, Masking, Text Overlay, HDR |
| Pan Range: | 350° |
| Tilt Range: | 100° |
| Processor: | Quad-Core Arm® Cortex®-A53 based chip |
| AI Engine: | Multi-TOPS AI Engine |
| Intelligent Detection: | People, Vehicles, Animals, Faces, License Plates |
| Storage: | 1x microSD card slot |
| Network Port: | (1) 10/100 MbE RJ45 Port |
| Audio: | Two-way audio with integrated microphone and speaker |
| Power Supply: | PoE+ (Power over Ethernet Plus) |
| PoE Standard: | IEEE 802.3at |
| Supported Voltage Range: | 42.5–57V DC |
| Max Power Consumption: | 24.5 W |
| Typical Power Consumption: | approx. 5.8 - 14 W (depending on operating mode) |
| Protection Class (Weather): | IP66 |
| Protection Class (Vandalism): | IK04 |
| Housing Material: | Aluminum alloy, Polycarbonate |
| Operating Temperature: | -30°C to 50°C |
| Operating Humidity: | 20 to 90% non-condensing |
| Dimensions (without mount): | ⌀107.2 x 104.5 x 203.2 mm |
| Weight (without mount): | 1 kg |
| Weight (with wall mount): | 1.1 kg |
| Certifications: | CE, FCC, IC |
| NDAA Compliance: | Yes |
Scope of Delivery
| 1 x Ubiquiti UniFi Protect G6 PTZ Camera (UVC-G6-PTZ) |
| 1 x Wall Mount |
| 1 x Ceiling Mount |
| 1 x Pole Mount |
Frequently Asked Questions (FAQ)
Does the Ubiquiti G6 PTZ require a separate Power Supply?
No, the camera is powered via PoE+ (Power over Ethernet Plus, 802.3at standard). This means that both data transmission and Power Supply occur over a single Ethernet Cable from a compatible UniFi Switch or PoE Injectors / Power Supplies.
Can the G6 PTZ record in complete darkness?
Yes. It features integrated infrared LEDs that enable a night vision range of up to 30 meters, providing clear black-and-white images even at 0 lux (complete darkness).
Is the camera suitable for outdoor use in rain and snow?
Yes, absolutely. The camera is IP66 certified, meaning it is dust-tight and protected against powerful water jets. The operating temperature range of -30°C to 50°C also ensures reliable use under extreme weather conditions.
What exactly does "10x Hybrid Zoom" mean?
Hybrid zoom combines optical zoom with digital zoom. The G6 PTZ utilizes its dual-lens system to switch between a wide-angle and a telephoto lens, achieving lossless optical zoom, which is then digitally extended to ensure high image quality across the entire zoom range.
Can I store G6 PTZ recordings locally?
Yes, the camera features a microSD card slot for local recordings as a backup. However, primary storage is centralized on the UniFi Protect NVR, which is recommended for professional surveillance.
Does automatic person tracking (Auto-Tracking) work reliably?
Yes, thanks to powerful on-device AI and low-latency PTZ mechanics, the camera can automatically track detected people or vehicles within its field of view. This function, combined with "Smart Zoom," automatically adjusts the zoom to keep the target optimally framed.
