Ubiquiti USG-PRO-4: Proven Enterprise Security
The USG-PRO-4 is the gateway that brought UniFi into the server rack. It offers reliable routing and firewall functions for medium-sized businesses.
Unlike the small desktop models (USG-3), the Pro version features active fans and an internal power supply, making it predestined for continuous operation in the rack.
Ports for Fiber (SFP)
A key feature is the Combo WAN Ports. You can decide whether to feed your internet via standard network cable (RJ45) or fiber (SFP).
This often eliminates the provider's external modem if they offer a direct fiber handoff. Of course, the device supports Multi-WAN (e.g., main line on WAN 1, backup LTE on WAN 2).
Deep Packet Inspection (DPI)
Through the UniFi Controller, the USG-PRO-4 provides exciting insights. Thanks to hardware offloading, it analyzes traffic (DPI) without speed loss. You see exactly which applications (Netflix, YouTube, BitTorrent) are consuming bandwidth and can create rules accordingly.
Detailed Technical Data
| General & Identification | |
| Manufacturer / Model: | Ubiquiti / USG-PRO-4 |
| Form Factor: | 19" Rackmount (1U), 135 mm depth |
| Chassis Material: | Steel, powder-coated |
| Cooling: | Active Fans (Rear) |
| Weight: | 2.3 kg |
| Hardware Performance | |
| Processor: | Dual-Core 1 GHz (MIPS64) with Hardware Acceleration |
| Memory: | 2 GB DDR3 RAM |
| Internal Storage: | 4 GB Flash |
| Packet Processing (64 Byte): | 2,400,000 packets per second |
| Packet Processing (512 Byte): | 4 Gbps (Line Rate) |
| Interfaces | |
| LAN Ports: | 2x 10/100/1000 RJ45 |
| WAN Ports: |
2x 10/100/1000 RJ45/SFP Combo (Either RJ45 or SFP usable) |
| Console Port: | 1x RJ45 Serial Console |
| USB: | 1x USB 2.0 (Reserved for future use) |
| Power Supply | |
| Power Supply: | Internal AC/DC Adapter (60W) |
| Input Voltage: | 110 - 240V AC |
| Power Consumption: | Max. 40 Watt |
Scope of Delivery
| 1 x Ubiquiti USG-PRO-4 Gateway |
| 1 x Power Cord |
| 1 x Rackmount Screw Set (Cage nuts) |
