Ubiquiti LiteBeam M5 23: Your Reliable WiFi Bridge over Long Distances
No more slow connections or expensive earthworks for cables. The Ubiquiti LiteBeam M5 23 is the smart solution for wirelessly connecting two locations. Whether you want to bring the internet to your workshop, connect two company buildings, or set up video surveillance for a remote area – this CPE is the answer. As a specialized component for outdoor wireless Networks, it offers you an extremely stable and directional connection that far surpasses conventional WiFi. Setting it up as a point-to-point wireless link is straightforward and quick thanks to the intuitive airOS software.
Maximum Efficiency thanks to airMAX TDMA Technology
Unlike standard WiFi, where devices can interfere with each other, the LiteBeam M5 uses Ubiquiti's intelligent airMAX TDMA protocol. TDMA (Time Division Multiple Access) assigns fixed time slots for sending and receiving to each connected device. This prevents data collisions, reduces latency, and maximizes data throughput – crucial advantages for a stable point-to-point connection you can always rely on.
Thought Out to the Last Detail: From Mounting to Operation
Ubiquiti has thought of everything in the development of the LiteBeam M5 23. With a weight of only 750 grams and a compact packing size, logistics are a breeze. Mounting on the mast is precise and flexible thanks to the innovative ball joint with 3-axis alignment. Power Supply via Passive PoE (Power over Ethernet) means that you only need to lay a single Ethernet Cable to the Antenna, which supplies both data and power. You cannot install a WiFi Bridge more simply and cleanly.
Strengths & Notes at a Glance
- Pro: Offers unbeatable value for money for professional wireless bridges.
- Pro: The highly directional 23 dBi Antenna enables enormous ranges and is very interference-resistant.
- Pro: Extremely fast, tool-less assembly of the Antenna reflector.
- Pro: Very light and compact, simplifying transport and installation.
- Note: The 10/100 Mbps Ethernet Port limits the real data throughput to less than 100 Mbps and represents the bottleneck of the system.
- Note: The plastic ball joint mount is perceived by some users as less robust compared to metal mounts.
Specifications & Features
| Manufacturer: | Ubiquiti |
| Model: | LiteBeam M5 23 (LBE-M5-23) |
| EAN: | 0810354022326 |
| Manufacturer Part Number (MPN): | LBE-M5-23-EU |
| Product Class: | CPE (Customer Premises Equipment) |
| Processor: | MIPS 74K |
| RAM: | 64 MB RAM |
| Network Interface: | (1) 10/100 Mbps Ethernet Port |
| Max. Data Throughput: | Up to 100 Mbps (physically limited by Ethernet Port) |
| Range: | Up to 30+ km (with optimal line of sight) |
| Frequency Band: | 5 GHz (license-free) |
| Operating Frequency (Worldwide): | 5150 - 5875 MHz |
| WiFi Standard: | 802.11n with airMAX TDMA Protocol |
| Antenna Gain: | 23 dBi |
| Transmit Power (TX Power): | 25 dBm |
| Antenna Type: | Highly directional Antenna with InnerFeed™ Technology |
| Polarization: | Linear |
| Max. VSWR: | 1.5:1 |
| Power Supply: | Passive Power over Ethernet (PoE) |
| PoE Specification: | 24V, 0.2A (Pairs 4, 5+; 7, 8 Return) |
| Included PoE Injectors / Power Supplies: | Yes (24V, 0.2A) |
| Max. Power Consumption: | 4 Watt |
| Dimensions: | 362 x 267 x 184 mm |
| Weight (with mount): | 750 g |
| Housing Material: | UV-stabilized plastic |
| Mounting: | Mast Mounting Kit (included) |
| Operating Temperature: | -40°C to 70°C |
| Operating Humidity: | 5 to 95% (non-condensing) |
| Wind Resistance: | Up to 200 km/h |
| ESD/EMP Protection: | ± 24kV (Air/Contact) |
| Certifications: | CE, FCC, IC |
| RoHS Compliance: | Yes |
Scope of Delivery
| 1 x Ubiquiti LiteBeam M5 23 Antenna |
| 1 x Mast Mounting Kit |
| 1 x 24V, 0.2A Passive PoE Injectors / Power Supplies |
| 1 x Power Cable |
Frequently Asked Questions (FAQ)
Can I use the LiteBeam M5 23 as a regular WiFi Access Point for my home?
No, it is not designed for that. The LiteBeam M5 generates a highly directional signal for point-to-point connections, not a 360-degree signal required for room coverage.
What does CPE mean and what is the airMAX TDMA standard?
CPE stands for 'Customer Premises Equipment' and refers to a device installed at the end-customer's location to establish a connection to the provider's Network. airMAX TDMA is a proprietary Ubiquiti Networks protocol that maximizes radio channel efficiency by assigning fixed time slots to each client for sending and receiving, which prevents collisions and improves throughput.
Do I need a clear line of sight for a stable connection?
Yes, for optimal performance and maximum range, a clear, direct line of sight (LoS) between the two LiteBeam devices is essential. Obstacles such as buildings or dense forests will significantly attenuate or block the signal.
How is the LiteBeam M5 23 powered?
Power is supplied exclusively via the included 24V Passive PoE Injectors / Power Supplies. A single Ethernet Cable provides both the data connection and power.
Is the configuration difficult for beginners?
Configuration is done via the web-based airOS interface. While basic setup of a point-to-point bridge is feasible with guides, fully utilizing its potential and troubleshooting requires Network knowledge. However, the user interface is considered intuitive.
Can the LiteBeam M5 communicate with a newer LiteBeam 5AC model?
Yes, a connection is possible as both use the airMAX protocol. However, the performance of the entire connection will be limited to the capabilities of the older M5 device (802.11n, max. 100 Mbps port). For the best possible performance, identical models should be used.
