Welcome to the Wi-Fi 7 Era: Your Upgrade for Maximum Performance
The EAP725-Wall is more than just an update – it's a quantum leap. With the power of Wi-Fi 7 (802.11be), you are equipped for the future of the internet. Technologies like 4K-QAM pack 20% more data into each signal, while MLO (Multi-Link Operation) intelligently combines frequency bands to drastically reduce latency and maximize throughput. The result is an incredibly fast and responsive connection that remains stable even in environments with hundreds of devices on your Network.
Connectivity Without Compromise: The 2.5G PoE Hub for Your Wall
A fast WiFi Access Point also needs a fast wired connection. That's why the EAP725-Wall features a 2.5 Gigabit uplink port, powered via PoE (802.3at/bt). But that's not all: another 2.5G port with PoE pass-through and two additional Gigabit Ethernet ports make it the perfect all-in-one solution. Connect a PC, an IP phone, or a Smart TV directly and even power another device – all with just a single Ethernet Cable in the wall.
Intelligent Network Management with TP-Link Omada SDN
This WiFi Access Point is part of the intelligent ecosystem of TP-Link Omada. For you, this means: central management made easy. Whether you manage one, ten, or hundreds of WiFi Access Points at different locations – with the Omada Cloud Controller, you have everything under control. Configure SSIDs, set up guest networks with Captive Portal, monitor Network status in real-time, and deploy firmware updates with a few clicks. Scale your network without losing oversight.
Perfectly Integrated: Unobtrusive Design for Professional Demands
Specifically designed for mounting on a flush-mounted box, the EAP725-Wall almost invisibly disappears into your wall. The flat and modern design is ideal for hotel rooms, offices, conference rooms, or sophisticated living spaces where aesthetics play a role. No more cluttered devices and cable mess. You get maximum WiFi performance in a minimal, professional form factor. The easy installation makes it a top choice for system integrators and demanding home users.
Strengths & Notes at a Glance
- Pro: Future-proof Wi-Fi 7 technology for extreme speeds and efficiency.
- Pro: Outstanding wired connectivity with 2.5G PoE-In/Out and two Gigabit Ethernet ports.
- Pro: Seamless integration and central management via the Omada SDN platform.
- Pro: Discrete and functional wall-plate design for a clean installation.
- Note: The device can become noticeably warm under load; good air circulation at the mounting location is recommended.
- Note: Full performance (240 MHz channel width) is regulatorily limited to 160 MHz in the EU.
Specifications & Features
| Manufacturer: | TP-Link |
| Model: | Omada EAP725-Wall |
| EAN: | 8885020626353 |
| Device Class: | WiFi Access Point (Wall Mount) |
| WiFi Standards: | IEEE 802.11a/b/g/n/ac/ax/be |
| Wi-Fi Generation: | Wi-Fi 7 |
| Frequency Bands: | Dual-Band (2.4 GHz, 5 GHz) |
| Max Data Rate (Total, EU Model BE3600): | 3570 Mbps |
| Data Rate 5 GHz (EU Model BE3600): | Up to 2882 Mbps |
| Data Rate 2.4 GHz (EU/US Model): | Up to 688 Mbps |
| Max Data Rate (Total, US Model BE5000): | 5012 Mbps |
| Data Rate 5 GHz (US Model BE5000): | Up to 4324 Mbps |
| Channel Bandwidth (EU Model): | Up to 160 MHz (5 GHz) |
| Channel Bandwidth (US Model): | Up to 240 MHz (5 GHz) |
| Modulation Technologies: | 4K-QAM, MLO (Multi-Link Operation), Multi-RUs |
| Antennas: | 4x Internal |
| Antenna Gain 2.4 GHz: | 2x 4 dBi |
| Antenna Gain 5 GHz: | 2x 5 dBi |
| Transmit Power (TX Power): | < 22 dBm (2.4 GHz), < 22 dBm (5 GHz) |
| Max Client Count: | 250+ |
| Coverage: | approx. 50 m² |
| Processor (Chipset): | Broadcom 1.5 GHz Tri-Core |
| Uplink Port: | 1x 2.5 Gigabit Ethernet Port (PoE-In) |
| Downlink Ports: | 1x 2.5 Gigabit Ethernet Port (PoE Pass-Through), 2x Gigabit Ethernet Ports |
| Power Supply: | 802.3at/bt PoE |
| PoE Pass-Through: | Yes, on the 2.5G Downlink Port (up to 15.4W with 802.3bt Input, up to 7W with 802.3at Input) |
| Max Power Consumption: | 17 W |
| Management: | Central via Omada SDN (Hardware/Software/Cloud Controller), Standalone mode via App |
| Bluetooth: | Bluetooth 5.2 (for configuration) |
| WiFi Encryption: | WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Network Security: | Captive Portal, Access Control, MAC Address Filtering, Wireless Isolation, Rogue AP Detection, VLAN Support |
| Number of SSIDs: | Up to 16 (8 per Band) |
| WiFi Features: | Omada Mesh, Seamless Roaming, Beamforming, Band Steering, Load Balancing, Airtime Fairness, QoS (WMM), Rate Limit |
| Dimensions (W x D x H): | 143 × 86 × 40 mm |
| Weight: | approx. 0.35 kg |
| Mounting: | Wall Mount (Mounting Kit included) |
| Operating Temperature: | 0–40 °C |
| Certificates: | CE, FCC, RoHS |
Scope of Delivery
| 1 x TP-Link Omada EAP725-Wall |
| 1 x Mounting Kit |
Frequently Asked Questions (FAQ)
Does the TP-Link EAP725-Wall require a separate Power Supply?
No, the WiFi Access Point is powered exclusively via Power over Ethernet (PoE). You will need a PoE-compatible Ethernet Switch or a PoE Injector that supports the 802.3at standard or, ideally, 802.3bt.
Can I power another PoE device with the EAP725-Wall?
Yes, the Access Point features a 2.5G port with PoE Pass-Through. If the Access Point itself is powered via 802.3bt PoE, it can provide up to 15.4 watts to a connected device (e.g., an IP Camera or a VoIP phone). When powered via 802.3at, it provides 7 watts.
Do I need to manage the EAP725-Wall with an Omada Controller?
No, it is not strictly necessary. The WiFi Access Point can also be operated in standalone mode and configured via the TP-Link Omada App on a smartphone or tablet. However, for advanced functions and managing multiple UniFi Access Points, central management via a TP-Link Omada Controller is highly recommended.
What is the difference between the US and EU models of the EAP725-Wall?
The main difference lies in the available channel bandwidth in the 5 GHz frequency band. The US model (BE5000) supports up to 240 MHz, which enables higher speeds for 5 GHz Components. The EU model (BE3600) is regulatorily limited to 160 MHz, which reduces the maximum speed.
Is the EAP725-Wall suitable for outdoor use?
No, the device is designed exclusively for indoor use. It does not have an appropriate IP certification against the ingress of water or dust, and its operating temperature is designed for indoor environments. For outdoor needs, consider specific 4G / LTE Outdoor Antennas or 5G Antennas / Outdoor Antennas.
What do Wi-Fi 7 and 4K-QAM mean in practice?
Wi-Fi 7 (802.11be) is the latest WiFi standard, offering higher speeds, lower latency, and improved efficiency in congested networks. 4K-QAM is an advanced modulation technique that enables 20% more data transmission than the previous standard, enhancing overall Network performance.
