The Shelly Pro 1PM Mini Gen3 is the world's smallest WiFi relay switch for DIN rail mounting with integrated power metering. With its compact dimensions of 18.5x89.5x68.5 mm, it fits into any distribution box and offers a professional solution for controlling and monitoring your electrical devices. Based on the new Gen3 platform with the powerful ESP-Shelly-C38F processor, it is lightning-fast and reliable. It can switch devices with up to 16A and provides you with precise real-time data on power consumption.
The integrated WiFi, LAN, and Bluetooth connectivity makes integration into your network a breeze. You can conveniently control the Shelly Pro 1PM Mini Gen3 via the Shelly Smart Control App, cloud platforms, or local voice assistants like Google Assistant or Alexa. Thanks to its small size and low self-consumption of less than 3W, it is the ideal choice for efficient and smart home automation.
Technical Data:
| Model: | Shelly Pro 1PM Mini Gen3 |
| Size (HxWxD): | 18.5x89.5x68.5 ±0.5 mm |
| Weight: | approx. 70g |
| Mounting: | DIN rail |
| Conductor cross-section: | 0.2 to 2.5 mm² / 24 to 14 AWG |
| Stripping length of conductor: | 6 to 7 mm |
| Housing material: | Plastic |
| Color: | Black |
| Ambient temperature: | -20 °C to 40 °C |
| Humidity: | 30 % to 70 % RH |
| Max. altitude: | 2000 m |
| Power supply: | 110-240 VAC, 50/60 Hz |
| Self-consumption: | < 3 W |
| Power measurement: | Yes |
| Max. switching voltage (AC): | 240 V |
| Max. switching current (AC): | 16 A |
| WiFi protocol: | 802.11 b/g/n |
| WiFi frequency band: | 2.4 GHz |
| WiFi radio power: | < 20 dBm |
| Bluetooth protocol: | 4.2 |
| Bluetooth frequency band: | 2.4 GHz |
| Processor: | ESP-Shelly-C38F |
| Flash: | 8 MB |
Scope of Delivery:
| 1x Shelly Pro 1PM Mini Gen3 |
| 1x Quick start guide |
