Your Upgrade for High-Speed Internet: The 2.5G SFP-Port
While most Routers in this price range stop at 1 Gigabit, the MikroTik hEX S (2025) goes a decisive step further. With its integrated 2.5-Gigabit-SFP-Port, you are perfectly equipped for the future. Connect your fiber optic connection directly and use the full bandwidth you pay for. The connection to a fast Network Attached Storage (NAS) or a powerful Ethernet Switch will no longer be a bottleneck. In combination with the matching SFP / SFP\+ Modules, completely new possibilities open up in your home or office Network.
Maximum Flexibility thanks to Power over Ethernet (PoE)
Cabling simplified: The hEX S can not only receive power but also provide it. Via the first Ethernet port (PoE-In), you can conveniently power the Router itself from a PoE Switch, saving you a power adapter. At the same time, the fifth port (PoE-Out) delivers passive PoE, utilizing its capabilities as a PoE Injector / Power Supply to power another device. Ideal, for example, to connect one of our WiFi Access Points or an IP Camera with just a single Network cable.
RouterOS v7: The Power of a Data Center for Your Home
The heart of every MikroTik device is the legendary RouterOS. In version 7, it is more powerful and modern than ever before. Configure complex Firewall rules, segment your Network with VLANs, bundle ports for more throughput (Link Aggregation), or build secure VPN tunnels with WireGuard or IPsec. The Hardware IPsec Acceleration ensures maximum performance. Whether via the graphical interface WinBox, the Web interface, or the command line – you have full control over your MikroTik Router.
Compact, Silent, and Extremely Robust
Despite its enormous performance, the hEX S comes in a compact housing and operates absolutely silently thanks to passive cooling. It has been tested for an extremely wide temperature range from -40°C to 70°C and offers reliability that you are not used to from consumer devices. Integrated sensors for CPU and board temperature as well as voltage ensure that you always have an eye on the status of your system. This wired Router is built to run – 24/7.
Strengths & Notes at a Glance
- Pro: Excellent price-performance ratio with professional Network features, typical for MikroTik Routers.
- Pro: Future-proof 2.5G SFP-Port for high-speed connections (e.g., fiber optic, NAS), compatible with various SFP / SFP\+ Modules.
- Pro: Flexible Power Supply with PoE-In and PoE-Out to simplify Cabling, acting as a PoE Injector / Power Supply.
- Pro: Extremely powerful and customizable RouterOS v7 for full Network control, a hallmark of MikroTik Access Points & Router.
- Note: The enormous functional diversity of RouterOS requires familiarization and is a challenge for absolute beginners.
- Note: As a pure wired Router, it absolutely requires a separate Access Point for a WiFi Network.
Specifications & Features
| Manufacturer: | MikroTik |
| Model: | hEX S (2025 Edition) |
| EAN: | 4752224009753 |
| Product Code: | E60iUGS |
| Device Classification: | Wired Router |
| CPU Architecture: | ARM 64bit |
| CPU Model: | EN7562CT |
| Number of CPU Cores: | 2 |
| Number of CPU Threads: | 2 |
| CPU Clock Frequency: | 950 MHz |
| Switch Chip Model: | EN7523 (integrated) |
| RAM: | 512 MB |
| Storage Size: | 128 MB |
| Storage Type: | NAND |
| Hardware IPsec Acceleration: | Yes |
| Gigabit Ethernet Ports: | 5 x 10/100/1000 Mbit/s (RJ-45) |
| SFP Port: | 1 x SFP Cage (supports 2.5G Modules) |
| USB Port: | 1 x USB 3.0 Type A |
| Maximum USB Current Output: | 1 A |
| USB Power Reset Function: | Yes |
| Number of DC Inputs: | 2 (DC Jack, PoE-IN) |
| Voltage Range (DC Jack): | 12 - 57 V |
| PoE Input: | Port Ether1 |
| PoE-In Standard: | 802.3af/at |
| Voltage Range (PoE-In): | 18 - 57 V |
| PoE Output: | Port Ether5 |
| PoE-Out Standard: | Passive PoE |
| PoE-Out Maximum Voltage: | Up to 57 V (corresponds to input voltage) |
| PoE-Out Current Limit: | 0.5 A (500 mA) |
| Max. Power Consumption (with attachments): | 23 W |
| Max. Power Consumption (without attachments): | 5 W |
| Operating System: | MikroTik RouterOS v7 |
| RouterOS License Level: | 4 |
| Configuration Methods: | WinBox, WebFig, CLI |
| Dimensions: | 113 x 89 x 28 mm |
| Cooling: | Passive (silent) |
| Tested Ambient Temperature: | -40°C to 70°C |
| MTBF: | approx. 100,000 hours at 25°C |
| Certifications: | CE, EAC, ROHS |
| Protection Class: | IP20 |
| Integrated Monitors: | CPU Temperature, PCB Temperature, Voltage |
Scope of Delivery
| 1 x MikroTik hEX S (2025) Gigabit Router (E60iUGS) |
| 1 x Power Adapter (24V, 1.2A) |
Frequently Asked Questions (FAQ)
Can the MikroTik hEX S (2025) provide a whole house with WiFi?
No, the hEX S (2025) is a pure wired MikroTik Router and does not have Antennas or WiFi functions. To establish a robust WiFi Network, you need to connect one or more separate WiFi Access Points to its Ethernet ports.
What is the main advantage of the 2.5G SFP port?
The 2.5G SFP port allows connection to Internet or Network links faster than 1 Gigabit per second. This is ideal for modern fiber optic connections (FTTH) or for connecting to a fast local Network Attached Storage (NAS) to utilize full speed, leveraging advanced SFP / SFP\+ Modules.
Is the hEX S (2025) suitable for beginners?
For absolute Network beginners, it is only conditionally suitable. While a basic configuration of this MikroTik Router is possible, utilizing its advanced features like VPNs, VLANs, and Firewall requires dedicated learning time and fundamental Network understanding.
What does 'PoE-Out' mean on Port 5?
'PoE-Out' means that Port 5 can power another device, such as an IP Camera or a small WiFi Access Point, via the same Ethernet Cable. The MikroTik Router itself must be sufficiently powered for this (e.g., via the included PoE Injectors / Power Supplies).
What is the difference between the new hEX S (2025) and the old model (RB760iGS)?
The 2025 model (E60iUGS) is a significant upgrade for MikroTik Routers: it features a faster ARM CPU, double the RAM (512MB), more storage (128MB), a faster 2.5G SFP port (supporting SFP / SFP+ Modules), and a more modern USB 3.0 connection.
Can I operate the router without a separate Power Supply?
Yes, if you possess a PoE-enabled Ethernet Switch that supports the 802.3af/at standard. You can then power the hEX S MikroTik Router via an Ethernet Cable on Port 1, eliminating the need for a separate Power Supply at the router's location, utilizing efficient PoE Injectors / Power Supplies.
