RouterOS: Your Command Center for the Network
Forget the limited interfaces of typical consumer devices. With the MikroTik hEX lite RB750r2, you dive deep into the world of professional Network administration. The core is the legendary RouterOS with Level 4 license. With it, you configure complex Firewall rules, set up secure VPN tunnels (PPTP, L2TP, OVPN, IPsec) for remote access, or segment your Network with VLANs, for example, to separate your home office from the rest of the house. You get the tools that are otherwise only available to professionals.
Compact, Quiet, and Extremely Economical
The hEX lite was designed for unobtrusive continuous operation. With its minimalist dimensions, it fits into even the smallest technical cabinet or discreetly on a desk. Since it is completely passively cooled, it operates absolutely silently. Its biggest asset, however, is its minimal power consumption of a maximum of 2 watts. This not only protects the environment but also your wallet in 24/7 operation. Its robust plastic Enclosure reliably protects the sensitive technology.
Flexible Installation Thanks to Power over Ethernet (PoE)
Sometimes the best position for a Router is not directly next to a power outlet. MikroTik has thought ahead: The hEX lite RB750r2 can be powered not only via the classic DC barrel jack but also directly via the Network cable. The first Ethernet Port supports passive PoE-In across a wide voltage range of 6V to 30V. In combination with suitable PoE Injectors / Power Supplies or a PoE-enabled Ethernet Switch, you can place the Router exactly where you need it.
Who is the hEX lite the perfect Router for?
The RB750r2 is not a simple plug-and-play Router. It is the ideal choice for tech enthusiasts, administrators in small businesses, and anyone who wants to learn how a Network truly works. It is perfect if you have an internet connection up to 100 Mbit/s and are looking for a stable, highly configurable solution. To set up a WiFi Network, simply combine it with a separate WiFi Access Points to create a professional, modular Network solution.
Strengths & Notes at a Glance
- Pro: Extremely powerful RouterOS with enterprise features (VPN, VLAN, QoS, BGP etc.).
- Pro: Excellent price-performance ratio for the range of functions.
- Pro: Very compact, passively cooled (silent) and extremely energy-efficient (max. 2W).
- Pro: Flexible Power Supply via DC connector or passive PoE-In on the first port.
- Note: Only 10/100 Mbit/s Fast Ethernet Ports; becomes a bottleneck for internet speeds >100 Mbit/s.
- Note: Steep learning curve for RouterOS; not suitable for absolute Network beginners without a willingness to learn.
Specifications & Features
| Manufacturer: | MikroTik |
| Model: | hEX lite |
| Product Code: | RB750r2 |
| EAN: | 4251028602769 |
| Device Classification: | Ethernet Router |
| CPU: | Qualcomm Atheros QCA9533 |
| CPU Architecture: | MIPSBE |
| CPU Cores: | 1 |
| CPU Clock Frequency: | 850 MHz |
| Switch Chip: | QCA9533 (integrated) |
| RAM: | 64 MB |
| Storage Size: | 16 MB |
| Storage Type: | FLASH |
| Ethernet Ports: | 5 x 10/100 Mbit/s |
| Number of DC Inputs: | 2 (DC Barrel Jack, PoE-IN) |
| Voltage Range (DC Barrel Jack): | 6 V - 30 V |
| PoE-In: | Yes, on Port Ether1 |
| PoE-In Standard: | Passive PoE |
| Voltage Range (PoE-In): | 6 V - 30 V |
| Maximum Power Consumption: | 2 W |
| Included Power Adapter: | 24V 0.38A (may vary depending on vendor) |
| Operating System: | MikroTik RouterOS |
| RouterOS License: | Level 4 |
| Dimensions: | 113 x 89 x 28 mm |
| Weight (device only): | 129 g |
| Housing Material: | Plastic |
| Cooling: | Passive (fanless) |
| Tested Ambient Temperature: | -40°C to 70°C |
| MTBF: | approx. 100,000 hours at 25°C |
| Certifications: | CE, EAC, ROHS |
| IP Protection Class: | IP20 |
Scope of Delivery
| 1 x MikroTik hEX lite (RB750r2) |
| 1 x Power Adapter (e.g., 24V, 0.38A) |
Frequently Asked Questions (FAQ)
Is the MikroTik hEX lite RB750r2 suitable for beginners?
Only to a limited extent. While basic configuration is possible via the Quick-Set assistant, using the advanced features of RouterOS requires technical understanding and familiarization time. For pure plug-and-play users, this MikroTik Router is less suitable for managing a complex Network.
Can the RB750r2 provide WiFi?
No, the hEX lite is a pure Ethernet Router and does not have integrated WiFi functions. To set up a WiFi network, a separate WiFi Access Point must be connected to one of the Ethernet Ports using an Ethernet Cable.
Are the 100 Mbps ports sufficient for a modern home network?
That depends on the use case. For internet connections up to 100 Mbps, the speed is sufficient. For faster connections or intensive data transfers to a NAS, a model with Gigabit ports like the MikroTik hEX RB750Gr3, which acts as a robust Ethernet Switch, is the better choice for your Network.
What does "RouterOS Level 4 License" mean?
The Level 4 license is the standard license for MikroTik SOHO devices. It unlocks almost all software features, including advanced routing protocols (RIP, OSPF, BGP) and VPN functions, making this MikroTik Router ideal for small to medium-sized Networks.
Can I operate the Router without the included Power Supply?
Yes, the Router can be powered via the first Ethernet Port (Ether1) using Passive Power over Ethernet (PoE) with a voltage between 6V and 30V, which allows for flexible installation without needing a separate PoE Injector / Power Supply unit, just an Ethernet Cable.
Is the hEX lite suitable for small businesses?
Yes, for small offices with an internet connection up to 100 Mbps, this MikroTik Router is ideal. It can securely segment the Network using VLANs and provide stable VPN access for employees.
