This powerful multiband 4G / LTE directional panel antenna has a high gain of up to 14dBi, is specifically designed for the 800, 1800 and 2600MHz 4G frequency band and compatible to 4G services of various 4G providers. Using this multiband 4G antenna will improve your 4G / LTE connection.
The 4G technology (also referred to as LTE) provides enormously high speeds of wireless data transmission. However, as is so common in wireless networks, there are areas which are not very well covered with the 4G signal by the common providers which will cause a bad 4G connection and a poor datarate. Using this high gain 4G directional antenna can solve these kinds of problems.
This 4G directional multi band antenna with its gain of up to 14dBi will help you to get a stable 4G connection, even on extremely high distances. Due to the high signal amplification, the signal strength, signal stability and transfer rate improves very clearly.
The 4G directional antenna requires an external antenna connector on your 4G router. The common commercial 4G routers offer such an external antenna connector).
The enclosure of the multiband 4G antenna is manufactured from robust, weather-resistant and UV-resistant plastic / PVC. The back is made of stainless steel. The construction is very robust. This allows to use this 4G antenna for in- and outdoor appliances even under extreme weather conditions.
For optimal amplification of your 4G connection, it is recommended that the 4G antenna is installed outdoor with a free line of sight to the transmitter station of your 4G provider.
The antenna is designed for mast/pole or wall handle installation. A mounting kit (angle bracket and u-clamp for 30-50mm diameter handles) is included.
Optional: We offer twin antenna cables with a length of 2.5m, 5m or 10m with N male to SMA male connector to connect the antenna to your 4G router. The shorter the cable, the better!
Technical Data:
| Manufacturer: | JARFT |
| Model: | J4GMB-14-DOMPA |
| Type of Antenna: | Directional 4G Antenna (2x2 MIMO) |
| Gain: | 10dBi @ 800 MHz 14dBi @ 1800MHz 14dBi @ 2600MHz |
| Impedance: | 50 Ohm |
| Frequency: | 791-862 MHz (2G, 4G) 1700 - 2100 MHz (3G, 4G) 2500 - 2700 (4G) |
| VSWR: | max. 1.6 |
| Ground: | DC-Ground |
| Polarisation: | Horizontal / Vertical (Linear) |
| Beam Width: | 30° Horizontal - 25° Vertical |
| Connector: | 2 x N female |
| Appliance: | In- and Outdoor |
| Max input power: | 50W |
| Max wind load: | 200 km/h |
| Operating Temperature: | -30° to 75° C |
| Dimensions: | 47cm x 31cm x 5cm |
| Weight: | 600g |
| Color: | White |
Technical Data Antennacable:
| Cable: | Coaxial TWIN |
| Length: | Optional |
| Impedance: | 50 Ohm |
| Loss: | 0,30db/m @ 800MHz 0,46db/m @ 1,8GHz 0,56db/m @ 2,6GHz |
| Capacity: | 80.3pf/m |
| Inner conductor: | 1.12mm Kupferdraht |
| Isolation: | 2.95mm PE |
| Jacket: | PVC |
| Outer diameter: | 4,95 mm |
| Color: | Black |
| Connector: | N male to SMA male |
Scope of delivery:
| 1 x Multiband 4G/LTE Panel Antenna, 14dBi |
| 1 x Mounting angle and a pipe clamp (30-50mm) |
| Optional: Without / 2.5m / 5m / 10m TWIN cable |
