The Grandstream GWN7710R: Your robust partner for any weather
Do you need an outdoor Network solution that truly delivers what it promises? The Grandstream GWN7710R Outdoor Lite Managed PoE Switch is exactly what you need. With its impressive IP66 certification, it is completely dustproof and protected against strong water jets. Whether scorching sun, icy cold, or heavy rain – this weatherproof Network switch functions reliably in a temperature range of -40°C to 60°C. This makes it the perfect choice for demanding environments where conventional switches would long give up. Trust the industrial Ethernet Switch that is made for extreme conditions.
Maximum Flexibility: PoE Power for your Outdoor Devices
The Grandstream GWN7710R is a true multi-talent when it comes to power supply. As a 6-Port PoE Switch, it not only offers IEEE 802.3af/at/bt PoE output (up to 60W on Port 1, 30W on Port 2-4), but also flexible 24V/48V DC passive PoE outputs. The special feature: You can power the switch itself via PoE-In (PoE++) on Port 5! This is brilliant for solar-powered remote locations or when you don't have an outlet nearby. This way, you effortlessly supply your surveillance camera PoE switch systems or WLAN Access Point outdoor power supply solutions with data and energy. Imagine extending your Network into remote areas without having to lay additional power lines – simple, efficient, and cost-saving.
Smart Networking for Demanding Scenarios
This Layer 2 Lite Managed Switch offers all essential functions for a stable and secure network. With VLAN, QoS, and bandwidth control, you optimize data traffic and prioritize important applications. The integrated 2.5Gbit SFP Port Switch is your gateway to lightning-fast fiber optic connections over several kilometers. This is ideal for connecting distant building sections or extending your network over long distances, for example with SFP / SFP\+ Modules. Whether temporary event networks in harsh environments or hybrid fiber and copper extensions – the GWN7710R makes it possible. The easy DIN-Rail wall mounting PoE Switch option also offers maximum flexibility during installation.
Easy Management, Maximum Control
Managing the Grandstream GWN7710R is incredibly simple and flexible. You can configure it locally via an intuitive web user interface or take advantage of the Grandstream Cloud (GDMS) to monitor and control your network from anywhere. For larger installations, the GWN Manager is available. These versatile management options give you full control over your outdoor network solution. Whether you want to connect IP Cameras, WiFi Access Points, or other PoE devices – with this switch, you always have an overview and full control.
Strengths & Notes at a Glance
- Pro: Extreme Robustness and Weather Resistance: With an IP66 certification, the switch is completely dustproof and protected against strong water jets. It functions reliably in a temperature range of -40°C to 60°C, making it ideal for use in the harshest outdoor conditions.
- Pro: Flexible PoE Options (Input & Output): The GWN7710R not only supports IEEE 802.3af/at/bt PoE output (up to 60W on Port 1, 30W on Port 2-4), but also 24V/48V DC passive PoE outputs. Particularly noteworthy is the PoE input capability on Port 5, which allows the switch itself to be powered via PoE, simplifying installation in power-less environments.
- Pro: Versatile Management and Installation Options: The switch can be managed locally via a web user interface, via the Grandstream Cloud (GDMS), or on-premise with GWN Manager. Support for pole, DIN rail, and wall mounting offers maximum flexibility during installation in various environments.
- Pro: 2.5Gbit SFP Port: Enables fiber optic connections over long distances for fast data transmission.
- Pro: Layer 2 Lite Managed Functions: Supports VLANs, QoS, bandwidth control, and Storm Control for optimized network performance.
- Note: 'Lite Managed' Layer 2 Functionality: Although the switch supports VLANs, QoS, and Storm Control, it is a 'Layer 2 Lite' Managed Switch. It does not offer Layer 3 routing functions, which can be a limitation for more complex network infrastructures with multiple subnets or advanced routing requirements.
- Note: Limited Port Count for Larger Installations: With a total of 6 ports (5x Gigabit RJ45, 1x 2.5G SFP), the switch is well suited for small to medium outdoor deployments. For very large installations with a high number of end devices, however, the port count could be limiting and require the use of multiple switches.
Specifications & Features
| Manufacturer: | Grandstream Networks |
| Model: | GWN7710R Outdoor Lite Managed PoE Switch |
| Product Type: | Outdoor PoE Switch |
| Ports: | 5x Gigabit RJ45, 1x 2.5G SFP |
| PoE Output: | Port 1: 802.3bt (60W), Port 2-4: 802.3at (30W), 24V/48V DC passive |
| PoE Input: | Port 5: 802.3bt (PoE++) |
| Certification: | IP66 (Dustproof and protected against water jets) |
| Operating Temperature: | -40°C to 60°C |
| Management: | Web-UI, Grandstream Cloud (GDMS), GWN Manager |
| Layer Functions: | Layer 2 Lite Managed (VLAN, QoS, Bandwidth Control, Storm Control) |
| Mounting Options: | Pole Mounting, DIN Rail Mounting, Wall Mounting |
| Power Supply: | PoE Input (802.3bt) or external power adapter (not included) |
| Dimensions (LxWxH): | 160 x 100 x 30 mm |
| Weight: | 0.6 kg |
| Humidity: | 10% to 90% non-condensing |
| Lightning Protection: | 6KV Surge Protection |
| ESD Protection: | 8KV Air-discharge, 4KV Contact-discharge |
Scope of Delivery
| 1 x Grandstream GWN7710R Outdoor Lite Managed PoE Switch |
Frequently Asked Questions (FAQ)
What does IP66 certification mean for the Grandstream GWN7710R?
IP66 certification means that the Grandstream GWN7710R is completely dustproof and protected against powerful water jets from any direction, making it ideal for outdoor use in harsh weather conditions.
Can the Grandstream GWN7710R power other devices?
Yes, the Grandstream GWN7710R has 4 PoE output ports that support IEEE 802.3af/at/bt PoE (up to 60W on Port 1 and 30W on Ports 2-4) as well as 24V/48V DC passive PoE, to power connected devices such as IP Cameras or WiFi Access Points.
How is the Grandstream GWN7710R managed?
The Grandstream GWN7710R can be managed in various ways: via a local web UI, via the Grandstream Device Management System (GDMS) cloud platform, or on-premise with GWN Manager.
What types of installations does the GWN7710R support?
The GWN7710R supports flexible installation options such as pole mounting, DIN rail mounting, and wall mounting, making it suitable for a variety of outdoor and indoor applications.
Is the Grandstream GWN7710R suitable for use with solar power?
Yes, the Grandstream GWN7710R is ideal for solar-powered systems as it can be powered via PoE input (PoE++) while simultaneously offering flexible PoE output options (including 24V/48V DC passive) to power other devices, simplifying Cabling in remote areas.
Does the GWN7710R offer advanced network features like VLANs or QoS?
Yes, although it is a "Layer 2 Lite" managed switch, the GWN7710R supports features such as VLANs (global or per port), DSCP/802.1p QoS priority management, bandwidth control, and storm control to optimize network performance and segmentation.
